FAG UCFL206-J7 30 mm 2-Bolt Flange Bearing Unit

FAG UCFL206-J7 30 mm 2-Bolt Flange Bearing Unit

FAG UCFL206-J7 is a complete 2-bolt flange bearing unit designed for a 30 mm shaft. The assembly combines a UC206 radial insert ball bearing with an FL206 cast-iron flange housing. Its principal mounting dimensions are 148x80 mm, with J = 117 mm mounting-hole spacing and two 16 mm mounting holes.

Exact product identification:

FAG + UCFL206-J7 + UCFL 206 J7 + UC206 + FL206 + 30 mm bore + 148x80 mm flange + 117 mm bolt spacing + 2-bolt flange bearing unit

FAG UCFL206-J7 – Technical Characteristics

What Is FAG UCFL206-J7?

FAG UCFL206-J7 is a complete housed bearing unit, not a standalone UC206 bearing.

The assembly consists of:

UC206 – radial insert ball bearing

and:

FL206 – 2-bolt flange housing.

Together, these components form a ready-to-install bearing unit for a nominal:

30 mm shaft.

For correct identification, distinguish between:

UC206 = insert bearing only

FL206 = flange housing

UCFL206-J7 = complete FAG flange bearing unit.

FAG UCFL206-J7 Dimensions

The key mounting dimensions are:

d = 30 mm – bearing bore / nominal shaft diameter

H = 148 mm – flange height

L = 80 mm – flange width

J = 117 mm – mounting-hole centre spacing

N = 16 mm – mounting-hole diameter

U = 40.2 mm – overall axial dimension

Number of mounting holes:

2

For a complete flange bearing unit, a simple three-dimension description does not provide enough mounting information.

A more useful identification is:

30 mm bore + 148x80 mm flange + 117 mm bolt spacing + 2 x 16 mm mounting holes.

FL206 2-Bolt Flange Housing

FAG UCFL206-J7 uses an FL206 cast-iron flange housing.

It has an elongated 2-bolt configuration with mounting points located on opposite sides of the bearing axis.

The:

148x80 mm flange dimensions

and:

117 mm mounting-hole spacing

are key parameters when identifying the unit.

The FL206 housing configuration is fundamentally different from a square four-bolt F206 housing.

UC206 Radial Insert Ball Bearing

The bearing insert used in FAG UCFL206-J7 is:

UC206.

Its nominal bore diameter is:

30 mm.

UC206 belongs to the radial insert ball bearing family and is designed to operate in a compatible housing.

The spherical outside surface of the insert operates against the corresponding spherical seat in the housing.

This bearing-to-housing geometry allows the assembled unit to compensate for limited static mounting misalignment.

It should not be confused with the internal self-aligning principle of a conventional double-row self-aligning ball bearing.

Shaft Location by Set Screws

The UC206 insert is secured to the shaft using set screws in the extended inner ring.

Common English terminology includes:

set screw locking

set screws

grub screw locking

and:

grub screws.

The shaft-locking system is an important selection parameter.

Another 30 mm flange bearing unit should not automatically be considered interchangeable if it uses a different shaft-location method.

FAG UCFL206-J7 vs UCF206-J7

These are different bearing-unit configurations.

UCFL206-J7 uses an:

FL206 elongated 2-bolt flange housing.

By contrast:

UCF206-J7

uses an:

F206 square 4-bolt flange housing.

Therefore:

UCFL206 ≠ UCF206.

Both units may use a UC206 insert and have a 30 mm bore, but their housing geometry and mounting-hole arrangements are different.

FAG UCFL206-J7 vs UC206

These references also identify different products.

FAG UC206

is the radial insert ball bearing itself.

FAG UCFL206-J7

is the complete assembly:

UC206 insert + FL206 flange housing.

If only the insert bearing requires replacement, UC206 is the relevant reference.

If the complete 2-bolt flange assembly is required, the relevant product is:

FAG UCFL206-J7.

What Does J7 Mean in FAG UCFL206-J7?

J7 is part of the exact FAG execution designation and relates to the bearing-to-housing fit.

