CORTECO 01034875 BF RWDR-KOMBI 45x64.85/71.2x8.9/14.7 mm - Differential Radial Shaft Oil Seal

CORTECO 01034875 BF RWDR-KOMBI 45x64.85/71.2x8.9/14.7 mm - Differential Radial Shaft Oil Seal Simmerring

CORTECO 01034875 BF RWDR-KOMBI 45x64.85/71.2x8.9/14.7 mm is a combined radial shaft oil seal from the Simmerring family, used in specified differential, transmission and axle shaft applications. The seal is manufactured from ACM polyacrylate rubber and features compound geometry with a 45 mm inside diameter, 64.85/71.2 mm outside diameters and 8.9/14.7 mm heights.

Technical data - CORTECO 01034875

What does CORTECO 01034875 BF RWDR-KOMBI mean?

The complete product identification is:

CORTECO 01034875 BF RWDR-KOMBI 45x64.85/71.2x8.9/14.7 mm

Each element helps distinguish this product from conventional radial shaft oil seals with simpler geometry.

CORTECO - manufacturer of the sealing component.

01034875 - CORTECO product identification number.

01034875B - reference commonly found in aftermarket catalogue systems.

82034875 - additional CORTECO reference associated with this product.

BF - type designation for this specific version.

RWDR-KOMBI - designation describing the combined radial shaft sealing construction.

ACM - polyacrylate rubber used as the elastomeric sealing material.

45x64.85/71.2x8.9/14.7 mm - complete compound dimensional specification.

For accurate identification, the complete geometry and construction should be retained. This product should not be simplified to a generic 45x65 mm oil seal.

Dimensions of CORTECO 01034875

The complete dimensional specification is:

45x64.85/71.2x8.9/14.7 mm

where:

• d = 45 mm - inside diameter
• D1 = 64.85 mm - first outside diameter
• D2 = 71.2 mm - second outside diameter
• B1 = 8.9 mm - first height
• B2 = 14.7 mm - overall height

Some catalogue systems may round the first outside diameter to 64.8 mm or 65 mm.

For precise technical identification, the correct value should be retained as:

64.85 mm

and the complete dimensional designation as:

45x64.85/71.2x8.9/14.7 mm

Why is the 45x64.85/71.2x8.9/14.7 mm geometry important?

CORTECO 01034875 is not a conventional radial shaft seal described by one outside diameter and one width.

The two outside diameters:

64.85/71.2 mm

and two height values:

8.9/14.7 mm

describe the compound geometry of this specific sealing component.

This is particularly important when evaluating replacement products.

A conventional 45x65x9 mm seal may appear dimensionally similar in its basic sealing section, but that does not establish interchangeability with CORTECO 01034875.

ACM - Polyacrylate Rubber

CORTECO 01034875 is manufactured from:

ACM - Polyacrylate Rubber

ACM elastomers are used in sealing systems for transmissions, drivetrains and differentials where the material must operate with the specified lubricant and under the conditions of the particular assembly.

When evaluating the seal for an application, consider:

• lubricant type
• actual operating temperature
• shaft surface speed
• lubrication conditions
• transmission design
• differential design
• mating surface condition
• vehicle or transmission manufacturer requirements

A specific operating temperature range should not be assigned to CORTECO 01034875 solely from generic ACM material data.

BF RWDR-KOMBI construction

The product is identified with:

BF RWDR-KOMBI

RWDR is used in technical terminology for a radial shaft sealing ring, while KOMBI identifies a more complex combined sealing configuration.

For CORTECO 01034875, the special nature of the construction is also evident from its compound geometry:

45x64.85/71.2x8.9/14.7 mm

When selecting an alternative, the complete construction should therefore be considered rather than only the 45 mm shaft diameter and approximate 65 mm housing diameter.

The BF designation should also be retained as part of the exact product identification. It should not be replaced with another CORTECO profile code unless interchangeability is specifically confirmed.

CORTECO 01034875 as a differential oil seal

CORTECO 01034875B is classified in aftermarket catalogues as a:

differential radial shaft oil seal

In specified vehicle applications, it is also used as a transmission axle shaft or driveshaft seal.

The component seals the area where a rotating shaft passes through the housing of a transmission or differential assembly.

The exact installation position must always be confirmed according to the OE reference and documentation for the specific vehicle or transmission.

