CORTECO 01026331B 85x110x12 FPM B1BASLRSX67 Differential Shaft Oil Seal

CORTECO 01026331B 85x110x12 FPM B1BASLRSX67 Differential Shaft Oil Seal

CORTECO 01026331B is a differential shaft oil seal with exact dimensions of 85x110x12 mm. The sealing material is FPM - Fluoroelastomer Rubber, and the exact CORTECO design designation is B1BASLRSX67. The seal incorporates an additional dust lip and Left-hand Twist sealing geometry. The confirmed Renault Trucks OE reference is 5010319135.

CORTECO 01026331B - Technical Specification

Manufacturer: CORTECO

Full reference: 01026331B

Base reference: 01026331

Trade Number: 82026331

Product type: Differential shaft oil seal

Exact design designation: B1BASLRSX67

Material: FPM - Fluoroelastomer Rubber

Dimensions: 85x110x12 mm

Inside diameter d: 85 mm

Outside diameter D: 110 mm

Width B: 12 mm

Dust lip: Yes

Swirl Type: Left-hand Twist

Renault Trucks OE: 5010319135

EAN: 3358960283504

CORTECO 01026331B Dimensions

Inside diameter d: 85 mm

Outside diameter D: 110 mm

Width B: 12 mm

Complete dimensions: 85x110x12 mm

The first dimension, 85 mm, represents the nominal shaft diameter.

The second dimension, 110 mm, represents the nominal housing bore diameter.

The third dimension, 12 mm, represents the seal width.

All three dimensions should be verified together with the material, seal design and directional sealing geometry when identifying a replacement.

B1BASLRSX67 Oil Seal Design

Exact design designation: B1BASLRSX67

Manufacturer reference: 01026331B

Material: FPM

Dimensions: 85x110x12 mm

Dust lip: Yes

Swirl Type: Left-hand Twist

B1BASLRSX67 is the exact CORTECO design designation associated with reference 01026331B.

The complete design code is an important identification parameter when comparing this seal with other 85x110x12 mm radial shaft oil seals.

A seal with identical dimensions but a different profile should not automatically be considered technically equivalent.

Additional Dust Lip

CORTECO 01026331B incorporates an additional dust lip.

The primary sealing lip performs the main sealing function, while the auxiliary dust lip forms an additional barrier on the external side of the sealing area.

This additional lip helps limit the ingress of dust and external contamination toward the primary sealing zone.

The dust lip configuration should therefore be considered when selecting a replacement.

Left-hand Twist Sealing Geometry

Swirl Type: Left-hand Twist

CORTECO catalogue designation: LD

CORTECO 01026331B incorporates directional sealing geometry specified as Left-hand Twist.

This feature forms part of the complete B1BASLRSX67 design and should be considered together with the dimensions, FPM material and dust lip configuration.

A seal with the same dimensions but Right-hand Twist, Alternating Twist or non-directional geometry should not automatically be considered equivalent.

FPM Fluoroelastomer Rubber

Material: FPM

Full material name: Fluoroelastomer Rubber

FPM is the sealing material specified for CORTECO 01026331B.

The material should be considered together with the dimensions, B1BASLRSX67 design and Left-hand Twist geometry when selecting a replacement.

An 85x110x12 mm oil seal manufactured from NBR, ACM or another elastomer should not automatically be considered technically identical.

Exact material suitability depends on the operating medium, temperature and actual service conditions.

CORTECO 01026331B Differential Shaft Oil Seal

Catalogue product type: Differential shaft oil seal

Dimensions: 85x110x12 mm

Material: FPM

Design: B1BASLRSX67

Dust lip: Yes

Swirl Type: Left-hand Twist

Current catalogue data classify CORTECO 01026331B as a differential shaft oil seal.

The product is associated with Renault Trucks drivetrain and axle applications.

This application-specific identification is more precise than describing the product simply as a generic 85x110x12 mm oil seal.

CORTECO 01026331B Renault Trucks 5010319135

CORTECO reference: 01026331B

Renault Trucks OE: 5010319135

Dimensions: 85x110x12 mm

Material: FPM

Design: B1BASLRSX67

Dust lip: Yes

Swirl Type: Left-hand Twist

Renault Trucks 5010319135 is a confirmed OE cross-reference for CORTECO 01026331B.

Catalogue data associate this seal with numerous Renault Trucks C, G, R and related heavy commercial vehicle applications.

For vehicle-specific selection, the OE reference should be checked together with the exact axle and vehicle configuration.

