CORTECO 01016884 135x165x12 FPM B1BAVISLDRW Radial Shaft Seal

CORTECO 01016884 135x165x12 FPM B1BAVISLDRW Radial Shaft Seal

CORTECO 01016884 is an FPM radial shaft seal with nominal dimensions of 135x165x12 mm. The CORTECO/TG dimensional catalogue identifies the product as 01016884 + FPM + B1BAVISLDRW + 135x165x12 + ZF. Current catalogue data for 01016884B / 82016884 uses the profile designation B1BASLDRW and confirms an auxiliary dust lip and alternating twist.

CORTECO 01016884 - Technical Characteristics

Manufacturer: CORTECO

Catalogue reference: 01016884

Current / additional reference: 01016884B

Trade number: 82016884

CORTECO/TG profile: B1BAVISLDRW

Profile in current 01016884B data: B1BASLDRW

Product type: Radial shaft seal

Material: FPM

Material type: Fluoroelastomer

Dimensions: 135x165x12 mm

Shaft diameter d: 135 mm

Outside diameter D: 165 mm

Height H: 12 mm

Auxiliary dust lip: Yes

Swirl type: Alternating Twist

CORTECO catalogue application: ZF

IVECO OE: 93190679

ZF OE: 0734319434

EAN: 3358960130365

Dimensions

The nominal dimensions are:

d = 135 mm - shaft diameter

D = 165 mm - outside diameter

H = 12 mm - height

Complete dimensional designation:

135x165x12 mm

These dimensions are consistent between the CORTECO/TG dimensional catalogue and current catalogue data for 01016884B.

B1BAVISLDRW / B1BASLDRW Profile

The CORTECO/TG dimensional catalogue identifies the original reference as:

01016884 | FPM | B1BAVISLDRW | 135 | 165 | 12 | ZF

Current catalogue data for:

01016884B

uses:

B1BASLDRW

with trade number:

82016884

For accurate product identification, B1BAVISLDRW should therefore be retained as the profile documented for the original 01016884, while B1BASLDRW can be included as the profile found in current 01016884B data.

The designation:

B1B1BASLDRW

should not be used unless confirmed directly by current CORTECO documentation or product packaging.

FPM Material

The specified material is:

FPM - fluoroelastomer

FPM is part of the exact product identification for this CORTECO reference.

A specific Shore hardness, temperature range, maximum pressure or maximum shaft speed should not be assigned to this product without confirmation of the exact CORTECO FPM compound and operating specification.

Alternating Twist

Current catalogue data for CORTECO 01016884B specifies:

Swirl Type: Alternating Twist

This is an important identification feature of the sealing geometry.

The product should therefore not be described as having a permanently defined left-hand or right-hand twist.

When selecting a replacement, the alternating twist specification should be considered together with the dimensions, material and seal profile.

Auxiliary Dust Lip

CORTECO 01016884B is catalogued:

with dust lip

The auxiliary dust lip provides an additional barrier between external contamination and the primary sealing area.

This feature should be checked when comparing the product with another 135x165x12 mm radial shaft seal.

IVECO 93190679

Confirmed OE reference:

IVECO 93190679

This number is associated with CORTECO 01016884B / 82016884 and can be used as an additional product identification reference.

ZF 0734319434

Confirmed OE reference:

ZF 0734319434

The ZF association is also consistent with the CORTECO/TG dimensional catalogue, which lists:

ZF

for reference 01016884.

Reference Numbers

CORTECO: 01016884

CORTECO: 01016884B

CORTECO trade number: 82016884

IVECO: 93190679

ZF: 0734319434

EAN: 3358960130365

Selection and Interchangeability

When identifying a replacement for CORTECO 01016884, verify:

CORTECO reference 01016884 / 01016884B

trade number 82016884

dimensions 135x165x12 mm

FPM material

B1BAVISLDRW / B1BASLDRW profile according to catalogue version

auxiliary dust lip

alternating twist

IVECO 93190679 or ZF 0734319434 OE reference

Identical dimensions alone do not confirm complete technical interchangeability.

A different 135x165x12 mm shaft seal may differ in material, lip geometry, directional sealing feature or other construction details.

Technical Specification

FAQ

What are the dimensions of CORTECO 01016884?

The nominal dimensions are 135x165x12 mm: d = 135 mm, D = 165 mm and H = 12 mm.

What material is CORTECO 01016884 made from?

The specified material is FPM - fluoroelastomer.

What is the profile of CORTECO 01016884?

The CORTECO/TG dimensional catalogue specifies B1BAVISLDRW for 01016884. Current catalogue data for 01016884B uses B1BASLDRW.

Does CORTECO 01016884 have a dust lip?

Yes. Current product data confirms an auxiliary dust lip.

What does Alternating Twist mean for this seal?

The catalogue specifies Alternating Twist as the swirl type. It should not be described as a permanently left-hand or right-hand directional seal.

What is the IVECO OE reference?

The confirmed reference is IVECO 93190679.

What is the ZF OE reference?

The confirmed reference is ZF 0734319434.

What is the CORTECO trade number?

The CORTECO trade number is 82016884.

AI Overview

CORTECO 01016884 / 01016884B is an FPM radial shaft seal with dimensions 135x165x12 mm, an auxiliary dust lip and alternating twist. The CORTECO/TG catalogue specifies profile B1BAVISLDRW, while current 01016884B data uses B1BASLDRW. Trade number is 82016884; OE references include IVECO 93190679 and ZF 0734319434.