Confirmed OE reference numbers

The following cross-reference numbers are associated with CORTECO 01034875 / 01034875B:

CITROEN

• 312160

FIAT

• 55207480

PEUGEOT

• 312160

SAAB

• 55355129

OE references are particularly useful for this product because its compound geometry makes selection based only on basic shaft and housing dimensions unreliable.

CORTECO 01034875 vs Citroen / Peugeot 312160

The reference:

312160

is associated with both:

CITROEN

and:

PEUGEOT

and is cross-referenced with CORTECO 01034875B.

In some parts catalogues, the reference can also be formatted as:

3121.60

Both formats can therefore be useful when identifying the component, while 312160 remains the compact OE reference.

CORTECO 01034875 vs Fiat 55207480

The confirmed Fiat reference for this sealing component is:

55207480

This OE number is cross-referenced with CORTECO 01034875B and provides a useful identification point when selecting the correct transmission or axle shaft seal.

The exact transmission configuration and installation position should still be checked before installation.

CORTECO 01034875 vs Saab 55355129

Another confirmed reference associated with this product is:

SAAB 55355129

For applications using this OE number, identification by the original reference is more reliable than selecting a seal only by its nominal shaft diameter.

Confirmed vehicle applications

Application catalogue data associates CORTECO 01034875B with specified versions within vehicle families including:

• Citroen Jumper
• Fiat Ducato
• Peugeot Boxer

In these applications, the product is catalogued as a transmission / axle shaft sealing component.

Application data also associates the seal with specified applications using Saab reference 55355129.

The presence of a vehicle model family in catalogue data does not mean the seal fits every version, engine, model year or transmission.

Compatibility should be confirmed using:

OE reference + transmission type + vehicle version + installation position

M40 transmission applications

For specified Fiat Ducato, Citroen Jumper and Peugeot Boxer applications, aftermarket catalogue data identifies CORTECO 01034875B as an axle shaft seal used with the:

M40 manual transmission

Some application data also uses the designation:

M40 CV6

and identifies the seal for a specific installation side.

This information applies only to the relevant vehicle and transmission configurations. It should not be interpreted as universal compatibility with every M40 transmission.

Alternative designations and reference numbers

Useful identification variants include:

• CORTECO 01034875
• CORTECO 01034875B
• 01034875 CORTECO
• 01034875B CORTECO
• CORTECO 82034875
• CORTECO 01034875 BF
• CORTECO 01034875 RWDR-KOMBI
• CORTECO 01034875 BF RWDR-KOMBI
• CORTECO 01034875 ACM
• CORTECO 01034875 45x64.85/71.2x8.9/14.7
• CORTECO 01034875B 45x64.85/71.2x8.9/14.7
• CORTECO Simmerring 45x64.85/71.2x8.9/14.7
• CORTECO differential oil seal
• CORTECO axle shaft seal
• CORTECO M40 oil seal
• Citroen 312160
• Citroen 3121.60
• Peugeot 312160
• Peugeot 3121.60
• Fiat 55207480
• Saab 55355129

Confirmed references:

CORTECO

• 01034875
• 01034875B
• 82034875

CITROEN

• 312160

FIAT

• 55207480

PEUGEOT

• 312160

SAAB

• 55355129

CORTECO 01034875 vs a standard 45x65 mm oil seal

CORTECO 01034875 should not automatically be replaced by a conventional radial shaft oil seal with dimensions close to:

45x65 mm

For CORTECO 01034875, verify:

• 45 mm inside diameter
• D1 = 64.85 mm outside diameter
• D2 = 71.2 mm second outside diameter
• B1 = 8.9 mm height
• B2 = 14.7 mm overall height
• ACM material
• BF type
• RWDR-KOMBI construction
• OE reference
• installation position

Similar basic dimensions do not establish full technical interchangeability.

The compound 64.85/71.2 mm outside geometry and 8.9/14.7 mm height are particularly important for this product.

How to select CORTECO 01034875 correctly

The safest starting point is identification by:

CORTECO 01034875 / 01034875B

or a confirmed OE reference:

Citroen 312160

Fiat 55207480

Peugeot 312160

Saab 55355129

Then verify:

• ACM material
• BF type
• RWDR-KOMBI construction
• complete 45x64.85/71.2x8.9/14.7 mm dimensions
• transmission type
• installation position

For vehicle applications, additional confirmation using the VIN and the relevant vehicle parts catalogue is recommended.

