SKF 7313 BEGAM 65x140x33 - Angular Contact Ball Bearing

SKF 7313 BEGAM 65x140x33 mm - Single Row Angular Contact Ball Bearing

SKF 7313 BEGAM 65x140x33 mm is a single row angular contact ball bearing from the SKF Explorer performance class, belonging to the 73 bearing series. It features a 40-degree contact angle, an optimized internal design, a machined brass cage and a universally matchable GA arrangement for light preload. The bearing has a cylindrical bore, an open construction and is designed to accommodate radial loads together with axial loads acting in one direction.

Technical Specifications - SKF 7313 BEGAM

Load ratings and speeds are SKF catalogue values. Actual operating conditions require consideration of applied loads, lubrication, temperature, mounting fits and the bearing arrangement.

What Does SKF 7313 BEGAM Mean?

7313 - Bearing Series and Size

The designation 7313 identifies a single row angular contact ball bearing belonging to the 73 dimensional series.

Its principal dimensions are:

• Bore diameter: 65 mm.

• Outside diameter: 140 mm.

• Bearing width: 33 mm.

The 73 series comprises angular contact ball bearings designed to accommodate combined radial and axial loads.

B - 40-Degree Contact Angle

The suffix B identifies a bearing with a nominal contact angle of 40 degrees.

The contact angle describes the direction of load transmission between the balls and raceways.

A 40-degree contact angle enables the bearing to accommodate substantial axial loads in one direction together with radial loads.

This characteristic is particularly important when selecting bearings for combined loading conditions.

E - Optimized Internal Design

The letter E identifies an optimized internal bearing design.

This design influences the internal geometry and the load-carrying characteristics of the bearing.

SKF 7313 BEGAM should not automatically be considered equivalent to other 7313 variants with different internal designs.

GA - Universally Matchable Bearing for Light Preload

The suffix GA identifies a universally matchable bearing designed to provide light preload when correctly paired with another compatible bearing.

Universally matchable angular contact ball bearings can be arranged in:

• Back-to-back configurations.

• Face-to-face configurations.

• Tandem configurations.

The resulting bearing arrangement characteristics depend on the selected configuration and matching requirements.

GA does not indicate C3 radial internal clearance.

M - Machined Brass Cage

The suffix M identifies a machined brass cage.

In SKF 7313 BEGAM, the cage is guided by the rolling elements.

The cage maintains the correct spacing between the balls and supports their guidance during operation.

This construction differs from polyamide and pressed steel cages used in other bearing variants.

Construction of SKF 7313 BEGAM

Inner and Outer Rings

The bearing incorporates one-piece inner and outer rings with raceways displaced relative to each other in the axial direction.

This geometry allows the bearing to accommodate combined radial and axial loading.

Steel Balls

The rolling elements are steel balls operating between the inner and outer ring raceways.

Loads are transmitted through rolling contact at a nominal contact angle of 40 degrees.

Machined Brass Cage

The machined brass cage separates the balls and maintains their circumferential spacing.

Its construction differs from polymer and pressed steel cage designs.

The cage material and guidance arrangement must be considered when evaluating the operating conditions.

Open Bearing Construction

SKF 7313 BEGAM is an open bearing without integrated seals or shields.

The bearing arrangement must provide appropriate lubrication and protection against contamination.

Radial and Axial Load Capacity

Radial Loads

SKF 7313 BEGAM accommodates loads acting perpendicular to the shaft axis.

Its basic dynamic load rating C is 116 kN, while its basic static load rating C0 is 86.5 kN.

These ratings are used in bearing life calculations and load assessments.

They must not be interpreted as universally permissible operating loads under all conditions.

Axial Loads

A single row angular contact ball bearing accommodates axial loads in one direction.

To support axial loads acting in both directions, an appropriately arranged bearing pair or another suitable bearing arrangement is generally required.

Combined Loads

SKF 7313 BEGAM can accommodate radial and axial loads simultaneously.

Its 40-degree contact angle is an important parameter when calculating load distribution and selecting the bearing arrangement.

Universally Matchable GA Design

The GA execution is one of the defining characteristics of SKF 7313 BEGAM.

It allows compatible bearings to be matched in different configurations while providing the specified light preload under the appropriate mounting conditions.

Back-to-Back Arrangement

In a back-to-back arrangement, the bearings are positioned with their contact lines diverging outward.

This configuration can provide relatively high moment stiffness and resistance to tilting moments.

It is often selected where shaft support rigidity is important.

Face-to-Face Arrangement

In a face-to-face arrangement, the bearing contact lines converge inward.

This configuration accommodates axial loads in both directions but has different stiffness and misalignment characteristics compared with a back-to-back arrangement.

Tandem Arrangement

In a tandem arrangement, the bearings are oriented in the same direction.

This configuration is used when increased axial load-carrying capacity is required in one direction.

The selection of a bearing configuration requires engineering calculations and consideration of the complete mechanical assembly.

SKF 7313 BEGAM vs Other Bearing Variants

Identical principal dimensions of 65x140x33 mm do not guarantee identical operating characteristics or interchangeability.

7313 BEGAM vs 7313 BECBM

SKF 7313 BEGAM is designed for universal matching with light preload.

SKF 7313 BECBM belongs to a matching execution associated with the CB axial clearance class.

This difference is important when selecting or replacing bearings operating in matched pairs.

7313 BEGAM vs 7313 BEGBM

Both versions incorporate machined brass cages and are designed for universal matching.

However, GA and GB identify different preload classes.

