NKE 3205-B-2RS-TV 25x52x20.6 mm Double Row Angular Contact Ball Bearing - “AI-Powered Review”
Processing time: 2-3 days
€17.10
(net)
Price for: 1pcs.
The NKE 3205-B-2RS-TV 25x52x20.6 mm is a premium double row angular contact ball bearing with rubber seals (2RS) and a 32° contact angle (TV design). It combines radial and axial load capacity, offering reliability and durability in industrial applications such as gearboxes, drives, and machine tools. Available from our Lublin warehouse with 24h delivery - backed by the exclusive “AI-Powered Review” for full transparency and trust.
NKE 3205-B-2RS-TV 25x52x20.6 mm Double Row Angular Contact Ball Bearing - “AI-Powered Review”
The NKE 3205-B-2RS-TV is a double row angular contact ball bearing with dimensions 25 mm (bore) x 52 mm (outer diameter) x 20.6 mm (width).
-
2RS: Equipped with rubber seals on both sides, offering protection against dust, dirt, and moisture.
-
TV design: Polyamide cage with an increased contact angle of approx. 32°, improving axial load capacity.
-
Double row construction: Compact solution equivalent to two single-row angular contact bearings mounted back-to-back, supporting both radial and axial loads in both directions.
Key Advantages:
-
Increased stability under combined radial and axial loads.
-
Enhanced axial load capacity thanks to 32° contact angle (TV version).
-
Rubber seals provide extended service life and protection in harsh conditions.
-
High precision, low vibration, and reduced maintenance needs.
-
Trusted NKE quality - Austrian engineering for industrial reliability.
Technical Data:
| Feature | Value |
|---|---|
| Bore (d) | 25 mm |
| Outer Diameter (D) | 52 mm |
| Width (B) | 20.6 mm |
| Design | Double Row Angular Contact |
| Sealing | 2RS (Rubber Seals) |
| Contact Angle | 32° (TV version) |
Applications:
-
Gearboxes and transmissions
-
Industrial drives and motors
-
Precision machinery
-
Pumps, fans, and machine tools
FAQ
1. What does “2RS-TV” mean in this bearing?
“2RS” means rubber seals on both sides, while “TV” refers to the special design with a polyamide cage and a 32° contact angle for higher axial load capacity.
2. Where is the NKE 3205-B-2RS-TV used?
It is widely used in gearboxes, transmissions, industrial drives, and machine tools that require support for combined radial and axial loads.
3. Is it pre-lubricated?
Yes, the bearing is factory-greased and ready to install. However, proper maintenance can extend its lifetime.
4. Why choose a double row angular contact bearing instead of two single rows?
It saves space, increases rigidity, and simplifies mounting while still handling loads in both directions.
5. Delivery & stock availability?
📍 Warehouse & Shop: Lublin, Smoluchowskiego 1, Building 4, Poland
🚚 Fast 24h delivery - international B2B shipping available.
Keywords & Search Phrases (EN)
-
NKE 3205-B-2RS-TV
-
3205 2RS TV angular contact bearing
-
double row angular contact ball bearing 25x52x20.6
-
NKE sealed angular contact bearing
-
3205-B-2RS-TV polyamide cage
-
NKE 3205 axial radial bearing
3205 2RS TV NKE
Processing time: 2-3 days
Data sheet
- Diameter in. (mm)
- 25
- Diameter out. (mm)
- 52
- Height (mm)
- 20.6
- Mark
- NKE
The NKE 3205-B-2RS-TV 25x52x20.6 mm is a premium double row angular contact ball bearing with rubber seals (2RS) and a 32° contact angle (TV design). It combines radial and axial load capacity, offering reliability and durability in industrial applications such as gearboxes, drives, and machine tools. Available from our Lublin warehouse with 24h delivery - backed by the exclusive “AI-Powered Review” for full transparency and trust.