Selection and interchangeability checklist

Before ordering CORTECO 01034875, check:

• CORTECO 01034875 / 01034875B
• OE reference
• ACM material
• BF version
• RWDR-KOMBI construction
• 45 mm inside diameter
• 64.85/71.2 mm outside geometry
• 8.9/14.7 mm height
• transmission type
• installation position

If the existing seal has similar basic dimensions but different external geometry or overall height, interchangeability should not be assumed.

Installation of CORTECO 01034875

Before installation, thoroughly clean the seal housing and the mating surface of the shaft or axle shaft.

Check for:

• scratches
• burrs
• corrosion
• sharp edges
• wear grooves
• mechanical damage

Because of the compound geometry of CORTECO 01034875, correct installation depth and orientation are particularly important.

The seal should be installed evenly and squarely using a fitting tool that applies force to the appropriate structural surface.

Installation force should not be applied directly to the functional sealing elements.

What should be checked when an axle shaft or differential seal leaks?

If the previous seal was leaking, inspect the surrounding components before installing the new CORTECO 01034875.

Check:

• axle shaft or shaft sealing surface
• wear grooves
• shaft runout
• bearing play
• transmission bearing condition
• alignment
• seal housing condition
• lubricant level
• correct lubricant specification

Oil leakage is not always caused solely by deterioration of the radial shaft seal. Excessive shaft movement or a damaged sealing surface can cause leakage even after a new seal has been installed.

FAQ - CORTECO 01034875

What are the dimensions of CORTECO 01034875?

The complete dimensions are 45x64.85/71.2x8.9/14.7 mm. The seal has a 45 mm inside diameter, 64.85 and 71.2 mm outside diameters, and 8.9/14.7 mm height.

What material is CORTECO 01034875 made from?

CORTECO 01034875 is manufactured from ACM polyacrylate rubber.

What does RWDR-KOMBI mean?

RWDR refers to a radial shaft sealing ring, while KOMBI identifies a combined sealing configuration. For this SKU, the complete construction and compound geometry should be retained when selecting a replacement.

Are CORTECO 01034875 and 01034875B the same reference?

01034875 identifies the CORTECO product, while 01034875B is a reference format widely used in aftermarket catalogue systems. The complete dimensions and OE cross-references should also be verified during selection.

Which OE numbers correspond to CORTECO 01034875?

Confirmed references include Citroen 312160, Peugeot 312160, Fiat 55207480 and Saab 55355129.

Is CORTECO 01034875 an axle shaft seal?

In specified catalogue applications, CORTECO 01034875B is used as a transmission axle shaft seal. It is also classified as a differential radial shaft oil seal.

Is CORTECO 01034875 used with the M40 transmission?

Application data identifies 01034875B for specified M40 manual transmission configurations, including selected Fiat Ducato, Citroen Jumper and Peugeot Boxer applications. Compatibility must be checked using the OE number and exact transmission version.

Can a standard 45x65 oil seal replace CORTECO 01034875?

No automatic interchangeability should be assumed. CORTECO 01034875 has compound 45x64.85/71.2x8.9/14.7 mm geometry, ACM material and BF RWDR-KOMBI construction. Similar nominal dimensions alone are insufficient to confirm compatibility.

CORTECO 01034875 BF RWDR-KOMBI 45x64.85/71.2x8.9/14.7 mm - key information

CORTECO 01034875 is an ACM combined radial shaft oil seal with BF RWDR-KOMBI construction and compound 45x64.85/71.2x8.9/14.7 mm geometry. It is used in specified differential and transmission axle shaft applications. References include 01034875B, 82034875, Citroen/Peugeot 312160, Fiat 55207480 and Saab 55355129.

Availability from simmering.pl

CORTECO 01034875 BF RWDR-KOMBI 45x64.85/71.2x8.9/14.7 mm is available from simmering.pl for transmission repair specialists, workshops, industrial maintenance, technical procurement, distributors and B2B customers.

Products are supplied from stock in Poland, with worldwide shipping available. simmering.pl specialises in CORTECO Simmerring radial shaft seals, technical sealing solutions and bearings, with support for product identification by manufacturer reference, OE number, construction and dimensions.
