CORTECO 12010928 NBR BA 38x60x10 - Rotary Shaft Seal

CORTECO 12010928 NBR BA 38x60x10 - Rotary Shaft Seal

CORTECO 12010928 is an NBR radial shaft seal with dimensions 38x60x10 mm and BA design. The product is also listed as CORTECO 12010928B. The CORTECO dimensional catalogue associates this reference with IVECO applications, while aftermarket catalogues list IVECO OE references 745332 and 9006457 and identify it as a seal used in manual transmission applications.

CORTECO 12010928 - Technical Data

Dimensions

The primary dimensions of the seal are:

38x60x10 mm

• shaft diameter d: 38 mm

• housing bore diameter D: 60 mm

• width: 10 mm

Some technical catalogues also list CORTECO 12010928B as:

38x60x10/8 mm

with two height values of 10 mm and 8 mm.

Both dimension formats may therefore appear when searching for this reference.

NBR Material

CORTECO 12010928 is manufactured from NBR - nitrile butadiene rubber.

NBR is widely used for radial shaft seals due to its good resistance to many mineral oils and greases.

When selecting a seal, the following operating parameters should also be considered:

• operating medium

• operating temperature

• shaft speed

• pressure

• shaft surface condition

• actual operating environment

BA Design

The CORTECO catalogue specifies the seal design as:

BA

The complete technical identification is:

CORTECO 12010928 - NBR - BA - 38x60x10 mm

The BA design is an important part of the product specification. A replacement should not be selected solely according to shaft diameter, housing diameter and width.

CORTECO 12010928 and 12010928B

The product can be found under the following references:

12010928

12010928B

Both references should be considered when searching technical catalogues, purchasing systems, aftermarket databases and online sources.

The principal specification is:

NBR - BA - 38x60x10 mm

IVECO Application

The CORTECO dimensional catalogue associates reference 12010928 with:

IVECO

Aftermarket catalogues identify CORTECO 12010928B as a radial shaft seal associated with manual transmission applications.

Confirmed OE references:

IVECO 745332

IVECO 9006457

Cross-references:

IVECO 745332 → CORTECO 12010928B

IVECO 9006457 → CORTECO 12010928B

For a specific vehicle or gearbox, compatibility should be confirmed using the OE reference and the exact transmission configuration.

Important - 38x60x10 Does Not Uniquely Identify the Seal

The dimensions 38x60x10 mm alone do not uniquely identify this CORTECO seal.

Other CORTECO products are available in the same dimensions but with different materials and sealing designs. For example:

CORTECO 12019607 - FPM B1BAVISLRSX7 - 38x60x10 mm

This is not the same product as:

CORTECO 12010928 - NBR BA - 38x60x10 mm

Identical dimensions therefore do not automatically confirm full interchangeability.

Alternative Search References

The product can also be searched as:

• CORTECO 12010928

• CORTECO 12010928B

• 12010928

• 12010928B

• CORTECO BA 38x60x10

• CORTECO 38x60x10

• CORTECO 38x60x10/8

• NBR BA 38x60x10

• oil seal 38x60x10

• radial shaft seal 38x60x10

• NBR oil seal 38x60x10

• Simmerring 38x60x10

• Simmerring NBR 38x60x10

• IVECO 745332

• IVECO 9006457

• CORTECO 745332

• CORTECO 9006457

• IVECO oil seal 38x60x10

• IVECO gearbox oil seal

• IVECO transmission shaft seal

Selection and Interchangeability

Before selecting an alternative to CORTECO 12010928, verify:

1. Shaft diameter 38 mm.

2. Housing bore diameter 60 mm.

3. Width 10 mm.

4. Additional 10/8 mm catalogue dimension where relevant.

5. NBR material.

6. BA design.

7. CORTECO reference 12010928 / 12010928B.

8. IVECO OE 745332 or 9006457 when selecting by vehicle application.

9. Operating medium.

10. Actual operating conditions.

Matching the 38x60x10 mm dimensions alone is not sufficient to confirm full interchangeability.

Installation

Before installation:

• clean the shaft and housing bore thoroughly

• inspect the shaft sealing surface

• remove dirt, corrosion and burrs

• protect the sealing lip from sharp edges

• use a suitable installation tool

• press the seal evenly into the housing

• avoid deformation of the seal body

• verify the correct installation orientation

The condition of the shaft sealing surface has a direct effect on sealing performance and service life.

FAQ

What are the dimensions of CORTECO 12010928?

The primary dimensions of CORTECO 12010928 are 38x60x10 mm. Some catalogues also list the product as 38x60x10/8 mm.

What material is CORTECO 12010928 made from?

The seal is manufactured from NBR - nitrile butadiene rubber.

What is the design of CORTECO 12010928?

The CORTECO catalogue specifies the design as BA.

Are CORTECO 12010928 and 12010928B related references?

Yes. 12010928B is an aftermarket reference used for the NBR BA 38x60x10 mm seal, while 12010928 remains an important product identification and search reference.

Which vehicle manufacturer is associated with CORTECO 12010928?

The CORTECO dimensional catalogue associates this reference with IVECO.

What IVECO OE numbers correspond to CORTECO 12010928B?

Aftermarket catalogues list IVECO 745332 and IVECO 9006457.

Is CORTECO 12010928 a transmission oil seal?

Aftermarket catalogues classify 12010928B as a radial shaft seal associated with manual transmission applications. The exact installation position should be confirmed for the specific vehicle and gearbox.

Why is the dimension 38x60x10/8 also used?

Some catalogues specify two height values for CORTECO 12010928B: 10 mm and 8 mm. For this reason, searches may return both 38x60x10 mm and 38x60x10/8 mm.

Can any 38x60x10 oil seal replace CORTECO 12010928?

No. Seals with identical dimensions may use different materials and sealing profiles. The NBR material, BA design, CORTECO reference and application requirements should also be verified.

CORTECO 12010928 - Quick Technical Answer

CORTECO 12010928 / 12010928B is an NBR radial shaft seal with BA design and primary dimensions 38x60x10 mm. The CORTECO catalogue associates it with IVECO applications, while aftermarket catalogues list IVECO OE references 745332 and 9006457 and identify the seal with manual transmission applications.