It should not be interpreted as:

shaft diameter

C3 radial internal clearance

or:

bearing precision class.

When the exact FAG product is required, retain the complete designation:

FAG UCFL206-J7.

Removing the J7 suffix broadens the identification to the generic UCFL206 size and potentially other executions.

FAG UCFL206-J7 Mounting-Hole Spacing – 117 mm

The unit has:

2 mounting holes.

Each mounting hole has a diameter of:

16 mm.

The centre-to-centre mounting-hole spacing is:

J = 117 mm.

This is one of the most important dimensions when identifying an existing UCFL206 flange bearing.

Before ordering, verify:

shaft diameter – 30 mm

flange height – 148 mm

flange width – 80 mm

mounting-hole spacing – 117 mm

and:

mounting-hole diameter – 16 mm.

A 30 mm shaft diameter alone does not establish mounting compatibility.

FAG UCFL206-J7 Load Ratings

Basic dynamic load rating:

Cr = 19,500 N = 19.5 kN

Basic static load rating:

C0r = 11,300 N = 11.3 kN

Fatigue load limit:

Cur = 480 N = 0.48 kN

These are standardized bearing parameters used in bearing selection and calculation.

Cr should not be interpreted as a universal maximum permissible load for the complete bearing unit regardless of mounting, load direction, required bearing life and operating conditions.

Selection and Interchangeability

When selecting a replacement for FAG UCFL206-J7, verify:

exact designation – UCFL206-J7

bore diameter d = 30 mm

UC206 insert bearing

FL206 housing type

2-bolt flange geometry

flange height H = 148 mm

flange width L = 80 mm

mounting-hole spacing J = 117 mm

mounting-hole diameter 16 mm

shaft-locking system

bearing load ratings

and:

operating conditions.

The 206 size designation, a 30 mm bore or a visually similar housing does not by itself establish full interchangeability.

How Is FAG UCFL206-J7 Searched Online?

Industrial buyers, maintenance engineers and purchasing departments may search for this unit using the exact FAG designation, shortened UCFL206 reference, bearing insert number, housing number, shaft diameter or mounting dimensions.

Common search variants include:

• FAG UCFL206-J7
• UCFL206-J7 FAG
• FAG UCFL 206 J7
• UCFL 206 J7 FAG
• FAG UCFL206 J7
• UCFL206 J7 FAG
• FAG UCFL206
• UCFL206 FAG
• FAG UCFL 206
• UCFL 206 FAG
• UCFL206-J7
• UCFL206 J7
• UCFL 206 J7
• UCFL206
• UCFL 206
• UCFL206 bearing
• FAG UCFL206 bearing
• UCFL206 bearing unit
• FAG UCFL206 bearing unit
• UCFL206 housed bearing
• UCFL206 housed bearing unit
• UCFL206 housing bearing
• UCFL206 flange bearing
• FAG UCFL206 flange bearing
• UCFL206 flange bearing unit
• FAG UCFL206 flange bearing unit
• UCFL206 flanged bearing unit
• UCFL206 flanged housing unit
• FAG UCFL206 flanged housing unit
• UCFL206 oval flange bearing
• UCFL206 oval flange bearing unit
• UCFL206 2 bolt flange bearing
• UCFL206 2-bolt flange bearing
• UCFL206 two bolt flange bearing
• UCFL206 2 bolt bearing
• FAG 2 bolt flange bearing 30mm
• FAG 2-bolt flange bearing 30mm
• 2 bolt flange bearing 30mm
• 2-bolt flange bearing 30mm
• two bolt flange bearing 30mm
• 30mm flange bearing
• 30 mm flange bearing
• 30mm flange bearing unit
• 30mm flanged bearing unit
• 30mm oval flange bearing
• 30mm oval flange bearing unit
• 30mm 2 bolt flange bearing
• 30mm 2-bolt flange bearing
• 30mm bore flange bearing
• 30mm bore flange bearing unit
• 30mm bore 2-bolt flange bearing
• UCFL206 30mm
• UCFL206 30 mm
• UCFL206 30mm bore
• UCFL206 30 mm bore
• FAG UCFL206 30mm
• FAG UCFL206 30 mm
• UCFL206 148x80
• UCFL206 30x148
• UCFL206 30x148x40.2
• FAG UCFL206 30x148x40.2
• UCFL206 30mm 148x80
• UCFL206 117mm
• UCFL206 117 mm
• UCFL206 117mm bolt spacing
• UCFL206 117 mm bolt spacing
• UCFL206 117mm mounting holes
• UCFL206 117 mm hole spacing
• UCFL206 16mm mounting holes
• UC206 FL206
• UC206 + FL206
• FAG UC206 FL206
• FL206 housing UC206
• FL206 bearing housing with UC206
• UC206 flange housing
• UC206 flange bearing unit
• UC206 2 bolt flange housing
• UC206 2-bolt flange housing
• UC206 30mm flange bearing
• FAG flange bearing 30mm
• FAG 30mm flange bearing unit

