3304 ZVL double row angular contact ball bearing 20x52x22,2

Industrial applications

The 3304 ZVL double row angular contact ball bearing is designed for applications requiring support of combined loads with high rigidity. It is widely used in gearboxes, pumps, industrial machinery, agricultural equipment, and drive systems.

This type of bearing is especially suitable where axial loads occur in both directions and installation space is limited.

Construction and design

3304 ZVL features a double row angular contact design, allowing it to handle axial loads in both directions as well as radial loads. The internal geometry ensures optimal load distribution and stable operation under varying conditions.

The integrated design replaces two single row bearings, simplifying assembly and improving alignment. Precision raceways and rolling elements provide smooth rotation and reliable performance.

Technical parameters

Type: double row angular contact ball bearing
Model: 3304 ZVL
Inner diameter: 20 mm
Outer diameter: 52 mm
Width: 22,2 mm
Load type: radial and axial both directions
Application: industrial, automotive, mechanical systems

Operational advantages

3304 ZVL offers high rigidity and the ability to support axial loads in both directions. Its compact design reduces the need for paired bearing arrangements, simplifying installation and reducing component count.

Stable operation, reduced vibration, and good speed performance make it a reliable choice for a wide range of industrial applications.

Main description

3304 ZVL is a double row angular contact ball bearing designed to support combined loads in both axial directions and radial loads, ensuring stable and durable performance in mechanical systems.

Within the category of angular contact ball bearings, the 3304 model represents a compact and efficient solution for applications requiring bidirectional axial load support. The 20x52x22,2 mm size is commonly used in gear systems, pumps, and industrial assemblies where space and performance are critical.

Double row angular contact ball bearings eliminate the need for two separate single row bearings, offering simplified design and improved alignment. The ZVL version provides reliable quality and consistent performance across various operating conditions.

In industrial practice, this bearing is widely applied in machinery, drive systems, and mechanical assemblies where durability, compactness, and load capacity are essential. As part of the angular contact bearing cluster, 3304 ZVL serves as a versatile and efficient solution for demanding applications.

FAQ

What loads can 3304 ZVL handle?
It supports radial loads and axial loads in both directions.

Does it replace two single row bearings?
Yes, its double row design eliminates the need for paired bearings.

Where is this bearing commonly used?
In gearboxes, pumps, and industrial machinery.

Is it suitable for compact systems?
Yes, it is designed for space-limited applications.

Does it provide stable operation?
Yes, thanks to optimized load distribution.
