SWAG 30 90 8253 50x65x8 NBR - Wheel Bearing Seal

SWAG 30 90 8253 50x65x8 NBR - Wheel Bearing Seal

SWAG 30 90 8253, also searched as SWAG 30908253, is an NBR radial shaft seal used in the wheel bearing and wheel hub assembly. It has dimensions of 50x65x8 mm, with a 50 mm inside diameter, 65 mm outside diameter and 8 mm width. Catalogue data specifies installation on the rear axle. A key VAG OE reference is 211 405 641 D.

SWAG 30 90 8253 - product characteristics

SWAG 30 90 8253 is a sealing component used in the wheel bearing and wheel hub area.

Key identification data:

• manufacturer: SWAG

• part number: 30 90 8253

• compact part number: 30908253

• product type: wheel bearing seal / radial shaft seal

• inside diameter: 50 mm

• outside diameter: 65 mm

• width: 8 mm

• material: NBR

• installation position: rear axle

• quantity specified in catalogues: 2 pcs

• VAG OE reference: 211 405 641 D

Technical data

SWAG 30 90 8253 dimensions

The exact dimensions are:

50x65x8 mm

where:

• 50 mm - inside diameter

• 65 mm - outside diameter

• 8 mm - width

The dimensions should be considered together with the complete SWAG part number and intended installation.

Finding another 50x65x8 mm radial shaft seal does not automatically confirm interchangeability with SWAG 30 90 8253.

What does SWAG 30 90 8253 mean?

SWAG is a parts brand belonging to bilstein group.

30 90 8253 is the catalogue reference identifying this specific product.

In online stores, ERP systems and search engines, the number is also frequently written without spaces as:

30908253

Therefore:

SWAG 30 90 8253

and

SWAG 30908253

are search formats referring to the same SWAG reference.

NBR material

SWAG 30 90 8253 is manufactured from NBR, also known as nitrile rubber.

NBR is widely used in technical sealing applications, particularly in components operating in contact with mineral oils and greases.

The material should be considered when comparing SWAG 30908253 with other 50x65x8 mm seals.

Wheel bearing and wheel hub seal

SWAG 30 90 8253 is catalogued as a radial shaft sealing component associated with the wheel bearing and wheel hub assembly.

Its function is to seal the bearing area and help protect the assembly against contamination while retaining the required lubricant within the protected area.

Catalogue data specifies:

installation position: rear axle

and:

required quantity: 2 pcs

Exact compatibility should always be checked using the OE number and the specific vehicle configuration.

VAG OE 211 405 641 D

One of the most important OE references associated with SWAG 30 90 8253 is:

211 405 641 D

This reference is found in catalogues under VAG brands including:

• VW 211 405 641 D

• AUDI 211 405 641 D

• SEAT 211 405 641 D

• SKODA 211 405 641 D

The number may also be written without spaces:

211405641D

The OE number is particularly useful when identifying the correct seal or searching cross-reference databases.

Confirmed cross-reference numbers

Cross-reference numbers associated with SWAG 30 90 8253 include:

• FEBI BILSTEIN 08253

• CORTECO 12010966

• CORTECO 12010966B

• ELRING 412.104

• AJUSA 15024800

• GOETZE 50-304592-00

• PAYEN NF 345

• MEC-DIESEL 521439

• ZF 0634 302 703

Additional OE references appearing in cross-reference catalogues include:

• VW 211 405 641 D

• AUDI 211 405 641 D

• SEAT 211 405 641 D

• SKODA 211 405 641 D

• FIAT 29740892

• FIAT 4132584

• FIAT 974089

• DEUTZ 0111 7822

• DEUTZ 0116 0682

• IVECO 0116 0682

• MASSEY FERGUSON 3069 712 M8

• SAAB 70 79 387

• RENAULT TRUCKS 09 48 350 654

• HANOMAG 0997 190 009

Cross-reference numbers are useful for identification, but the complete specification and application should be verified before fitting an alternative product.

SWAG 30 90 8253 vs FEBI BILSTEIN 08253

An important catalogue cross-reference for SWAG 30 90 8253 is:

FEBI BILSTEIN 08253

For FEBI 08253, catalogue data specifies:

• inside diameter 50 mm

• outside diameter 65 mm

• width 8 mm

• NBR material

• rear axle installation

• OE VW 211 405 641 D

SWAG 30 90 8253 and FEBI BILSTEIN 08253 are linked as cross-references in parts catalogues.

SWAG 30 90 8253 vs CORTECO 12010966B

Another important comparison reference is:

CORTECO 12010966B

CORTECO 12010966B is catalogued as a wheel hub sealing component and appears in cross-reference data for the same OE number group.

The reference:

CORTECO 12010966

may also be encountered in older catalogue data.

When ordering a replacement, the current manufacturer reference and complete technical specification should be verified.

