CORTECO 12001700 / 12001700B is an NBR radial shaft seal with B1KL design and dimensions 45x72x8 mm. The CORTECO catalogue classifies it for agricultural applications and associates the reference with NEW HOLLAND / CNH. When selecting an equivalent, verify the NBR material and B1KL design in addition to the dimensions. Available from simmering.pl, stock in Poland with worldwide shipping.
CORTECO 12001700 is an NBR radial shaft seal with dimensions 45x72x8 mm and B1KL design. The product is also listed under reference CORTECO 12001700B. The CORTECO catalogue classifies this seal for agricultural applications and associates it with NEW HOLLAND / CNH.
| Parameter | Value |
|---|---|
| Manufacturer | CORTECO |
| Reference | 12001700 |
| Alternative reference | 12001700B |
| Product type | Radial shaft seal / oil seal |
| Design | B1KL |
| Material | NBR |
| Shaft diameter d | 45 mm |
| Housing bore diameter D | 72 mm |
| Width b | 8 mm |
| Application group | Agricultural machinery |
| Catalogue application | NEW HOLLAND / CNH |
The complete seal dimensions are:
45x72x8 mm
shaft diameter d: 45 mm
housing bore diameter D: 72 mm
width b: 8 mm
The dimensions 45x72x8 mm are confirmed in CORTECO catalogues for reference 12001700 / 12001700B.
CORTECO 12001700 is manufactured from NBR - nitrile butadiene rubber.
NBR is one of the most widely used elastomers for radial shaft seals. It provides good resistance to many mineral oils and greases and is therefore commonly used in machinery, gearboxes, mechanical systems and agricultural equipment.
Material suitability should always be verified against the actual operating medium, temperature, shaft speed and application conditions.
The CORTECO catalogue specifies the seal design as:
B1KL
The B1KL profile is an important part of the complete product identification.
Correct specification:
CORTECO 12001700 - NBR - B1KL - 45x72x8 mm
A replacement should therefore not be selected solely on the basis of the 45x72x8 mm dimensions.
The CORTECO catalogue associates:
12001700 / 12001700B
with:
NEW HOLLAND / CNH
The product is classified within the agricultural sealing range.
When selecting the seal for a specific tractor, agricultural machine, transmission or mechanical assembly, the original part number and exact machine configuration should also be verified.
The product can be found under both references:
12001700
and
12001700B
Both numbers are used when identifying the CORTECO seal with the following specification:
45x72x8 mm - NBR - B1KL
For technical catalogue searches, purchasing systems and online searches, both references should be checked.
The dimensions 45x72x8 mm do not uniquely identify one CORTECO radial shaft seal.
CORTECO offers different seal designs in the same dimensions, including:
CORTECO 12001700 - NBR B1KL
CORTECO 12010958 - NBR BA
CORTECO 12011169 - NBR BASL
other material and design variants
Therefore, identical 45x72x8 mm dimensions do not automatically confirm full interchangeability.
The reference number, material, seal profile and requirements of the specific application must also be verified.
The product can also be searched as:
CORTECO 12001700
CORTECO 12001700B
12001700
12001700B
CORTECO B1KL
B1KL 45x72x8
CORTECO 45x72x8 NBR
oil seal 45x72x8
radial shaft seal 45x72x8
NBR oil seal 45x72x8
Simmerring 45x72x8
Simmerring NBR 45x72x8
New Holland oil seal 45x72x8
New Holland shaft seal 45x72x8
CNH oil seal 45x72x8
New Holland CORTECO 12001700
Before selecting an alternative to CORTECO 12001700, verify:
Shaft diameter 45 mm.
Housing bore diameter 72 mm.
Width 8 mm.
NBR material.
B1KL design.
CORTECO reference 12001700 / 12001700B.
OE reference when selecting the seal for a specific machine.
Operating medium.
Operating temperature.
Shaft speed.
The 45x72x8 mm dimensions alone are not sufficient to confirm interchangeability.
Before installation:
clean the shaft and housing bore thoroughly
inspect the shaft sealing surface
remove dirt, corrosion and burrs
protect the sealing lip from sharp edges
use a suitable installation tool
press the seal evenly into the housing
avoid deformation of the seal body
verify the correct installation orientation
A worn, corroded or damaged shaft surface can reduce the effectiveness and service life of the new seal.
CORTECO 12001700 has dimensions of 45x72x8 mm.
The seal is manufactured from NBR - nitrile butadiene rubber.
The CORTECO catalogue design designation is B1KL.
Yes. Both references are used to identify the NBR B1KL seal with dimensions 45x72x8 mm.
Yes. The CORTECO catalogue classifies 12001700B within its agricultural sealing range.
Yes. The CORTECO catalogue associates this reference with NEW HOLLAND / CNH applications. Exact compatibility with a specific machine should be confirmed using the OE reference and machine configuration.
No. CORTECO offers several seals with dimensions 45x72x8 mm but different designs. The B1KL profile, NBR material and application requirements must also be verified.
No. Although the dimensions are identical, CORTECO 12010958 uses the BA design, while CORTECO 12001700 uses the B1KL design.
CORTECO 12001700 / 12001700B is an NBR radial shaft seal with dimensions 45x72x8 mm and B1KL design. The CORTECO catalogue classifies it for agricultural applications and associates the reference with NEW HOLLAND / CNH. When selecting an equivalent, the B1KL profile and NBR material should be verified in addition to the dimensions.
CORTECO 12001700 NBR B1KL 45x72x8 is available from simmering.pl, a specialist B2B supplier of radial shaft seals, industrial sealing solutions, O-rings and bearings.
Stock and technical service are located in Lublin, Poland, with worldwide shipping available.