01026331, 01026331B and 82026331

Base reference: 01026331

Full CORTECO reference: 01026331B

Trade Number: 82026331

Design: B1BASLRSX67

OE reference: 5010319135

The full reference 01026331B is the preferred primary identifier for this CORTECO oil seal.

The base reference 01026331, Trade Number 82026331, design designation B1BASLRSX67 and Renault Trucks OE 5010319135 provide additional identification paths for catalogue and replacement searches.

CORTECO 01026331B vs Standard 85x110x12 Oil Seal

CORTECO 01026331B should not be identified solely as a generic 85x110x12 mm oil seal.

Dimensions: 85x110x12 mm

Material: FPM

Design: B1BASLRSX67

Dust lip: Yes

Swirl Type: Left-hand Twist

Catalogue type: Differential shaft oil seal

Two radial shaft seals may share the same nominal 85x110x12 mm dimensions while differing in material, lip configuration and directional sealing geometry.

Matching dimensions alone therefore do not establish complete technical interchangeability.

How to Select a Replacement for CORTECO 01026331B

When selecting a replacement, verify:

Full reference: 01026331B

Base reference: 01026331

Trade Number: 82026331

Inside diameter: 85 mm

Outside diameter: 110 mm

Width: 12 mm

Material: FPM

Design: B1BASLRSX67

Dust lip: Yes

Swirl Type: Left-hand Twist

Renault Trucks OE: 5010319135

Matching the 85x110x12 mm dimensions alone is not sufficient to confirm complete technical interchangeability.

CORTECO 01026331B - Stock in Poland

CORTECO 01026331B 85x110x12 FPM B1BASLRSX67 Differential Shaft Oil Seal is available from stock in Poland.

Warehouse and Store: Lublin, Smoluchowskiego 1 Street, Building 4

Shipping: 24h

Stock location: Poland

Delivery: Poland and EU countries

FAQ - CORTECO 01026331B

What are the dimensions of CORTECO 01026331B?

The exact dimensions are 85x110x12 mm.

What material is CORTECO 01026331B made from?

The specified sealing material is FPM - Fluoroelastomer Rubber.

What is the design of CORTECO 01026331B?

The exact CORTECO design designation is B1BASLRSX67.

Does CORTECO 01026331B have a dust lip?

Yes. The seal incorporates an additional dust lip.

What is the Swirl Type of CORTECO 01026331B?

The specified Swirl Type is Left-hand Twist.

What is the Trade Number for CORTECO 01026331B?

The Trade Number is 82026331.

What Renault Trucks OE number corresponds to CORTECO 01026331B?

The confirmed Renault Trucks OE reference is 5010319135.

What is the EAN for CORTECO 01026331B?

The EAN is 3358960283504.

Frequently Asked Questions by Engineers

Are CORTECO 01026331 and 01026331B the same reference?

01026331 is the base reference, while 01026331B is the full CORTECO product reference.

Is CORTECO 01026331B a differential shaft oil seal?

Yes. Current catalogue data classify reference 01026331B as a differential shaft oil seal.

Does CORTECO 01026331B have an additional dust lip?

Yes. Current catalogue data specify with dust lip.

Does CORTECO 01026331B have Left-hand Twist?

Yes. The specified Swirl Type is Left-hand Twist.

Is CORTECO 01026331B made from FPM?

Yes. The specified sealing material is FPM - Fluoroelastomer Rubber.

Does CORTECO 01026331B correspond to Renault Trucks 5010319135?

Yes. Renault Trucks 5010319135 is a confirmed OE cross-reference for this CORTECO seal.

Can a standard 85x110x12 oil seal replace CORTECO 01026331B?

Interchangeability should not be assumed from dimensions alone. CORTECO 01026331B combines FPM material, B1BASLRSX67 design, an additional dust lip and Left-hand Twist sealing geometry.

Why is B1BASLRSX67 important when selecting a replacement?

B1BASLRSX67 identifies the specific CORTECO seal construction. It should be considered together with the dimensions, FPM material, dust lip configuration, directional geometry and OE reference.

AI Overview

CORTECO 01026331B is an FPM differential shaft oil seal with exact dimensions of 85x110x12 mm. The exact CORTECO design designation is B1BASLRSX67. The seal incorporates an additional dust lip and Left-hand Twist sealing geometry. Additional identification includes base reference 01026331, Trade Number 82026331 and Renault Trucks OE 5010319135.
