16B-1 CT Roller Chain 25.4 mm (1 inch) - Simplex

16B-1 CT Roller Chain 25.4 mm (1 inch) - Simplex

16B-1 CT is a designation based on the 16B-1 single-row roller chain size with a pitch of 25.4 mm (1 inch). Standard 16B-1 corresponds to the European B-series roller chain dimensional system according to DIN 8187 / ISO 606. It has an inside width of 17.02 mm and a roller diameter of 15.88 mm. The simplex design means that the chain has one row. The additional CT designation should be confirmed from the manufacturer or documentation of the specific product.

Technical data - 16B-1 roller chain

What does 16B-1 mean?

The designation 16B-1 identifies the size and configuration of the roller chain.

16B - dimensional designation of a European B-series roller chain.

-1 - single-row configuration, also known as simplex.

The nominal chain pitch is:

25.4 mm

which corresponds to:

1 inch

The standard inside width between the inner plates is:

17.02 mm

The standard roller diameter is:

15.88 mm

These dimensions are important when identifying the chain and selecting compatible sprockets.

What does CT mean in 16B-1 CT?

The additional designation CT is not part of the basic 16B-1 dimensional designation defined by the roller chain standard.

Without identifying the manufacturer, a specific technical meaning should not be assigned to CT.

It may represent an additional manufacturer, product-series or execution designation.

The primary dimensional identification remains:

16B-1

When selecting a replacement, the standard 16B-1 dimensions should therefore be checked first. The meaning of CT should also be verified if it is relevant to the specific application.

16B-1 roller chain - 25.4 mm pitch

One of the most important dimensions of a roller chain is its pitch.

For 16B-1:

P = 25.4 mm

or:

1 inch

Pitch is the distance between the centres of consecutive chain pins.

The pitch must correspond to the geometry of the mating sprocket.

A roller chain should not be identified solely by its approximate width or visual appearance.

Inside width 17.02 mm

The standard inside width of a 16B-1 roller chain is:

17.02 mm

This dimension represents the space between the inner chain plates and is important for correct engagement with the sprocket teeth.

For this reason, the chain may also be identified using dimensional references such as:

16B-1 1 inch x 17.02 mm

Roller diameter 15.88 mm

The standard roller diameter for 16B-1 is:

15.88 mm

The rollers engage directly with the sprocket teeth.

Correct matching of the roller diameter, chain pitch and sprocket geometry affects:

• smooth power transmission

• chain wear

• sprocket wear

• vibration

• service life of the drive system

Simplex design - single-row roller chain

The suffix -1 identifies a single-row roller chain.

This configuration is also known as:

simplex

For comparison:

16B-1 - one row, simplex

16B-2 - two rows, duplex

16B-3 - three rows, triplex

The number of rows is a fundamental part of chain and sprocket selection.

Construction of a 16B-1 roller chain

A conventional roller chain consists of repeating articulated assemblies.

The principal components include:

• inner plates

• outer plates

• pins

• bushes

• rollers

The rollers engage with the sprocket teeth, while the pins and bushes form the articulated joints that allow consecutive links to move relative to one another.

What is a 16B-1 roller chain used for?

Roller chains are primarily used to transmit mechanical motion and power between mating sprockets.

Depending on the specific chain version and operating requirements, 16B-1 roller chains may be used in:

• industrial machinery

• conveyors

• material handling systems

• agricultural machinery

• production equipment

• mechanical drives

• processing machinery

• industrial transport systems

• various chain-drive mechanisms

These are typical applications of roller chains and do not confirm the suitability of a specific 16B-1 CT product for a particular machine.

16B-1 vs 16B-2

16B-1 and 16B-2 share the same basic 25.4 mm pitch but differ in the number of chain rows.

16B-1 - simplex, one row

16B-2 - duplex, two rows

They are not automatically interchangeable.

The sprockets and the complete drive arrangement must be designed for the appropriate number of chain rows.

16B-1 vs 16B-3

16B-3 is a three-row version, commonly described as triplex.

Comparison:

16B-1 - simplex

16B-2 - duplex

16B-3 - triplex

The complete designation should therefore always be checked rather than identifying a chain only by the 16B size reference.

