CORTECO 12013740B 60x75x16 NBR COMBI SF8 Shaft Seal

CORTECO 12013740B 60x75x16 NBR COMBI SF8 Shaft Seal

CORTECO 12013740B is an NBR combined shaft seal measuring 60x75x16 mm. The CORTECO catalogue design is COMBI SF8, while Freudenberg Sealing Technologies identifies the corresponding sealing system as COMBI F8. The nominal shaft diameter is 60 mm, outside diameter 75 mm and seal width 16 mm.

Complete product identification:

CORTECO -> 12013740B -> 60x75x16 mm -> NBR -> COMBI SF8 -> combined shaft seal

CORTECO 12013740B - Characteristics

Manufacturer: CORTECO

Part number: 12013740B

Base / older reference: 12013740

Trade Number: 82013740

Product type: Combined shaft seal

CORTECO design: COMBI SF8

Freudenberg designation: COMBI F8

Material: NBR

Material specification: 75 NBR 106200 / 72 NBR 902

Dimensions: 60x75x16 mm

Inside diameter: 60 mm

Outside diameter: 75 mm

Width: 16 mm

Weight: 65.8 g

EAN: 3358960143372

CORTECO 12013740B Dimensions

The principal dimensions are:

d - Nominal shaft diameter: 60 mm

D - Outside diameter: 75 mm

B - Width: 16 mm

Complete dimensions:

60x75x16 mm

These dimensions are confirmed in both CORTECO and Freudenberg catalogue data.

All three dimensions should be verified when selecting a replacement.

Matching the 60 mm shaft diameter and 75 mm housing diameter alone is not sufficient because the COMBI SF8 construction and complete 16 mm width are important identification criteria.

NBR Sealing Material

CORTECO 12013740B is specified with NBR sealing material.

The official Freudenberg product data specifies:

75 NBR 106200

and:

72 NBR 902

NBR stands for Nitrile Butadiene Rubber.

The exact material specification is useful when identifying this particular COMBI seal and comparing it with other sealing systems of similar dimensions.

A seal manufactured from FPM, ACM or another elastomer should not automatically be considered technically identical even if its nominal dimensions match.

COMBI SF8 Seal Design

The CORTECO catalogue design designation is:

COMBI SF8

The corresponding Freudenberg Sealing Technologies product designation is:

COMBI F8

This identifies the product as a combined sealing system rather than a conventional basic radial shaft oil seal.

The COMBI construction combines sealing functions in a more developed sealing arrangement designed for rotating shaft applications where the sealing system must also provide protection against external contamination.

For replacement selection, the COMBI SF8 construction should therefore be considered together with the exact 60x75x16 mm dimensions and NBR material.

COMBI SF8 vs COMBI F8

Two closely related design descriptions are associated with this product:

CORTECO: COMBI SF8

Freudenberg Sealing Technologies: COMBI F8

The CORTECO Oil Seals Pocket Guide lists reference 12013740B as:

COMBI SF8

The official Freudenberg product page for reference 12013740 identifies the product family as:

COMBI F8

Both designations are therefore relevant when identifying and searching for this exact sealing system.

CORTECO 12013740 vs 12013740B

The product can be found under the reference:

12013740

and the full CORTECO catalogue reference:

12013740B

The associated technical specification is:

60x75x16 mm

NBR

COMBI SF8

The base reference 12013740 should be retained in the product description because it remains important for technical and catalogue searches.

CORTECO Trade Number 82013740

Another catalogue identifier associated with this product is:

82013740

Useful product identification numbers therefore include:

CORTECO 12013740B

CORTECO 12013740

CORTECO 82013740

COMBI SF8

COMBI F8

60x75x16 NBR

CORTECO 12013740B Applications

Catalogue and cross-reference data associates CORTECO 12013740B with applications including:

DANA

LANDINI

JCB

MASSEY FERGUSON

These manufacturer names should be treated as catalogue application references rather than confirmation that the seal fits every machine produced by the respective manufacturer.

For a specific machine, axle or transmission, compatibility should be confirmed using the exact OE number and technical specification.

Reference Numbers for CORTECO 12013740B

Catalogue and cross-reference data includes:

DANA: 2130600801

LANDINI / MASSEY FERGUSON: 3015548X1

These numbers provide additional identification criteria for CORTECO 12013740B.

The exact OE reference should always be checked against the specific machine or assembly before installation.

CORTECO 12013740B vs Standard 60x75x16 Oil Seal

A conventional radial shaft oil seal measuring:

60x75x16 mm

should not automatically be considered equivalent to CORTECO 12013740B.

CORTECO 12013740B uses the specific:

COMBI SF8

combined sealing construction.

When selecting a replacement, verify:

Inside / shaft diameter: 60 mm

Outside diameter: 75 mm

Width: 16 mm

Material: NBR

Construction: COMBI SF8 / COMBI F8

OE or cross-reference number

Application requirements

Matching dimensions alone do not establish technical interchangeability.

Selecting a Replacement for CORTECO 12013740B

When selecting a technically corresponding replacement, verify at least:

CORTECO reference: 12013740B

Base reference: 12013740

Trade Number: 82013740

d - Nominal shaft diameter: 60 mm

D - Outside diameter: 75 mm

B - Width: 16 mm

Material: NBR

CORTECO design: COMBI SF8

Freudenberg designation: COMBI F8

Material specification: 75 NBR 106200 / 72 NBR 902

OE reference for the specific application

A replacement should not be selected solely on the basis of the 60x75x16 mm dimensions.

Technical Specification

Manufacturer: CORTECO

Part number: 12013740B

Base / older reference: 12013740

Trade Number: 82013740

Product type: Combined shaft seal

CORTECO design: COMBI SF8

Freudenberg designation: COMBI F8

Material: NBR

Material name: Nitrile Butadiene Rubber

Material specification: 75 NBR 106200 / 72 NBR 902

Dimensions: 60x75x16 mm

d - Nominal shaft diameter: 60 mm

D - Outside diameter: 75 mm

B - Width: 16 mm

Weight: 65.8 g

EAN: 3358960143372

FAQ

What are the dimensions of CORTECO 12013740B?

CORTECO 12013740B measures 60x75x16 mm. The nominal shaft diameter is 60 mm, outside diameter is 75 mm and seal width is 16 mm.

What material is CORTECO 12013740B made from?

The seal uses NBR - Nitrile Butadiene Rubber. Freudenberg specifies the materials as 75 NBR 106200 / 72 NBR 902.

What is the design of CORTECO 12013740B?

The CORTECO catalogue designation is COMBI SF8. Freudenberg Sealing Technologies identifies the corresponding product as COMBI F8.

Is CORTECO 12013740B a standard radial shaft oil seal?

No. It is a COMBI combined sealing system and should not be treated as a conventional radial shaft oil seal solely on the basis of its dimensions.

Are CORTECO 12013740 and 12013740B the same product reference?

12013740 is the base reference, while 12013740B is the full CORTECO catalogue reference. The associated specification is 60x75x16 mm, NBR and COMBI SF8.

What is the Trade Number for CORTECO 12013740B?

The catalogue Trade Number is 82013740.

What OE numbers are associated with CORTECO 12013740B?

Catalogue cross-reference data includes DANA 2130600801 and LANDINI / MASSEY FERGUSON 3015548X1.

Can a standard 60x75x16 oil seal replace CORTECO 12013740B?

Not automatically. The replacement should match the 60x75x16 mm dimensions, NBR material, COMBI SF8 / COMBI F8 sealing construction and application requirements.
