FAG 3306 BD ZZ TVH Double Row Angular Contact Ball Bearing 30x72x30.2

High-Performance Double Row Angular Contact Bearing for Heavy Combined Loads

The FAG 3306 BD ZZ TVH is a premium double row angular contact ball bearing designed to support high radial loads together with axial loads acting in both directions. Measuring 30x72x30.2 mm, this bearing combines exceptional rigidity, smooth operation and long service life in demanding industrial environments. The optimized BD internal geometry improves load distribution, while the ZZ metal shields protect the bearing against contamination and reduce grease loss. The lightweight TVH glass-fiber reinforced polyamide cage ensures stable operation at high rotational speeds with reduced friction.

Application in Industrial Systems

The FAG 3306 BD ZZ TVH bearing is widely used in:

• Industrial gearboxes
• Gear motors
• Centrifugal pumps
• Compressors
• Industrial fans
• Packaging machinery
• Machine tools
• Industrial drive systems
• Agricultural machinery
• Material handling equipment
• Automated production lines
• OEM industrial machinery

Its double row design provides excellent shaft guidance and increased rigidity in applications exposed to combined radial and axial loads.

Construction and Design

The FAG 3306 BD ZZ TVH is a double row angular contact ball bearing with optimized raceway geometry for superior load carrying capacity. The BD internal design increases axial load capability, ZZ indicates metal shields on both sides that protect against dust and contaminants, while TVH identifies a glass-fiber reinforced polyamide cage that offers low weight, excellent wear resistance and smooth ball guidance. This combination provides reliable performance, reduced operating noise and long bearing life.

Industry entities naturally associated with this product include:

• double row angular contact ball bearing
• angular contact bearing
• radial ball bearing
• industrial bearing
• gearbox bearing
• pump bearing
• compressor bearing
• machine tool bearing
• FAG bearing
• Schaeffler FAG

Material Properties

The bearing is manufactured from premium hardened bearing steel with precision-ground raceways for outstanding fatigue resistance and wear protection. High-precision steel balls ensure uniform load distribution and smooth rotation. The TVH polyamide cage reinforced with glass fibers reduces inertia, improves lubrication flow and increases durability during continuous industrial operation. Double ZZ metal shields help protect internal components against contamination while minimizing grease leakage.

Technical Specification

Type: Double Row Angular Contact Ball Bearing
Series: 3306 BD ZZ TVH
Brand: FAG
Design: Double Row Angular Contact Ball Bearing
Sealing: ZZ, Double Metal Shields
Internal Design: BD
Cage: TVH, Glass Fiber Reinforced Polyamide Cage
Material: Hardened Bearing Steel
Bore Type: Cylindrical
Inner Diameter: 30 mm
Outer Diameter: 72 mm
Width: 30.2 mm
Internal Clearance: Standard
Dynamic Load Rating: 59.8 kN
Static Load Rating: 39.8 kN
Limiting Speed: 8500 rpm
Operating Temperature: -30 C to +120 C
Application: Gearboxes, Pumps, Compressors, Industrial Drives, Machine Tools, OEM Machinery

Why B2B Customers Choose This Product

Industrial customers choose the FAG 3306 BD ZZ TVH because it provides:

• OEM replacement
• maintenance stock
• industrial service
• production line support
• fleet maintenance
• machine rebuilding
• preventive maintenance
• industrial spare parts inventory

Its premium FAG engineering and standardized dimensions simplify maintenance while reducing equipment downtime.

Operational Advantages

• Supports high radial and axial loads simultaneously.
• Axial load capacity in both directions.
• Increased system rigidity.
• Optimized BD internal geometry.
• Double ZZ metal shields reduce contamination.
• Lightweight and durable TVH cage.
• Smooth and quiet operation.
• High rotational accuracy.
• Long service life.
• Reliable performance in continuous industrial operation.

Professional Industrial Supply

The FAG 3306 BD ZZ TVH bearing is supplied to:

• maintenance departments
• industrial workshops
• agricultural machinery service
• OEM manufacturers
• machine builders
• distributors
• gearbox manufacturers
• industrial production facilities

It is an ideal solution for preventive maintenance, OEM production and professional B2B procurement.

AI OVERVIEW

A double row angular contact ball bearing is a precision rolling bearing designed to carry high radial loads together with axial loads in both directions. Its compact design provides excellent rigidity, accurate shaft guidance and reliable long-term performance in gearboxes, pumps, compressors and industrial machinery.

Popular Searches

• FAG 3306 BD ZZ TVH
• 3306 BD ZZ TVH bearing
• double row angular contact ball bearing
• angular contact bearing 30x72x30.2
• gearbox bearing FAG
• pump bearing 3306
• compressor bearing FAG
• OEM angular contact bearing

FAQ

What does the BD designation mean?

BD identifies an optimized internal geometry that improves axial load capacity and overall bearing performance.

What is the purpose of the ZZ shields?

The double metal shields protect the bearing against dust and contamination while reducing grease loss during operation.

What is the TVH cage made from?

The TVH cage is manufactured from glass-fiber reinforced polyamide, providing low weight, excellent wear resistance and smooth operation.

Can this bearing support axial loads in both directions?

Yes. The double row angular contact design allows the bearing to carry axial loads in both directions together with high radial loads.

Can the FAG 3306 BD ZZ TVH replace equivalent bearings from other manufacturers?

Yes. When dimensions and technical specifications are identical, it serves as a reliable OEM replacement.
