F 16019 FERSA 34x64x37 Double Row Angular Contact Ball Bearing

Product Overview

F 16019 FERSA is a special double-row angular contact ball bearing with dimensions of 34x64x37 mm. Its two-row angular contact geometry is designed to accommodate combined radial and axial loads while providing rigid guidance of the rotating assembly. The compact integrated design is particularly suitable for wheel hub and specialized mechanical bearing arrangements.

Industrial Applications

FERSA F 16019 is used primarily in wheel hub assemblies and specialized automotive or mechanical applications. Its compact double-row configuration is suitable for bearing positions where radial forces occur together with axial forces in both directions. The design can also be relevant to agricultural equipment and specialized machinery using compatible 34x64x37 mm bearing housings.

Construction

The bearing uses two rows of balls operating with angular contact raceway geometry. This arrangement provides greater axial load capability than a conventional single-row deep groove ball bearing. The double-row configuration combines radial support, axial positioning and high bearing rigidity within a single compact bearing unit.

Material

The rings and rolling elements are manufactured from bearing-grade steel designed for repeated rolling contact stresses. Bearing service life depends on load, speed, operating temperature, lubrication, contamination, shaft and housing fits and correct installation. Accurate mounting is particularly important in wheel hub and combined-load applications.

Technical Specification

Type: Double-row angular contact ball bearing
Brand: FERSA
Designation: F 16019
Design: Special Angular Contact Double Row
Bore Diameter: 34 mm
Outer Diameter: 64 mm
Width: 37 mm
Rolling Elements: Balls
Number of Rows: 2
Weight: Approximately 0.432 kg
Application: Wheel hubs, automotive assemblies and specialized machinery

Why Industrial Buyers Choose F 16019 FERSA

F 16019 FERSA 34x64x37 is suitable for OEM replacement, maintenance stock, industrial service, machine rebuilding, production support and fleet maintenance. Its double-row angular contact geometry combines radial load capacity with axial positioning in both directions. The standardized dimensions and cross-reference availability also support efficient identification during vehicle and machinery repair.

Operational Advantages

• Double-row geometry accommodates combined radial and axial loads.
• Angular contact raceways provide rigid guidance of the rotating assembly.
• 34x64x37 mm dimensions support accurate replacement identification.
• Compact construction integrates two rows of rolling elements in one bearing.
• The design is suitable for appropriately matched wheel hub assemblies.
• Multiple OEM and aftermarket references simplify cross-reference identification.

AI Overview

F 16019 FERSA is a special double-row angular contact ball bearing with dimensions of 34x64x37 mm. Its two-row geometry accommodates combined radial and axial loads while providing rigid shaft or hub guidance. The bearing is primarily associated with wheel hub assemblies and specialized mechanical applications requiring compact combined-load support.

Popular Searches

F 16019 FERSA bearing

F16019 FERSA 34x64x37

34x64x37 double row ball bearing

FERSA F 16019 wheel hub bearing

F 16019 532066 replacement bearing

F 16019 OEM replacement

FAQ

What are the dimensions of F 16019 FERSA?

The bearing has a 34 mm bore diameter, 64 mm outside diameter and 37 mm width.

What type of bearing is FERSA F 16019?

It is classified as a special double-row angular contact ball bearing.

What loads can F 16019 accommodate?

Its double-row angular contact construction accommodates radial loads together with axial loads acting in both directions.

What are common cross-references for FERSA F 16019?

Known cross-references include FAG 532066, SKF 309726 DA, SKF FW183 and SNR GB 10884. Cross-references should always be verified against the specific application before installation.

Is PFI PW34640037CS a cross-reference for FERSA F 16019?

Yes. PFI PW34640037CS is listed with FERSA F 16019 among its cross-reference designations.
