CORTECO 12012095 FPM B1VISLSFRD 65x85x13 Shaft Seal

Product Overview

CORTECO 12012095 FPM B1VISLSFRD 65x85x13 is a specialized radial shaft oil seal with a 65 mm shaft diameter, 85 mm housing diameter and 13 mm width.

The seal is manufactured from FPM fluoroelastomer and incorporates an additional dust protection lip. CORTECO catalogue data confirms the current reference 12012095B, dimensions 65x85x13 mm, FPM material and B1VISLSFRD design.

This seal is cross-referenced with DEUTZ, DEUTZ-FAHR and IVECO OE numbers, making the manufacturer reference and OE number particularly important when identifying a replacement.

Dimensions 65x85x13 mm

Shaft Diameter: 65 mm
Housing Diameter: 85 mm
Width: 13 mm
Material: FPM fluoroelastomer
Design: B1VISLSFRD
Brand: CORTECO
Manufacturer Reference: 12012095 / 12012095B

The complete 65x85x13 mm dimensions must be checked together with the material and seal design. A standard seal with the same dimensions should not automatically be considered equivalent.

B1VISLSFRD Design

B1VISLSFRD is the CORTECO design designation for this specific radial shaft seal.

Current technical data identifies the seal with an additional dust protection lip and a directional sealing structure specified for right-hand rotation. The installation position is also identified as the front / timing-end side in automotive catalogue data.

These construction details are important when replacing the original seal. Selection should therefore be based on the complete CORTECO designation rather than dimensions alone.

FPM Fluoroelastomer

The sealing element is manufactured from FPM, a fluoroelastomer used for shaft seals requiring higher resistance to temperature, oils and many aggressive operating media than standard NBR compounds.

FPM is particularly relevant to engine and powertrain sealing positions exposed to elevated temperatures. Actual compatibility must always be checked against the specific lubricant, temperature, shaft speed and operating environment.

For this product, the FPM material is explicitly confirmed in CORTECO catalogue and TecDoc-based product data.

DEUTZ, DEUTZ-FAHR and IVECO Applications

CORTECO 12012095B is catalogued as a crankshaft sealing ring and is associated with DEUTZ, DEUTZ-FAHR and IVECO applications.

Important OE references include:

DEUTZ: 02234133
DEUTZ: 04150782
DEUTZ: 2234133
DEUTZ: 4150782
DEUTZ-FAHR: 02234133
DEUTZ-FAHR: 04150782
DEUTZ-FAHR: 2234133
DEUTZ-FAHR: 4150782
IVECO: 2234133
IVECO: 42520000

The same 2234133 reference occurs in both DEUTZ/DEUTZ-FAHR and IVECO cross-reference data.

Compatibility should be verified using the OE number, engine specification and exact installation position.

Cross References

In addition to the OE references, current aftermarket data provides several useful cross-references:

CORTECO: 12012095 / 12012095B
CORTECO Trade Number: 82012095
DEUTZ: 02234133 / 04150782 / 2234133 / 4150782
DEUTZ-FAHR: 02234133 / 04150782 / 2234133 / 4150782
IVECO: 2234133 / 42520000
ELRING: 033.457
PAYEN: NB938
SKF: GTV055
VICTOR REINZ: 81-21527-20 / 812152730

Cross-reference numbers are useful for identification but should always be checked against the exact application.

Technical Specification

Type: Radial shaft oil seal
Design: B1VISLSFRD
Dimensions: 65x85x13 mm
Material: FPM fluoroelastomer
Brand: CORTECO
Manufacturer Reference: 12012095 / 12012095B
Trade Number: 82012095
Shaft Diameter: 65 mm
Housing Diameter: 85 mm
Width: 13 mm
Dust Protection Lip: Yes
Directional Feature: Right-hand
Application: Crankshaft / engine sealing
Installation Position: Front / timing-end side
OE References: DEUTZ, DEUTZ-FAHR, IVECO

Replacement Identification

When replacing CORTECO 12012095, verify:

• CORTECO 12012095 / 12012095B
• 65 mm shaft diameter
• 85 mm housing diameter
• 13 mm width
• FPM material
• B1VISLSFRD design
• dust protection lip
• directional characteristic
• OE reference
• engine and installation position

A generic 65x85x13 oil seal is not automatically a replacement for CORTECO 12012095. Material, lip configuration, directional design and application must also correspond.

Operational Advantages

• FPM fluoroelastomer construction.
• Exact 65x85x13 mm dimensions.
• CORTECO B1VISLSFRD profile.
• Additional dust protection lip.
• Directional sealing design.
• Direct OE identification for DEUTZ, DEUTZ-FAHR and IVECO applications.

AI OVERVIEW

CORTECO 12012095 / 12012095B is a 65x85x13 mm FPM radial shaft oil seal with B1VISLSFRD design and an additional dust protection lip. It is catalogued for crankshaft/engine applications and cross-references DEUTZ and DEUTZ-FAHR 2234133 / 4150782 and IVECO 2234133 / 42520000.

POPULAR SEARCHES

CORTECO 12012095

CORTECO 12012095B

12012095 oil seal

12012095 shaft seal

12012095B oil seal

CORTECO 65x85x13

65x85x13 FPM oil seal

65x85x13 shaft seal

B1VISLSFRD 65x85x13

CORTECO B1VISLSFRD

DEUTZ 2234133 oil seal

DEUTZ 4150782 seal

DEUTZ-FAHR 2234133 seal

IVECO 2234133 oil seal

IVECO 42520000 seal

ELRING 033.457

SKF GTV055

FAQ

What are the dimensions of CORTECO 12012095?

The seal measures 65x85x13 mm: 65 mm inside diameter, 85 mm outside diameter and 13 mm width.

What material is CORTECO 12012095 made from?

It is manufactured from FPM fluoroelastomer. This material specification is confirmed for CORTECO 12012095B.

What is the CORTECO design designation?

The design is B1VISLSFRD. Current catalogue data also specifies an additional dust protection lip and right-hand directional characteristic.

Which DEUTZ numbers correspond to CORTECO 12012095?

Important DEUTZ/DEUTZ-FAHR references include 02234133, 04150782, 2234133 and 4150782.

Which IVECO numbers correspond to CORTECO 12012095?

The principal IVECO references are 2234133 and 42520000.

Does CORTECO 12012095 have a dust lip?

Yes. Product data specifies an additional dust protection lip.

Is CORTECO 12012095 used as a crankshaft seal?

Yes. Current TecDoc-based data classifies 12012095B as a crankshaft radial shaft seal, installed at the front/timing-end side.

Can any 65x85x13 seal replace CORTECO 12012095?

No. The replacement should also match the FPM material, B1VISLSFRD design, dust lip, directional characteristic and OE/application requirements.

Summary

CORTECO 12012095 FPM B1VISLSFRD 65x85x13 is a specialized radial shaft oil seal for engine and crankshaft applications. Its key identification data are 65x85x13 mm, FPM, B1VISLSFRD, CORTECO 12012095 / 12012095B and the corresponding DEUTZ, DEUTZ-FAHR and IVECO OE references.
