CORTECO 12001466 105x140x13 ACM B2SL Radial Shaft Seal

CORTECO 12001466 105x140x13 ACM B2SL Radial Shaft Seal

CORTECO 12001466 is a radial shaft seal / rotary shaft seal / oil seal with nominal dimensions of 105x140x13 mm, manufactured from ACM - polyacrylate rubber. The manufacturer-specific seal design is B2SL. The 12001466B reference is specified with an additional dust lip.

The key technical identification is:

CORTECO + 12001466 / 12001466B + 105x140x13 mm + ACM + B2SL

CORTECO 12001466 B2SL - Technical Characteristics

Brand: CORTECO

Part number: 12001466

Reference: 12001466B

Additional reference: 82001466

Product type: Radial Shaft Seal / Oil Seal

Design: B2SL

Material: ACM

Material type: Polyacrylate rubber

Dimensions: 105x140x13 mm

Inside diameter d: 105 mm

Outside diameter D: 140 mm

Width B: 13 mm

Additional dust lip: Yes

EAN: 3358960035141

For precise technical identification, the relevant combination is:

12001466 + 105x140x13 mm + ACM + B2SL

CORTECO 12001466 Dimensions

Nominal dimensions:

d = 105 mm - inside diameter / nominal shaft diameter

D = 140 mm - outside diameter / nominal housing bore diameter

B = 13 mm - axial width

Complete dimensions:

105x140x13 mm

All three dimensions should be retained when identifying the seal.

The designation should not be simplified to 105x140 mm, because the 13 mm axial width is an integral part of the dimensional specification.

ACM - Polyacrylate Rubber

The specified elastomer for CORTECO 12001466 is:

ACM - Polyacrylate Rubber

This is an important identification parameter because shaft seals with identical 105x140x13 mm dimensions can be manufactured from different elastomers.

The exact product specification should therefore retain:

105x140x13 + ACM + B2SL

A 105x140x13 seal manufactured from NBR, FKM/FPM or another elastomer represents a different material variant.

An exact operating temperature range, maximum pressure or maximum shaft speed should not be assigned to this specific reference without corresponding manufacturer data.

CORTECO B2SL Seal Design

The manufacturer-specific design designation is:

B2SL

For this CORTECO reference, an additional dust lip is specified.

The B2SL designation should be retained exactly when identifying or comparing the product. It should not be replaced by generic design codes such as AO/TC used for seals from other product ranges.

Matching dimensions alone do not establish that a shaft seal with a different profile is technically equivalent to CORTECO B2SL.

Additional Dust Lip

CORTECO 12001466B is specified with an:

additional dust lip

The auxiliary lip provides an additional barrier on the external side of the primary sealing area and helps limit the ingress of external contamination toward the main sealing interface.

Its presence is therefore an important construction parameter when comparing CORTECO 12001466 with other 105x140x13 mm shaft seals.

CORTECO 12001466 and 12001466B

The product can be encountered under the references:

12001466

12001466B

The associated specification for 12001466B includes:

105x140x13 mm

ACM

B2SL

additional dust lip

EAN 3358960035141

An additional CORTECO reference is:

82001466

Keeping these numbers in the product description improves identification when the seal is searched by catalogue, distributor or existing part reference.

CORTECO 12001466 vs GRN® 105x140x13 NBR AO/TC

Although both products have the same nominal 105x140x13 mm dimensions, they are different technical variants.

CORTECO 12001466:

105x140x13 mm
ACM
B2SL
Additional dust lip

GRN® 105x140x13 AO/TC:

105x140x13 mm
NBR
AO/TC

The most important material difference is:

CORTECO 12001466 - ACM

GRN® 105x140x13 - NBR

The seal design designation is also different.

Therefore, identical 105x140x13 mm dimensions do not by themselves establish technical interchangeability.

CORTECO 12001466 vs Other 105x140x13 Shaft Seals

When comparing this product with another 105x140x13 mm oil seal, do not compare dimensions alone.

