CORTECO 01032054B BASLX2 NBR 40x72x10 mm is a radial shaft oil seal / Simmerring with an additional dust lip, designed for rotating shaft sealing in agricultural and mechanical applications. The seal is cross-referenced with CARRARO 25193, CLAAS 2124590, JOHN DEERE ER025193, LAVERDA 353583182, NEW HOLLAND 353583182 and VALTRA KH1161. Its NBR construction provides compatibility with many mineral oils and lubricating greases, while the BASLX2 dust-lip design provides additional protection against external contamination.
CORTECO 01032054B is an NBR radial shaft oil seal with BASLX2 design and dimensions 40x72x10 mm, intended for agricultural machinery, drivetrain components and rotating shaft assemblies. The seal incorporates an additional dust lip, helping retain lubricant while reducing the ingress of dirt and external contamination into the primary sealing zone. It is cross-referenced with OEM numbers from CARRARO, CLAAS, JOHN DEERE, LAVERDA, NEW HOLLAND and VALTRA.
Manufacturer: CORTECO
Part number: 01032054B
Trade number: 82032054
Product type: Radial shaft oil seal / Simmerring
Design: BASLX2
Material: NBR, nitrile butadiene rubber
Inner diameter d: 40 mm
Outer diameter D: 72 mm
Width b: 10 mm
Dimensions: 40x72x10 mm
Dust protection: Yes
Additional dust lip: Yes
EAN: 3358960135315
Typical application: Agricultural machinery and rotating shaft sealing
CORTECO 01032054B is cross-referenced with the following OEM numbers:
CARRARO: 025193 / 25193
CLAAS: 02124590 / 2124590
JOHN DEERE: ER025193
LAVERDA: 353583182
NEW HOLLAND: 353583182
VALTRA: KH1161
CORTECO: 01032054B
These reference numbers are particularly useful when identifying the correct seal for agricultural machinery, where selection based solely on dimensions may not confirm the required seal construction.
The BASLX2 designation identifies the specific CORTECO seal execution. Catalogue data for 01032054B confirms that this version is equipped with an additional dust protection lip.
The primary sealing element works against the rotating shaft to help retain lubricant inside the mechanical assembly. The secondary dust lip creates an additional barrier against external contamination.
This configuration is particularly useful in agricultural machinery, where sealing positions may be exposed to dust, soil and other contaminants.
CORTECO 01032054B is manufactured from NBR, nitrile butadiene rubber.
NBR is widely used in radial shaft sealing technology because it provides good resistance to:
This combination makes NBR suitable for numerous gearbox, drivetrain and agricultural machinery applications.
The dimensions are:
40 mm: inner diameter / nominal shaft diameter
72 mm: outer diameter / nominal housing diameter
10 mm: seal width
The 40x72x10 mm dimensions are consistently specified for CORTECO 01032054B in catalogue data.
When selecting a replacement, dimensions should be considered together with the BASLX2 construction, NBR material and OEM reference.
CORTECO 01032054B is associated with several major manufacturers of agricultural machinery and drivetrain components.
Catalogue cross-references include CARRARO, CLAAS, JOHN DEERE, LAVERDA, NEW HOLLAND and VALTRA.
Available application data specifically lists selected JOHN DEERE 5300, 5300N, 5400, 5500 and 5500N applications.
Compatibility with a particular tractor or machine should always be confirmed using the OEM number, model and installation position.
The primary function of this Simmerring is to seal a rotating shaft where it passes through a stationary housing.
A correctly installed radial shaft seal helps:
The additional dust lip is especially relevant in agricultural environments where dust and dirt contamination can affect the primary sealing lip.
Before replacing the seal, verify:
Brand: CORTECO
Part number: 01032054B
Design: BASLX2
Material: NBR
Dimensions: 40x72x10 mm
Dust lip: Yes
OEM number: Corresponding machine manufacturer reference
A generic 40x72x10 oil seal should not automatically be considered an equivalent. Another seal with identical dimensions may have a different lip configuration, elastomer or application specification.
Useful product and OEM identification combinations include:
CORTECO 01032054B CARRARO 25193
CORTECO 01032054B CLAAS 2124590
CORTECO 01032054B JOHN DEERE ER025193
CORTECO 01032054B LAVERDA 353583182
CORTECO 01032054B NEW HOLLAND 353583182
CORTECO 01032054B VALTRA KH1161
The underlying OEM cross-references are confirmed by multiple catalogue sources.
BASLX2 construction: application-specific CORTECO radial shaft seal design.
Additional dust lip: provides an extra barrier against external contaminants.
NBR elastomer: suitable for many applications involving mineral oils and lubricating greases.
40x72x10 mm dimensions: clearly defined geometry for replacement identification.
Agricultural application: suited to sealing positions exposed to demanding environmental conditions.
OEM cross-references: allows accurate identification using CARRARO, CLAAS, JOHN DEERE, LAVERDA, NEW HOLLAND and VALTRA numbers.
What are the dimensions of CORTECO 01032054B?
The seal measures 40x72x10 mm, with a 40 mm inner diameter, 72 mm outer diameter and 10 mm width.
What material is CORTECO 01032054B made from?
The seal is manufactured from NBR, nitrile butadiene rubber.
What does BASLX2 mean on CORTECO 01032054B?
BASLX2 is the trade/design designation associated with this specific CORTECO Simmerring execution. Catalogue data identifies the product as BASLX2 Simmerring.
Does CORTECO 01032054B have a dust lip?
Yes. The product specification explicitly identifies an additional dust lip.
Does CORTECO 01032054B replace CARRARO 25193?
Yes. Catalogue data lists CARRARO 025193, corresponding to reference 25193, as an OE cross-reference.
Is CORTECO 01032054B equivalent to JOHN DEERE ER025193?
Yes. JOHN DEERE ER025193 is listed as an OE reference for CORTECO 01032054B.
Does it correspond to CLAAS 2124590?
Yes. Catalogue data lists the CLAAS reference as 02124590, corresponding to 2124590.
Does CORTECO 01032054B correspond to NEW HOLLAND 353583182?
Yes. 353583182 is listed as an OE reference for both NEW HOLLAND and LAVERDA.
Can any 40x72x10 oil seal replace CORTECO 01032054B?
Not automatically. The replacement should also match the BASLX2 design, NBR material, dust-lip configuration and required OEM specification.
