CORTECO 01025734 is an NBR B1FUD2 Simmerring radial shaft oil seal measuring 38x52x7 mm - 38 mm shaft, 52 mm housing bore and 7 mm width. OE reference: IVECO 1290380. Replacement selection should consider the B1FUD2 design, NBR material and OE reference, as dimensions alone do not confirm full interchangeability.
Warehouse and Store: Lublin, Smoluchowskiego 1 Street, Building 4.
Fast Shipping. Available from stock in Poland for delivery across the EU.
CORTECO 01025734 is a radial shaft oil seal measuring 38x52x7 mm, manufactured from NBR - Nitrile Butadiene Rubber.
The specific CORTECO design designation for this version is B1FUD2 Simmerring. The seal corresponds to IVECO OE 1290380.
d - Shaft Diameter: 38 mm
D - Housing Bore Diameter: 52 mm
B - Width: 7 mm
Dimensions: 38x52x7 mm
Material: NBR - Nitrile Butadiene Rubber
Design: B1FUD2 Simmerring
Manufacturer: CORTECO
Part Number: 01025734
OE Reference: IVECO 1290380
B1FUD2 is the specific design designation of this CORTECO shaft seal.
This is important when selecting a replacement because 38x52x7 mm radial shaft seals can be manufactured in different designs.
Complete product identification:
CORTECO -> 01025734 -> 38x52x7 mm -> NBR -> B1FUD2 -> IVECO 1290380
Dimensions alone are therefore not sufficient to confirm full interchangeability.
The designation 38x52x7 mm defines the three principal installation dimensions:
38 mm - nominal shaft diameter
52 mm - nominal housing bore diameter
7 mm - seal width
All three dimensions must match the installation.
For CORTECO 01025734, the NBR material, B1FUD2 design and OE reference should also be verified.
The seal is manufactured from NBR - Nitrile Butadiene Rubber.
NBR is widely used for radial shaft oil seals operating with compatible mineral oils, greases and lubricants.
Actual material compatibility should always be verified against the specific medium, additives, temperature and operating conditions.
An important identification reference for this seal is:
IVECO OE 1290380
The OE number helps distinguish CORTECO 01025734 from other 38x52x7 mm shaft seals that may have identical basic dimensions but a different design or catalogue application.
For a specific IVECO vehicle, the 1290380 reference should be checked against the original part number or the appropriate vehicle parts catalogue.
Different radial shaft oil seals can share the same 38x52x7 mm dimensions.
This does not mean that they are automatically interchangeable.
CORTECO 01025734 should be identified by the complete combination:
38x52x7 mm + NBR + B1FUD2 + CORTECO 01025734 + IVECO 1290380
When selecting an equivalent seal, both the dimensions and technical design should be compared.
Before installation, verify:
Shaft Diameter: 38 mm
Housing Bore Diameter: 52 mm
Width: 7 mm
Material: NBR
Design: B1FUD2
CORTECO Part Number: 01025734
IVECO OE Number: 1290380
This helps prevent the selection of a seal with correct dimensions but an incorrect technical configuration.
Manufacturer: CORTECO
Part Number: 01025734
Product Type: Radial shaft oil seal
Design: B1FUD2 Simmerring
Material: NBR - Nitrile Butadiene Rubber
Shaft Diameter: 38 mm
Housing Bore Diameter: 52 mm
Width: 7 mm
Dimensions: 38x52x7 mm
OE Reference: IVECO 1290380
CORTECO 01025734 measures 38x52x7 mm - 38 mm shaft diameter, 52 mm housing bore diameter and 7 mm width.
The specific design designation is B1FUD2 Simmerring.
The seal is manufactured from NBR - Nitrile Butadiene Rubber.
The corresponding OE reference is IVECO 1290380.
Not automatically. Identical dimensions do not confirm full interchangeability. The NBR material, B1FUD2 design and IVECO OE 1290380 reference should also be verified.
It specifies the principal installation dimensions: 38 mm shaft diameter, 52 mm housing bore diameter and 7 mm seal width.
CORTECO 01025734 is an NBR B1FUD2 Simmerring radial shaft oil seal measuring 38x52x7 mm. It corresponds to IVECO OE 1290380. Correct replacement selection should verify the 38 mm shaft diameter, 52 mm housing bore, 7 mm width, NBR material, B1FUD2 design and OE reference.