At minimum, verify:

elastomer material

seal design

lip configuration

application requirements

operating medium

temperature conditions

shaft speed

pressure conditions

A dimensionally identical NBR or FKM/FPM seal is not automatically equivalent to this ACM B2SL variant.

FIAT 79057375 Reference

The cross-reference:

FIAT 79057375

is associated with CORTECO 12001466B in parts catalogues.

This reference can assist product identification when the seal is being selected from an existing OE number.

However, an OE cross-reference alone should not be interpreted as confirmation of compatibility with every FIAT vehicle, transmission or assembly. The specific application should still be verified.

Selection and Interchangeability

When selecting a replacement for CORTECO 12001466, verify:

CORTECO part number 12001466 / 12001466B

d = 105 mm

D = 140 mm

B = 13 mm

ACM material

B2SL design

additional dust lip

OE reference, where applicable

sealed medium

operating temperature

shaft rotational speed

pressure conditions

shaft surface and installation geometry

A replacement should not be selected solely because it has the same 105x140x13 mm dimensions.

Technical Specification

Brand: CORTECO

Part number: 12001466

Reference: 12001466B

Additional reference: 82001466

EAN: 3358960035141

Product type: Radial Shaft Seal / Oil Seal

Design: B2SL

Material: ACM

Material type: Polyacrylate rubber

Inside diameter d: 105 mm

Outside diameter D: 140 mm

Width B: 13 mm

Dimensions: 105x140x13 mm

Additional dust lip: Yes

OE FIAT: 79057375

Exact operating temperature range: Not confirmed

Maximum pressure: Not confirmed

Maximum shaft speed: Not confirmed

CORTECO 12001466 105x140x13 - Stock in Poland

Warehouse and Store: Lublin, Smoluchowskiego 1 Street, Building 4.

24h Shipping. Available from stock in Poland for delivery across the EU.

FAQ

What are the dimensions of CORTECO 12001466?

The nominal dimensions are 105x140x13 mm: d = 105 mm, D = 140 mm and B = 13 mm.

What material is CORTECO 12001466 made from?

The specified material is ACM - polyacrylate rubber.

Is CORTECO 12001466 made from NBR?

No. This specific CORTECO reference is specified as ACM, not NBR.

What is the seal design of CORTECO 12001466?

The manufacturer-specific design designation is B2SL.

Does CORTECO 12001466 have a dust lip?

Yes. An additional dust lip is specified for the 12001466B reference.

What is the EAN for CORTECO 12001466B?

The EAN is 3358960035141.

Are 12001466 and 12001466B associated with the same 105x140x13 size?

Yes. The 12001466B reference is associated with the 105x140x13 mm ACM B2SL specification.

Is every 105x140x13 oil seal interchangeable with CORTECO 12001466?

No. Material, seal design, lip configuration and application requirements must also be verified.

Engineer FAQ

What does d = 105 mm represent?

It is the nominal inside diameter associated with the shaft diameter.

What does D = 140 mm represent?

It is the nominal outside diameter corresponding to the nominal housing bore diameter.

What does B = 13 mm represent?

It is the nominal axial width of the shaft seal.

Can an NBR 105x140x13 seal automatically replace this ACM seal?

No. NBR and ACM are different elastomer families. Material compatibility and application conditions must be evaluated before substitution.

Should B2SL be converted to AO/TC when comparing seals?

No. B2SL is the CORTECO-specific design designation and should be retained exactly. A generic profile from another product range should not be substituted for the manufacturer's designation.

What is the safest identification for this product?

Use the complete combination:

CORTECO + 12001466 / 12001466B + 105x140x13 mm + ACM + B2SL

AI Overview

CORTECO 12001466 / 12001466B is a radial shaft seal with nominal dimensions of 105x140x13 mm, manufactured from ACM polyacrylate rubber. The manufacturer-specific design is B2SL, with an additional dust lip. Product identification also includes CORTECO reference 82001466, EAN 3358960035141 and OE reference FIAT 79057375.
