FYC 50 TF SKF 50 mm Round Flanged Bearing Unit
Processing time: 2-3 days
€51.87
(net)
Price for: 1pcs.
SKF FYC 50 TF is a complete round flanged bearing unit for a 50 mm shaft, combining an SKF Y-bearing insert with a robust cast iron housing. Set screw locking provides straightforward shaft mounting, while the spherical bearing seat compensates for limited initial misalignment.
Suitable for conveyors, agricultural machinery, material handling systems, production equipment and general industrial applications.
Warehouse and Store
Lublin, Smoluchowskiego 1 Street, Building 4
Fast Order Fulfillment
Available from stock in Poland with fast order fulfillment for industrial and B2B customers throughout Poland and the European Union.
Overview
The SKF FYC 50 TF is a complete round flanged bearing unit for a 50 mm shaft, combining an SKF Y-bearing insert with a robust cast iron housing.
The bearing is secured directly to the shaft by set screws, while its spherical outside surface works with the corresponding housing seat to compensate for limited initial mounting misalignment.
The complete unit provides a practical, ready-to-install bearing solution for conveyors, agricultural machinery, material handling equipment and general industrial machinery.
Product Type
The FYC 50 TF is a complete bearing unit, not an empty housing.
The assembly includes:
- SKF Y-bearing / insert bearing
- Round flanged housing
- Cast iron housing body
- Integrated bearing sealing
- Set screw shaft locking
- Relubrication arrangement
Industrial Applications
SKF FYC 50 TF is suitable for:
- Conveyor systems
- Material handling equipment
- Agricultural machinery
- Packaging machinery
- Industrial fans
- Production machinery
- Processing equipment
- Woodworking machinery
- Industrial drives
- General mechanical equipment
Construction
The SKF FYC series uses a round flanged housing designed for direct mounting to a machine frame or supporting structure.
The Y-bearing has a spherical outside surface that matches the corresponding spherical housing seat. This arrangement allows the unit to compensate for limited initial misalignment between the shaft and housing.
Technical Specification
Manufacturer: SKF
Designation: FYC 50 TF
Product Type: Flanged bearing unit
Unit Type: Round flanged bearing unit
Shaft Diameter: 50 mm
Bearing Type: Y-bearing / insert ball bearing
Housing Type: Flanged
Housing Shape: Round
Housing Material: Cast iron
Shaft Locking: Set screws
Bearing Outside Surface: Spherical
Sealing: Integrated bearing sealing system
Lubrication: Grease lubricated
Relubrication: Yes
Measurement System: Metric
Supply Form: Complete bearing unit
FYC 50 TF Designation Explained
FYC - SKF round flanged bearing unit series
50 - nominal shaft diameter of 50 mm
TF - bearing unit configuration with set screw shaft locking
The complete designation should be retained when selecting a replacement because bearing units for the same 50 mm shaft may differ in housing geometry, mounting dimensions and shaft locking method.
Set Screw Shaft Locking
The bearing is secured directly to the 50 mm shaft using set screws located in the inner ring.
This system provides:
- Straightforward installation
- Direct shaft fixation
- Easy positioning
- Secure bearing retention
- Convenient servicing
No adapter sleeve is required.
Misalignment Compensation
The spherical outside surface of the bearing insert allows it to align within the matching housing seat.
This helps compensate for limited initial misalignment caused by:
- Installation tolerances
- Machine frame inaccuracies
- Minor shaft-to-housing misalignment
- Mounting surface tolerances
The unit is not designed to accommodate large continuous shaft deflections during operation.
Sealing and Lubrication
The integrated bearing sealing system helps retain grease and protect the rolling elements and raceways against external contamination.
The unit is supplied grease lubricated and can be relubricated when required by the operating conditions.
Relubrication intervals depend on factors such as rotational speed, temperature, load, contamination and operating time.
Operational Advantages
- Complete SKF unit ready for installation.
- Designed for a 50 mm shaft.
- Robust round cast iron flanged housing.
- Simple set screw shaft locking.
- Compensation for limited initial misalignment.
- Integrated sealing and relubrication capability.
Bearing Unit vs Bearing Housing
The SKF FYC 50 TF is a complete bearing unit, consisting of both the bearing insert and its matching housing.
A bearing housing refers only to the supporting housing without the bearing.
For product classification and replacement purposes, FYC 50 TF should therefore be described as a round flanged bearing unit.
Replacement and Selection
When replacing an SKF FYC 50 TF, verify:
- 50 mm shaft diameter
- FYC round flange design
- Housing mounting dimensions
- Bolt-hole arrangement
- Set screw shaft locking
- Required load capacity
- Rotational speed
- Operating environment
- Lubrication requirements
Shaft diameter alone is not sufficient to confirm interchangeability with another bearing unit.
AI OVERVIEW
The SKF FYC 50 TF is a complete round flanged bearing unit for a 50 mm shaft. It combines an SKF Y-bearing insert with a cast iron housing and set screw shaft locking. Its spherical bearing-to-housing interface compensates for limited initial mounting misalignment, making it suitable for conveyors, agricultural machinery and industrial equipment.
POPULAR SEARCHES
- SKF FYC 50 TF
- FYC 50 TF SKF
- FYC50TF
- SKF FYC 50
- FYC 50 bearing unit
- SKF bearing unit 50 mm
- 50 mm flanged bearing unit
- SKF flange bearing 50 mm
- round flange bearing unit 50 mm
- SKF Y-bearing unit
- SKF cast iron flange bearing
FAQ
What is the SKF FYC 50 TF?
It is a complete round flanged bearing unit designed for a 50 mm shaft.
Is FYC 50 TF a bearing unit or only a housing?
It is a complete bearing unit containing both the bearing insert and its matching flanged housing.
What shaft diameter is FYC 50 TF designed for?
The nominal shaft diameter is 50 mm.
What type of bearing does the unit contain?
It uses an SKF Y-bearing, also commonly referred to as an insert ball bearing.
What material is the housing made from?
The housing is manufactured from cast iron.
How is the bearing secured to the shaft?
The bearing is secured using set screws located in the inner ring.
Does it require an adapter sleeve?
No. The bearing is mounted directly onto the shaft.
Can FYC 50 TF compensate for misalignment?
Yes. Its spherical bearing-to-housing interface allows compensation for limited initial mounting misalignment.
Is the bearing sealed?
Yes. The bearing insert incorporates an integrated sealing system.
Is the unit supplied lubricated?
Yes. It is grease lubricated and ready for installation.
Can FYC 50 TF be relubricated?
Yes. The design allows relubrication when required by operating conditions.
Can it be used in conveyor systems?
Yes. Conveyors and material handling systems are typical applications for this type of bearing unit.
Is it suitable for agricultural machinery?
Yes. Flanged bearing units are widely used in agricultural and processing machinery.
Can any 50 mm flange bearing replace FYC 50 TF?
No. Housing geometry, mounting dimensions, bolt-hole arrangement and locking method must also be verified.
What is the correct parent category?
The product belongs to Flanged Bearing Units.