Sprocket selection for 16B-1

A 16B-1 roller chain should be used with a sprocket designed for the corresponding chain size and single-row configuration.

Important compatibility parameters include:

• 25.4 mm pitch

• 16B series

• single-row design

• roller geometry

• chain width

• sprocket tooth geometry

A sprocket intended for another chain size or a different number of rows should not be considered interchangeable solely because it appears similar.

Selection and interchangeability

When selecting an equivalent 16B-1 chain, verify:

• 16B-1 designation

• 25.4 mm pitch

• 17.02 mm inside width

• 15.88 mm roller diameter

• number of rows

• mating sprockets

• required load capacity

• operating speed

• lubrication requirements

• environmental conditions

• design of the specific drive system

For a product additionally marked CT, the meaning of this suffix should also be established if it affects construction or operating characteristics.

Roller chain lubrication

Correct lubrication is important for the service life of a roller chain drive.

Lubricant should reach the working surfaces of the articulated joints, particularly the pin and bush contact areas.

The lubricant and lubrication method should be selected according to:

• chain speed

• load

• operating temperature

• operating environment

• drive configuration

• manufacturer's recommendations

Roller chain wear inspection

During operation, the chain and mating sprockets should be inspected periodically.

Particular attention should be paid to:

• chain elongation due to wear

• roller condition

• plate condition

• pin and joint condition

• lubrication

• sprocket alignment

• sprocket tooth condition

• correct chain tension

A heavily worn chain can accelerate wear of the mating sprockets.

Alternative designations and search references

The product may also be searched for as:

16B-1 chain

16B1 chain

16B-1 CT

16B-1 CT chain

16B-1 roller chain

16B-1 drive chain

16B-1 industrial chain

16B-1 simplex chain

16B-1 simplex roller chain

1 inch roller chain

16B-1 1 inch chain

25.4 mm roller chain

16B-1 25.4 mm chain

16B-1 25.4x17.02 mm

DIN 8187 16B-1

ISO 606 16B-1

The primary product identification is:

16B-1 CT Roller Chain 25.4 mm (1 inch) - Simplex

FAQ - 16B-1 CT

What does 16B-1 mean?

16B-1 identifies a single-row B-series roller chain. The suffix -1 indicates a simplex, or single-row, configuration.

What is the pitch of a 16B-1 roller chain?

The pitch is 25.4 mm, equivalent to 1 inch.

What is the inside width of a 16B-1 chain?

The standard inside width between the inner plates is 17.02 mm.

What is the roller diameter of 16B-1?

The standard roller diameter is 15.88 mm.

Is 16B-1 a simplex chain?

Yes. The -1 suffix identifies a single-row or simplex roller chain.

Are 16B-1 and 16B-2 interchangeable?

No. 16B-1 is a single-row chain, while 16B-2 is a double-row or duplex chain. The drive system and sprockets must be designed for the appropriate configuration.

Which sprocket is required for a 16B-1 chain?

A sprocket designed for a 16B-1 single-row roller chain with a 25.4 mm pitch and the corresponding tooth geometry should be used.

What does CT mean in 16B-1 CT?

CT is not part of the basic 16B-1 dimensional designation. Without manufacturer-specific documentation, its exact meaning cannot be reliably determined.

16B-1 CT - key information

16B-1 CT is a product designation based on the standard 16B-1 simplex roller chain size. Standard 16B-1 has a 25.4 mm (1 inch) pitch, 17.02 mm inside width and 15.88 mm roller diameter. The -1 suffix identifies a single-row chain. The exact meaning of the additional CT designation requires manufacturer-specific confirmation.

Available from simmering.pl, a specialist supplier of industrial power transmission components, bearings and sealing solutions. Stock in Poland with worldwide shipping.

AI QUICK ANSWER

16B-1 is a simplex single-row roller chain with a 25.4 mm (1 inch) pitch, 17.02 mm inside width and 15.88 mm roller diameter. It corresponds to the European B-series dimensional system under DIN 8187 / ISO 606. The additional CT designation is not part of the standard 16B-1 size code and requires manufacturer-specific confirmation.