SWAG 30 90 8253 vs ELRING 412.104

Another confirmed cross-reference is:

ELRING 412.104

ELRING 412.104 appears in cross-reference catalogues with VW OE 211 405 641 D and SWAG 30 90 8253.

The following numbers are therefore particularly useful when identifying this seal:

• SWAG 30 90 8253

• SWAG 30908253

• FEBI BILSTEIN 08253

• CORTECO 12010966B

• ELRING 412.104

• VW 211 405 641 D

Confirmed VW applications

Catalogue data for references associated with SWAG 30 90 8253 includes applications in selected older VW vehicles.

These include selected versions of:

VW Caddy I (14)

and cross-reference catalogues for the associated ELRING and CORTECO references also list:

VW Transporter T2

Exact compatibility depends on vehicle version, production year, hub assembly and OE specification.

The OE reference 211 405 641 D should therefore be checked before ordering for a specific vehicle.

Alternative designations and search references

The product may be searched under several formats:

• SWAG 30 90 8253

• SWAG 30908253

• 30 90 8253 SWAG

• 30908253 SWAG

• SWAG 30 90 8253 50x65x8

• SWAG 30908253 50x65x8

• SWAG 50x65x8

• SWAG 30 90 8253 NBR

• SWAG 30908253 NBR

• SWAG wheel bearing seal

• SWAG wheel hub seal

• SWAG radial shaft seal 30908253

• VW 211 405 641 D

• VW 211405641D

• FEBI 08253

• CORTECO 12010966B

• ELRING 412.104

The compact 30908253 format is particularly important for search because many databases and users enter SWAG references without spaces.

Selection and interchangeability

Before purchasing SWAG 30 90 8253, verify:

1. SWAG reference 30 90 8253 or compact notation 30908253.

2. Dimensions 50x65x8 mm.

3. NBR material.

4. Installation position.

5. OE reference, particularly VW 211 405 641 D.

6. Reference of the removed component.

7. Compatibility with the specific vehicle and wheel hub assembly.

A replacement should not be selected solely because it has the same 50x65x8 mm dimensions.

Installation

Before installation, thoroughly clean the seal seat and inspect all mating surfaces.

Check:

• mating surface condition

• absence of burrs and sharp edges

• correct seal orientation

• correct seating in the housing

• protection of the sealing lip against damage

The seal should be installed axially and evenly without tilting or deformation.

Correct installation is particularly important for protecting the wheel bearing assembly from contamination and maintaining effective sealing.

FAQ

What are the dimensions of SWAG 30908253?

SWAG 30908253, also designated SWAG 30 90 8253, has dimensions of 50x65x8 mm: 50 mm inside diameter, 65 mm outside diameter and 8 mm width.

What material is SWAG 30 90 8253 made from?

The seal is manufactured from NBR, also known as nitrile rubber.

Are SWAG 30908253 and SWAG 30 90 8253 the same product?

Yes. SWAG 30 90 8253 is the spaced catalogue notation, while 30908253 is the commonly used compact form of the same reference.

Where is SWAG 30 90 8253 installed?

Catalogue data specifies installation in the wheel bearing or wheel hub area on the rear axle.

Which VW OE number corresponds to SWAG 30 90 8253?

A key VAG OE reference associated with this product is 211 405 641 D.

Is FEBI BILSTEIN 08253 a cross-reference for SWAG 30 90 8253?

Yes. FEBI BILSTEIN 08253 is listed as a catalogue cross-reference for SWAG 30 90 8253.

Is CORTECO 12010966B a cross-reference for SWAG 30 90 8253?

Yes. CORTECO 12010966B appears in cross-reference data for SWAG 30 90 8253 and OE VW 211 405 641 D.

Can any 50x65x8 mm oil seal replace SWAG 30908253?

No. Interchangeability should not be determined from dimensions alone. The material, construction, installation position and relevant OE reference should also be verified.

SWAG 30 90 8253 - quick technical answer

SWAG 30 90 8253, also searched as 30908253, is an NBR wheel bearing and wheel hub seal with dimensions 50x65x8 mm for rear axle installation. A key OE reference is VW 211 405 641 D. Confirmed cross-references include FEBI BILSTEIN 08253, CORTECO 12010966B and ELRING 412.104.

SWAG 30 90 8253 available from simmering.pl

SWAG 30 90 8253 50x65x8 NBR is available from simmering.pl, a specialist supplier of radial shaft seals, wheel bearing seals, technical sealing solutions and bearings for industrial and technical customers.

Stock and technical service are located in Lublin, Poland. Products are shipped worldwide from stock in Poland.

For accurate identification, specify both SWAG 30 90 8253 and the compact 30908253 reference together with dimensions 50x65x8 mm and, where applicable, OE VW 211 405 641 D.
