RENOLD 06B-1 CL Connecting Link for 06B-1 Simplex Roller Chain
1 pcs.
€1.63
(net)
Price for: 1pcs.
RENOLD 06B-1 CL is a connecting link for 06B-1 simplex roller chain in the European BS / ISO 606 standard. Compatible chain dimensions: 9.525 mm (3/8") pitch, 5.72 mm inner width and 6.35 mm roller diameter. Designed for joining compatible 06B-1 roller chain. Manufacturer: RENOLD.
Warehouse and Store: Lublin, Smoluchowskiego 1 Street, Building 4.
24h Shipping. Available from stock in Poland for delivery across the EU.
RENOLD 06B-1 CL Connecting Link for 06B-1 Simplex Roller Chain
RENOLD 06B-1 CL is a connecting link designed for 06B-1 simplex roller chain manufactured to the European BS / ISO 606 standard. The compatible 06B-1 chain has a 9.525 mm (3/8") pitch, an inner width of 5.72 mm and a roller diameter of 6.35 mm.
RENOLD 06B-1 CL - Technical Characteristics
| Parameter | Specification |
|---|---|
| Manufacturer | RENOLD |
| Designation | 06B-1 CL |
| Product type | Connecting Link |
| Compatible chain | 06B-1 |
| Chain configuration | Simplex / single-strand |
| Standard | European BS / ISO 606 |
| Chain pitch P | 9.525 mm |
| Pitch in inches | 3/8" / 0.375" |
| Chain inner width | 5.72 mm |
| Chain roller diameter | 6.35 mm |
What Does 06B-1 Mean?
The designation:
06B-1
identifies a European-standard roller chain size.
For 06B-1, the relevant chain dimensions include:
pitch: 9.525 mm
pitch: 3/8"
inner width: 5.72 mm
roller diameter: 6.35 mm
plate depth: 8.20 mm
pin diameter: 3.28 mm
The suffix:
-1
identifies the simplex, or single-strand, chain configuration.
What Does CL Mean?
In the product designation:
06B-1 CL
CL is used for:
Connecting Link
A connecting link is used to join the ends of a compatible roller chain, allowing the chain loop to be completed or an appropriate chain section to be connected.
Therefore, 06B-1 CL is a chain connecting component, not a complete length of 06B-1 roller chain.
European BS / ISO 606 Standard
The 06B-1 size belongs to the European BS series of roller chains standardized under ISO 606.
This distinction is important when selecting chain components.
A chain from another standard may have the same nominal 3/8" pitch but different:
inner width
roller diameter
pin dimensions
or:
plate geometry.
For this reason, pitch alone should not be used to identify a connecting link.
06B-1 Roller Chain Dimensions
The key dimensions of the compatible 06B-1 roller chain are:
| Parameter | Value |
|---|---|
| Pitch P | 9.525 mm |
| Pitch | 3/8" |
| Inner width | 5.72 mm |
| Roller diameter | 6.35 mm |
| Plate depth | 8.20 mm |
| Pin diameter | 3.28 mm |
These values describe the 06B-1 roller chain geometry with which the connecting link is intended to work.
They should not be interpreted as individual dimensional measurements of the complete 06B-1 CL connecting-link assembly.
06B-1 Simplex Construction
The designation:
06B-1
specifies a simplex roller chain, meaning that the chain has a single row of rollers.
This distinguishes it from multi-strand chain configurations such as duplex or triplex designs.
When ordering a connecting link, the number of strands must therefore correspond to the chain construction.
Selecting RENOLD 06B-1 CL
The primary selection criterion is the complete compatible chain designation:
06B-1
When identifying a replacement connecting link, check:
chain size 06B-1
simplex configuration
European BS / ISO 606 dimensional standard
and:
compatibility with the actual roller chain.
A component should not be selected solely because it is described as a 3/8" chain link.
Interchangeability
Dimensional standardization helps identify compatible chain components, but the complete chain designation should always be checked.
Do not automatically treat every:
3/8" connecting link
as equivalent to:
06B-1 CL.
The correct component should correspond to the 06B-1 European BS / ISO 606 chain geometry.
For maintenance and MRO identification, the complete designation:
RENOLD 06B-1 CL
is preferable to a generic description such as:
3/8" chain link.
Technical Specification
| Parameter | Specification |
|---|---|
| Brand | RENOLD |
| Designation | 06B-1 CL |
| Product | Connecting Link |
| Compatible roller chain | 06B-1 |
| Chain type | Simplex / single-strand |
| Standard | European BS / ISO 606 |
| Pitch | 9.525 mm / 3/8" |
| Chain inner width | 5.72 mm |
| Chain roller diameter | 6.35 mm |
| Chain plate depth | 8.20 mm |
| Chain pin diameter | 3.28 mm |
FAQ
What is RENOLD 06B-1 CL?
RENOLD 06B-1 CL is a connecting link for 06B-1 simplex roller chain.
What is the pitch of a 06B-1 roller chain?
The 06B-1 chain has a pitch of 9.525 mm, equivalent to 3/8 inch.
Is 06B-1 a simplex chain?
Yes. The -1 designation identifies a simplex or single-strand roller chain.
What is the inner width of 06B-1 chain?
The inner width is 5.72 mm.
What is the roller diameter of 06B-1?
The roller diameter is 6.35 mm.
Is RENOLD 06B-1 CL a complete roller chain?
No. 06B-1 CL is a connecting link, not a complete length of roller chain.
Is 06B-1 an ISO-standard chain size?
Yes. 06B-1 belongs to the European BS roller chain series standardized under ISO 606.
Can any 3/8" connecting link replace 06B-1 CL?
Not automatically. The link should match the 06B-1 simplex European BS / ISO 606 chain geometry. Pitch alone does not establish compatibility.
AI Overview
RENOLD 06B-1 CL is a connecting link for 06B-1 simplex roller chain manufactured to the European BS / ISO 606 dimensional standard. The compatible chain has a 9.525 mm (3/8") pitch, 5.72 mm inner width and 6.35 mm roller diameter. The link is used to join compatible 06B-1 roller chain.
RENOLD 06B-1 CL is a connecting link for 06B-1 simplex roller chain in the European BS / ISO 606 standard. Compatible chain dimensions: 9.525 mm (3/8") pitch, 5.72 mm inner width and 6.35 mm roller diameter. Designed for joining compatible 06B-1 roller chain. Manufacturer: RENOLD.