The variants should not be interchanged without evaluating the required stiffness, operating loads and temperature conditions.

7313 BEGAM vs 7313 BEP

Both are single row angular contact ball bearings belonging to the same dimensional series.

However, the suffixes identify different internal and cage executions.

Matching dimensions alone are insufficient to establish technical equivalence.

Alternative Designations and Search References

The product may be encountered under the following written forms:

• SKF 7313 BEGAM

• 7313 BEGAM SKF

• 7313BEGAM SKF

• SKF 7313BEGAM

The complete SKF catalogue designation is 7313 BEGAM.

Designations such as 7313 BECBM, 7313 BEGBM and 7313 BEP must not be treated as alternative spellings of the same product.

They identify different technical executions.

Typical Applications of Single Row Angular Contact Ball Bearings

Angular contact ball bearings are used in mechanical assemblies where radial and axial loads act simultaneously.

Typical application categories include:

• Industrial machine shafts.

• Pump assemblies.

• Mechanical drive systems.

• Rotating machinery.

• Matched bearing arrangements.

• Mechanical systems requiring defined axial stiffness.

These are general applications based on angular contact ball bearing construction.

They do not establish confirmed installation of SKF 7313 BEGAM in any specific machine model.

Industrial Shaft Support

Angular contact ball bearings can provide radial support while accommodating axial loading in a defined direction.

Correct arrangement depends on the direction and magnitude of the applied loads.

Pump Assemblies

Angular contact ball bearings are used in suitable pump arrangements where rotating shafts experience combined radial and axial loading.

Bearing selection must account for speed, lubrication and thermal operating conditions.

Matched Bearing Arrangements

Universally matchable angular contact ball bearings can be used in pairs to achieve specific axial load-carrying and stiffness characteristics.

The GA execution must be considered when selecting the matching configuration.

Selection and Interchangeability of SKF 7313 BEGAM

Before ordering, verify:

1. Complete SKF designation 7313 BEGAM.

2. Manufacturer SKF.

3. Dimensions 65x140x33 mm.

4. Contact angle of 40 degrees.

5. GA universal matching execution.

6. Machined brass cage M.

7. Tolerance class P6.

8. Direction of axial loading.

9. Bearing arrangement configuration.

10. Required preload.

11. Rotational speed.

12. Operating temperature.

13. Lubrication method and conditions.

14. Shaft and housing fits.

A replacement bearing must not be selected solely by its bore diameter, outside diameter and width.

Can Another Manufacturer's Bearing Replace SKF 7313 BEGAM?

An alternative may be considered only after verifying equivalent dimensions, contact angle, internal design, cage construction, matching execution, preload requirements and operating characteristics.

Matching dimensions alone do not establish interchangeability.

Why Is the GA Suffix Important?

The GA suffix identifies a specific universal matching and preload execution.

Using a bearing with a different matching designation may change the preload, stiffness and operating behaviour of the bearing arrangement.

Installation and Operation of SKF 7313 BEGAM

Clean Installation Conditions

Protect the raceways and rolling elements against contamination during installation.

Even small particles can affect bearing performance and service life.

Correct Mounting Fits

Select shaft and housing fits according to the loading conditions and application requirements.

Incorrect fits may affect bearing clearance, preload and operating temperature.

Application of Mounting Force

Do not transmit mounting force through the rolling elements.

Apply the installation force to the ring being mounted with an interference fit.

Correct Bearing Orientation

The direction of axial load transmission must be considered during installation.

In matched bearing arrangements, the bearings must be positioned according to the intended configuration.

Lubrication

SKF 7313 BEGAM is an open bearing and requires suitable lubrication.

The lubricant type, quantity and relubrication intervals must be selected according to rotational speed, operating loads and temperature.

Storage

Store the bearing in its original packaging in a clean, dry environment.

Protect it from moisture, corrosion and mechanical damage before installation.

Frequently Asked Questions - SKF 7313 BEGAM

What Are the Dimensions of SKF 7313 BEGAM?

The bearing has a bore diameter of 65 mm, an outside diameter of 140 mm and a width of 33 mm.

What Does BEGAM Mean in SKF 7313 BEGAM?

B indicates a 40-degree contact angle, E identifies an optimized internal design, GA indicates universal matching with light preload, and M identifies a machined brass cage.

Can SKF 7313 BEGAM Carry Axial Loads in Both Directions?

A single bearing accommodates axial loads in one direction. Axial loads in both directions can be accommodated by an appropriately configured bearing pair.

Does SKF 7313 BEGAM Have a Brass Cage?

Yes. The suffix M identifies a machined brass cage.

What Does GA Mean?

GA identifies a universally matchable bearing designed to provide light preload when correctly paired with another compatible bearing.

Is SKF 7313 BEGAM Sealed?

No. It is an open bearing without integrated seals or shields.

Are SKF 7313 BEGAM and 7313 BECBM Interchangeable?

Automatic interchangeability should not be assumed. These variants differ in their matching execution and clearance or preload characteristics.

What Are the Load Ratings of SKF 7313 BEGAM?

The basic dynamic load rating C is 116 kN, and the basic static load rating C0 is 86.5 kN.

SKF 7313 BEGAM - Quick Technical Overview

SKF 7313 BEGAM is a single row SKF Explorer angular contact ball bearing measuring 65x140x33 mm, featuring a 40-degree contact angle. The GA suffix identifies universal matching with light preload, while M specifies a machined brass cage. The bearing accommodates radial loads and axial loads acting in one direction.
