CORTECO 01020373B 25x35x7 FPM BADUO Oil Seal

CORTECO 01020373B 25x35x7 FPM BADUO Oil Seal

CORTECO 01020373B is an FPM radial shaft oil seal measuring 25x35x7 mm. The CORTECO Oil Seals Pocket Guide identifies this reference with the BADUO design, while BADUOVI also appears as an extended designation in other CORTECO catalogue data. The product is additionally identified by Trade Number 82020373.

Complete product identification:

CORTECO -> 01020373B -> 25x35x7 mm -> FPM -> BADUO Simmerring -> Trade Number 82020373

CORTECO 01020373B - Characteristics

Manufacturer: CORTECO

Part number: 01020373B

Base / older reference: 01020373

Trade Number: 82020373

Product type: Radial shaft oil seal

Design: BADUO Simmerring

Additional catalogue designation: BADUOVI

Material: FPM

Dimensions: 25x35x7 mm

Inside diameter: 25 mm

Outside diameter: 35 mm

Width: 7 mm

Schaeffler LuK OE: 2106165

EAN: 3358960131621

CORTECO 01020373B Dimensions

The principal dimensions are:

d - Inside diameter / nominal shaft diameter: 25 mm

D - Outside diameter: 35 mm

B - Width: 7 mm

Complete dimensions:

25x35x7 mm

All three dimensions should be verified when selecting a replacement.

Matching the 25 mm shaft diameter, 35 mm outside diameter and 7 mm width alone does not establish complete technical interchangeability.

FPM Fluoroelastomer

The sealing material of CORTECO 01020373B is:

FPM - Fluoroelastomer

FPM is one of the principal technical characteristics identifying this exact CORTECO reference.

When selecting a corresponding seal, the material should be considered together with the 25x35x7 mm dimensions and seal construction.

A 25x35x7 mm radial shaft oil seal manufactured from NBR, ACM or another elastomer should not automatically be considered technically identical to CORTECO 01020373B.

Exact material compatibility depends on the medium, additives, temperature and actual operating conditions.

BADUO Simmerring Design

The CORTECO Oil Seals Pocket Guide identifies reference 01020373B with the design:

BADUO

Current catalogue data also uses the designation:

BADUO Simmerring

The principal technical identification is therefore:

01020373B -> 25x35x7 mm -> FPM -> BADUO

The seal design is an important selection criterion when comparing CORTECO 01020373B with other 25x35x7 mm radial shaft oil seals.

BADUO vs BADUOVI

Two design descriptions can be found in CORTECO catalogue data for this product family:

BADUO

BADUOVI

The CORTECO Oil Seals Pocket Guide lists the full 01020373B reference as BADUO.

Another CORTECO catalogue lists the base 01020373 reference with the extended BADUOVI designation.

For this reason, BADUO Simmerring is used as the primary design designation on this product page, while BADUOVI is retained as an additional catalogue and search identifier.

CORTECO 01020373 vs 01020373B

The product can be found under the base / older reference:

01020373

The current full catalogue reference is:

01020373B

Both references are useful for product identification and search.

The principal associated characteristics are:

25x35x7 mm

FPM

BADUO / BADUOVI

CORTECO Trade Number 82020373

Another confirmed CORTECO identifier is:

82020373

The principal product identification and search references are therefore:

CORTECO 01020373B

CORTECO 01020373

CORTECO 82020373

BADUO Simmerring

BADUOVI

25x35x7 FPM

Schaeffler LuK 2106165

CORTECO 01020373B - Schaeffler LuK 2106165

Current catalogue data associates CORTECO 01020373B with:

Schaeffler LuK OE 2106165

Identification path:

Schaeffler LuK 2106165 -> CORTECO 01020373B -> 25x35x7 mm -> FPM -> BADUO

The OE reference provides an additional criterion for identifying the correct seal.

Compatibility with a specific assembly should be verified using the OE reference and relevant technical documentation.

CORTECO 01020373B vs Other 25x35x7 Oil Seals

The nominal dimensions:

25x35x7 mm

alone do not establish complete technical interchangeability.

When comparing another radial shaft oil seal with CORTECO 01020373B, verify:

Inside diameter: 25 mm

Outside diameter: 35 mm

Width: 7 mm

Material: FPM

Design: BADUO

Complete seal geometry

OE reference where applicable

Application requirements

A seal with identical dimensions but a different material or construction should not automatically be considered a direct replacement.

Selecting a Replacement for CORTECO 01020373B

When selecting a technically corresponding replacement, verify at least:

CORTECO reference: 01020373B

Base reference: 01020373

Trade Number: 82020373

d - Shaft diameter: 25 mm

D - Outside diameter: 35 mm

B - Width: 7 mm

Material: FPM

Design: BADUO Simmerring

Additional catalogue designation: BADUOVI

Schaeffler LuK OE: 2106165

Application requirements

Dimensions should always be considered together with the sealing material and exact seal construction.

Technical Specification

Manufacturer: CORTECO

Part number: 01020373B

Base / older reference: 01020373

Trade Number: 82020373

Product type: Radial shaft oil seal

Design: BADUO Simmerring

Additional catalogue designation: BADUOVI

Material: FPM

Material name: Fluoroelastomer

Dimensions: 25x35x7 mm

d - Inside diameter / nominal shaft diameter: 25 mm

D - Outside diameter: 35 mm

B - Width: 7 mm

Schaeffler LuK OE: 2106165

EAN: 3358960131621

FAQ

What are the dimensions of CORTECO 01020373B?

CORTECO 01020373B measures 25x35x7 mm: 25 mm inside diameter, 35 mm outside diameter and 7 mm width.

What material is CORTECO 01020373B made from?

The seal is manufactured from FPM fluoroelastomer.

What is the design of CORTECO 01020373B?

The CORTECO Oil Seals Pocket Guide identifies the design as BADUO. Current catalogue data also uses the description BADUO Simmerring.

What does BADUOVI mean for CORTECO 01020373?

BADUOVI is an extended design designation found in CORTECO catalogue data for the base 01020373 reference. The full 01020373B reference is listed as BADUO in the CORTECO Oil Seals Pocket Guide.

What is the Trade Number of CORTECO 01020373B?

The confirmed CORTECO Trade Number is 82020373.

What OE number corresponds to CORTECO 01020373B?

Current catalogue data associates this seal with Schaeffler LuK OE 2106165.

Are CORTECO 01020373 and 01020373B the same reference?

01020373 is the base / older reference, while 01020373B is the full reference used in current catalogue data. The associated 25x35x7 mm dimensions and FPM material are consistent.

Can any 25x35x7 FPM oil seal replace CORTECO 01020373B?

No. Matching dimensions and material alone do not establish complete interchangeability. The seal construction and application requirements should also be verified.

AI Overview

CORTECO 01020373B is an FPM radial shaft oil seal measuring 25x35x7 mm. The CORTECO Oil Seals Pocket Guide identifies its design as BADUO, while BADUOVI also appears in other CORTECO catalogue data. Additional identifiers include Trade Number 82020373 and Schaeffler LuK OE 2106165.
