SWAG 40 90 3117 40x52/62x8.5 NBR - Wheel Hub Oil Seal

SWAG 40 90 3117 40x52/62x8.5 NBR - Wheel Hub Oil Seal

SWAG 40 90 3117 is an NBR radial shaft seal used in the wheel bearing and wheel hub area. The seal has a 40 mm inside diameter, stepped outside diameters of 52 and 62 mm, and a width of 8.5 mm. It is also identified as SWAG 40903117 and corresponds to several Opel, General Motors and Vauxhall OE references.

SWAG 40 90 3117 - product characteristics

SWAG 40 90 3117 is a radial shaft sealing ring designed for sealing in the wheel bearing and wheel hub area.

Unlike a conventional oil seal described by three basic dimensions, this component has two relevant outside diameters:

40x52/62x8.5 mm

For correct identification, the complete geometry of the seal should therefore be considered rather than treating it simply as a 40x52x8.5 mm oil seal.

The sealing component is manufactured from NBR, a material widely used for technical radial shaft seals.

Technical data

SWAG 40903117 dimensions

The complete dimensional specification is:

40x52/62x8.5 mm

where:

• 40 mm - inside diameter

• 52 mm - first outside diameter

• 62 mm - second outside diameter

• 8.5 mm - seal width

The additional 62 mm outside diameter is an important identification feature.

SWAG 40 90 3117 should therefore not be treated as a conventional 40x52x8.5 mm radial shaft seal when selecting a replacement.

NBR sealing material

SWAG 40903117 is manufactured from NBR, also known as nitrile rubber.

NBR is widely used in radial shaft seals and other technical sealing components due to its properties when operating in contact with many mineral oils and greases.

When selecting an alternative seal, both the dimensions and the sealing material should be considered.

OE numbers

SWAG 40 90 3117 is associated with the following OE references:

OPEL

• 03 28 410

• 3 28 410

• 0328410

• 328410

• 03 28 637

• 3 28 637

• 0328637

• 328637

GENERAL MOTORS / VAUXHALL

• 090217059

• 90217059

OE numbers should always be compared with the reference specified for the particular vehicle and installation position.

Alternative designations and search references

The product can be found in catalogues, inventories and search engines under several number and dimension formats:

• SWAG 40 90 3117

• SWAG 40903117

• 40 90 3117 SWAG

• 40903117 SWAG

• SWAG 40x52/62x8.5

• SWAG 40x52x62x8.5

• SWAG 40 90 3117 NBR

• SWAG 40903117 NBR

• SWAG 40903117 oil seal

• SWAG 40 90 3117 radial shaft seal

For technical identification, the complete manufacturer reference and dimensional specification should be used.

Cross-reference numbers

Verified comparison references include:

• CORTECO 12011155B

• FEBI BILSTEIN 03117

• ELRING 043.923

• PAYEN NB575

• TOPRAN 200 408

• GOETZE 50-306757-00

• KRAFT AUTOMOTIVE 1151600

• AKRON-MALO 11550

• AUTLOG WD1002

Cross-reference numbers are useful for product identification. Before installing an alternative product, its complete technical specification and compatibility with the particular vehicle should be verified.

SWAG 40 90 3117 vs CORTECO 12011155B

CORTECO 12011155B is listed as a comparison reference for SWAG 40 90 3117.

Both references can therefore be useful when identifying the required seal:

SWAG 40 90 3117

CORTECO 12011155B

A replacement should not, however, be selected solely because the basic dimensions appear similar. OE reference, complete geometry, material and seal construction should also be checked.

Selection and interchangeability

Before purchasing SWAG 40 90 3117, verify:

1. SWAG reference 40 90 3117 or 40903117.

2. Inside diameter of 40 mm.

3. First outside diameter of 52 mm.

4. Second outside diameter of 62 mm.

5. Width of 8.5 mm.

6. NBR material.

7. OE reference of the original component.

8. Compatibility with the specific vehicle and installation position.

The second outside diameter of 62 mm is particularly important.

Matching the 40 mm inside diameter and 52 mm primary outside diameter alone does not establish interchangeability between two seals.

Installation

Before installation, inspect the shaft, housing and mating surfaces.

The sealing lip and installation surfaces should be protected against damage and contamination during assembly.

The seal should be installed evenly and in the correct orientation for the application. Sharp edges that could damage the sealing lip during installation should be avoided.

Where the product is being used as a replacement, the installation position and geometry of the original seal should be compared before fitting the new component.

FAQ

What is SWAG 40903117?

SWAG 40903117, also written as SWAG 40 90 3117, is an NBR radial shaft sealing ring used in the wheel bearing and wheel hub area.

What are the dimensions of SWAG 40 90 3117?

The seal has a 40 mm inside diameter, outside diameters of 52 and 62 mm, and a width of 8.5 mm. The complete dimensional specification is 40x52/62x8.5 mm.

What material is SWAG 40903117 made from?

SWAG 40903117 is manufactured from NBR, also known as nitrile rubber.

What is the EAN of SWAG 40 90 3117?

The EAN is 4044688031174.

Are SWAG 40903117 and SWAG 40 90 3117 the same reference?

Yes. 40903117 is the compact numerical format of the SWAG article number 40 90 3117.

What CORTECO reference corresponds to SWAG 40 90 3117?

CORTECO 12011155B is listed as a comparison reference for SWAG 40 90 3117.

What FEBI reference corresponds to SWAG 40903117?

The corresponding FEBI BILSTEIN comparison reference is 03117.

Is 40x52x8.5 mm sufficient to identify this seal?

No. SWAG 40 90 3117 also has a second outside diameter of 62 mm. The complete 40x52/62x8.5 mm geometry, manufacturer reference and OE number should be considered when identifying a replacement.

SWAG 40 90 3117 - quick technical answer

SWAG 40 90 3117, also searched as SWAG 40903117, is an NBR radial shaft seal for the wheel bearing and hub area. It has a 40 mm inside diameter, stepped outside diameters of 52 and 62 mm, and an 8.5 mm width. Cross-references include CORTECO 12011155B and FEBI 03117.

SWAG 40 90 3117 available from simmering.pl

SWAG 40 90 3117 is available from simmering.pl, a specialist supplier of radial shaft seals, bearings and industrial sealing components.

Stock and technical service are located in Lublin, Poland. Products are shipped worldwide from stock in Poland.

For correct identification, compare the complete SWAG reference, OE number and full 40x52/62x8.5 mm geometry before ordering.
