CORTECO 12014151B 19x30x6.5 FPM Oil Seal

​CORTECO 12014151B 19x30x6.5 FPM Oil Seal

CORTECO 12014151B is an FPM radial shaft oil seal measuring 19x30x6.5 mm. It incorporates an additional dust lip and is catalogued for PIAGGIO applications under OE references 239391 and 482314. The sealing material is FPM fluoroelastomer.

Complete product identification:

CORTECO -> 12014151B -> 19x30x6.5 mm -> FPM -> dust lip -> PIAGGIO 239391 / 482314

CORTECO 12014151B - Characteristics

Manufacturer: CORTECO

Part number: 12014151B

Base reference: 12014151

Product type: Radial shaft oil seal

Material: FPM

Dimensions: 19x30x6.5 mm

Inside diameter: 19 mm

Outside diameter: 30 mm

Width: 6.5 mm

Dust lip: Yes

OE PIAGGIO: 239391

OE PIAGGIO: 482314

EAN: 3358960342300

CORTECO 12014151B Dimensions

The principal dimensions are:

d - Inside diameter / nominal shaft diameter: 19 mm

D - Outside diameter: 30 mm

B - Width: 6.5 mm

Complete dimensions:

19x30x6.5 mm

The 6.5 mm width should be retained when identifying this exact reference.

A 19x30x6 mm or 19x30x7 mm oil seal should not automatically be considered technically identical to CORTECO 12014151B.

FPM Fluoroelastomer

The specified sealing material is:

FPM - Fluoroelastomer

FPM is an important identifying characteristic of CORTECO 12014151B and should be considered together with the 19x30x6.5 mm dimensions and seal construction.

A radial shaft seal with identical dimensions manufactured from NBR, ACM or another elastomer should not automatically be considered technically equivalent.

Exact material compatibility depends on the medium, additives, temperature and actual operating conditions.

A specific maximum temperature, pressure or shaft speed should not be assigned to this exact CORTECO reference solely from generic FPM material properties.

Additional Dust Lip

CORTECO 12014151B is specified with an additional dust lip.

The dust lip provides an additional barrier on the external side of the primary sealing area and helps restrict external contaminants from reaching the main sealing interface.

This construction characteristic should be considered when comparing CORTECO 12014151B with other 19x30x6.5 mm radial shaft oil seals.

Matching dimensions alone do not confirm an identical lip configuration.

CORTECO 12014151B PIAGGIO Oil Seal

CORTECO 12014151B is catalogued for PIAGGIO applications.

Confirmed PIAGGIO OE references are:

239391

482314

The identification paths are:

PIAGGIO 239391 -> CORTECO 12014151B

PIAGGIO 482314 -> CORTECO 12014151B

The OE numbers provide important additional identifiers when searching for or selecting this exact radial shaft seal.

Compatibility with a specific vehicle or assembly should be verified using the OE reference and relevant catalogue data.

CORTECO 12014151B Design Designation

Different catalogue sources use different construction descriptions for CORTECO 12014151B.

These include:

BAVILD

BAVILDSL*7

BASLX7

Because these designations are not consistent across the available sources, a single exact construction code should not be assigned without confirmation from current CORTECO technical documentation.

The characteristics that can be reliably established are:

19x30x6.5 mm dimensions

FPM sealing material

additional dust lip

CORTECO reference 12014151B

PIAGGIO OE 239391 and 482314

Selecting a Replacement for CORTECO 12014151B

When selecting a technically corresponding replacement, verify at least:

CORTECO reference: 12014151B

Base reference: 12014151

d - Shaft diameter: 19 mm

D - Outside diameter: 30 mm

B - Width: 6.5 mm

Material: FPM

Additional dust lip: Yes

OE PIAGGIO: 239391 / 482314

Seal construction

Application requirements

Matching only the 19 mm inside diameter and 30 mm outside diameter does not establish complete technical interchangeability.

CORTECO 12014151B vs Standard 19x30 Oil Seals

Other radial shaft oil seals are available with a 19 mm inside diameter and 30 mm outside diameter.

They should not automatically be treated as replacements for CORTECO 12014151B.

Important characteristics of this reference include:

19x30x6.5 mm dimensions

FPM material

additional dust lip

PIAGGIO OE references

The exact 6.5 mm width is particularly important because 19x30 mm seals can be available in different widths and constructions.

Technical Specification

Manufacturer: CORTECO

Part number: 12014151B

Base reference: 12014151

Product type: Radial shaft oil seal

Material: FPM

Material type: Fluoroelastomer

Dimensions: 19x30x6.5 mm

d - Inside diameter / nominal shaft diameter: 19 mm

D - Outside diameter: 30 mm

B - Width: 6.5 mm

Additional dust lip: Yes

OE PIAGGIO: 239391

OE PIAGGIO: 482314

EAN: 3358960342300

FAQ

What are the dimensions of CORTECO 12014151B?

CORTECO 12014151B measures 19x30x6.5 mm: 19 mm inside diameter, 30 mm outside diameter and 6.5 mm width.

What material is CORTECO 12014151B made from?

The seal is manufactured from FPM fluoroelastomer.

Does CORTECO 12014151B have a dust lip?

Yes. The seal is specified with an additional dust lip.

What PIAGGIO OE numbers correspond to CORTECO 12014151B?

The confirmed PIAGGIO OE references are 239391 and 482314.

What is the EAN of CORTECO 12014151B?

The EAN is 3358960342300.

Is CORTECO 12014151 the same reference as 12014151B?

12014151 appears as the base or older CORTECO reference, while 12014151B is the full current product reference used in parts catalogues.

Can a 19x30x7 oil seal replace CORTECO 12014151B?

Not automatically. CORTECO 12014151B has a specified width of 6.5 mm. Material, lip construction and application requirements must also be considered.

Can an NBR 19x30x6.5 oil seal replace CORTECO 12014151B?

This should not be assumed based on dimensions alone. CORTECO 12014151B is specified in FPM, so the sealing material and its compatibility with the operating conditions must also be considered.

AI Overview

CORTECO 12014151B is an FPM radial shaft oil seal measuring 19x30x6.5 mm. It incorporates an additional dust lip and is catalogued for PIAGGIO applications. The nominal shaft diameter is 19 mm, outside diameter 30 mm and width 6.5 mm. Confirmed PIAGGIO OE references are 239391 and 482314.