The exact product described on this page is:

FAG UCFL206-J7 – complete 2-bolt flange bearing unit for a 30 mm shaft, combining a UC206 radial insert ball bearing with an FL206 cast-iron housing and 117 mm mounting-hole spacing.

UCFL 206 J7 FAG – Is It the Same as FAG UCFL206-J7?

Yes. Search formats such as:

UCFL 206 J7 FAG

FAG UCFL 206 J7

UCFL206 J7 FAG

UCFL206-J7 FAG

and:

FAG UCFL206-J7

are common ways of searching for the same exact FAG reference.

For precise technical identification, use:

FAG UCFL206-J7.

Is UCFL206 the Same as UCFL206-J7?

UCFL206 is a general size and construction designation used across the bearing industry.

UCFL206-J7 is the specific FAG execution.

Therefore, when the exact FAG product is required, retain the complete reference:

FAG UCFL206-J7.

Does FAG UCFL206-J7 Fit a 30 mm Shaft?

Yes. The nominal bore diameter is:

d = 30 mm.

However, when replacing the complete unit, also verify:

148 mm flange height

80 mm flange width

117 mm mounting-hole spacing

and:

2 x 16 mm mounting holes.

Is UCFL206-J7 a 2-Bolt or 4-Bolt Flange Bearing?

FAG UCFL206-J7 is a 2-bolt flange bearing unit.

For comparison:

UCFL206 = FL206 elongated 2-bolt flange housing

UCF206 = F206 square 4-bolt flange housing.

These housing types should not be treated as interchangeable.

Is UCFL206-J7 a Pillow Block Bearing?

No.

FAG UCFL206-J7 is a 2-bolt flange bearing unit, not a pillow block bearing unit.

Pillow block housings use a different mounting geometry. This distinction matters when searching for a 30mm housed bearing, because both pillow block and flange units may use a 30 mm insert but are mounted differently.

Technical Specification

FAQ

What is FAG UCFL206-J7?

FAG UCFL206-J7 is a complete 2-bolt flange bearing unit combining a UC206 radial insert ball bearing with an FL206 cast-iron flange housing.

What bore size does FAG UCFL206-J7 have?

The nominal bore diameter is 30 mm.

What is the mounting-hole spacing of UCFL206-J7?

The centre-to-centre distance between the two mounting holes is 117 mm.

What are the main dimensions of FAG UCFL206-J7?

The flange measures 148x80 mm, the bore is 30 mm, mounting-hole spacing is 117 mm, and overall axial dimension U is 40.2 mm.

Which bearing insert is used in FAG UCFL206-J7?

The unit uses a UC206 radial insert ball bearing.

Is UC206 the same as UCFL206-J7?

No. UC206 is the insert bearing, while UCFL206-J7 is the complete UC206 + FL206 flange housing assembly.

What is the difference between UCFL206 and UCF206?

UCFL206 uses an FL206 elongated 2-bolt flange housing, while UCF206 uses an F206 square 4-bolt flange housing.

Can any UCFL206 replace FAG UCFL206-J7?

Interchangeability should not be assumed from the UCFL206 designation alone. Verify the 30 mm bore, 148x80 mm housing geometry, 117 mm mounting-hole spacing, 16 mm mounting holes, shaft-locking method, bearing load ratings and housing execution.
