FYC 30 TF SKF 30 mm Round Flanged Bearing Unit
Processing time: 2-3 days
€31.30
(net)
Price for: 1pcs.
SKF FYC 30 TF is a complete round flanged bearing unit for a 30 mm shaft, combining an SKF Y-bearing insert with a robust cast iron housing. Set screw locking provides straightforward shaft mounting, while the spherical bearing seat compensates for limited initial misalignment.
Suitable for conveyors, agricultural machinery, material handling systems, production equipment and general industrial applications.
Warehouse and Store
Lublin, Smoluchowskiego 1 Street, Building 4
Fast Order Fulfillment
Available from stock in Poland with fast order fulfillment for industrial and B2B customers throughout Poland and the European Union.
Overview
The SKF FYC 30 TF is a complete round flanged bearing unit for a 30 mm shaft, combining an SKF Y-bearing insert with a robust cast iron housing.
The bearing is secured directly to the shaft by set screws, while its spherical outside surface allows the insert to align within the housing and compensate for limited initial mounting misalignment.
The complete unit is designed for straightforward installation in conveyors, agricultural machinery, material handling equipment and general industrial machinery.
Product Type
The FYC 30 TF is a complete bearing unit, not an empty housing.
The assembly combines:
- SKF Y-bearing / insert bearing
- Round flanged housing
- Cast iron housing body
- Integrated bearing sealing
- Set screw shaft locking
- Relubrication arrangement
Industrial Applications
SKF FYC 30 TF is suitable for:
- Conveyor systems
- Agricultural machinery
- Packaging equipment
- Material handling systems
- Industrial fans
- Production machinery
- Processing equipment
- Textile machinery
- Woodworking machinery
- General industrial drives
Construction
The SKF FYC series uses a round flanged housing designed for direct mounting to a machine frame or supporting structure.
The Y-bearing has a spherical outside surface that matches the corresponding housing seat. This arrangement enables the unit to compensate for limited initial misalignment between the shaft and housing.
The bearing is mounted directly on the shaft using set screws located in the inner ring.
Technical Specification
Manufacturer: SKF
Designation: FYC 30 TF
Product Type: Flanged bearing unit
Unit Type: Round flanged bearing unit
Shaft Diameter: 30 mm
Bearing Type: Y-bearing / insert ball bearing
Housing Type: Flanged
Housing Shape: Round
Housing Material: Cast iron
Shaft Locking Method: Set screws
Bearing Outside Surface: Spherical
Sealing: Integrated bearing sealing system
Lubrication: Grease lubricated
Relubrication: Yes
Measurement System: Metric
Supply Form: Complete bearing unit
FYC 30 TF Designation Explained
FYC - SKF round flanged bearing unit series
30 - nominal shaft diameter of 30 mm
TF - bearing unit configuration with set screw shaft locking
The complete designation should be used when selecting a replacement because other 30 mm bearing units may have different housing shapes, mounting dimensions or locking systems.
Set Screw Locking
The bearing is secured directly to the 30 mm shaft by set screws in the inner ring.
This mounting system provides:
- Easy installation
- Direct shaft fixation
- Simple positioning
- Secure shaft retention
- Convenient servicing
No adapter sleeve is required.
Misalignment Compensation
The spherical outside surface of the Y-bearing works with the spherical seat in the housing.
This allows the unit to compensate for limited initial misalignment caused by installation or mounting tolerances.
It is not intended to accommodate large continuous shaft deflections during operation.
Sealing and Lubrication
The integrated bearing sealing system helps retain grease and protect the rolling elements against external contamination.
The unit is supplied grease lubricated and can be relubricated when required by operating conditions.
Relubrication intervals depend on speed, load, temperature, contamination and operating time.
Operational Advantages
- Complete SKF bearing unit ready for installation.
- Designed for a 30 mm shaft.
- Robust round cast iron flanged housing.
- Simple set screw shaft locking.
- Compensation for limited initial misalignment.
- Integrated sealing and relubrication capability.
Replacement and Selection
When replacing an SKF FYC 30 TF, verify:
- 30 mm shaft diameter
- FYC round flange design
- Housing mounting dimensions
- Bolt-hole arrangement
- Set screw locking
- Required load capacity
- Rotational speed
- Operating environment
- Lubrication requirements
Shaft diameter alone is not sufficient to confirm interchangeability with another flanged bearing unit.
AI OVERVIEW
The SKF FYC 30 TF is a complete round flanged bearing unit for a 30 mm shaft. It combines an SKF Y-bearing insert with a cast iron housing and set screw shaft locking. Its spherical bearing-to-housing interface compensates for limited initial mounting misalignment, making it suitable for conveyors, agricultural machinery and industrial equipment.
POPULAR SEARCHES
- SKF FYC 30 TF
- FYC 30 TF SKF
- FYC30TF
- SKF FYC 30
- FYC 30 bearing unit
- SKF bearing unit 30 mm
- 30 mm flanged bearing unit
- SKF flange bearing 30 mm
- round flange bearing unit 30 mm
- SKF Y-bearing unit
- SKF cast iron flange bearing
FAQ
What is the SKF FYC 30 TF?
It is a complete round flanged bearing unit designed for a 30 mm shaft.
Is FYC 30 TF a complete bearing unit or only a housing?
It is a complete unit containing both the Y-bearing insert and its matching flanged housing.
What shaft diameter is FYC 30 TF designed for?
The nominal shaft diameter is 30 mm.
What type of housing does it use?
It uses a round flanged cast iron housing.
How is the bearing secured to the shaft?
The bearing is secured using set screws in the inner ring.
Does it require an adapter sleeve?
No. The bearing is mounted directly onto the shaft.
Can FYC 30 TF compensate for misalignment?
Yes. The spherical bearing outside surface allows compensation for limited initial mounting misalignment.
Is the bearing sealed?
Yes. The Y-bearing incorporates an integrated sealing system.
Is the unit supplied lubricated?
Yes. It is grease lubricated and ready for installation.
Can the bearing unit be relubricated?
Yes. The design allows relubrication when required by operating conditions.
Can it be used in conveyors?
Yes. Conveyor and material handling systems are typical applications.
Can it be used in agricultural machinery?
Yes. Flanged bearing units are widely used in agricultural and processing machinery.
Can any 30 mm flange bearing replace FYC 30 TF?
No. Mounting dimensions, housing geometry, locking method and operating requirements must also be verified.
What is the difference between a bearing unit and a housing?
A bearing unit contains both the bearing and housing. A housing is only the supporting body without the bearing insert.
What is the correct parent category?
The product belongs to Flanged Bearing Units.
