CORTECO 12015254B 80x100x13/15 ACM B2SLSFDRWX6 Oil Seal

CORTECO 12015254B 80x100x13/15 ACM B2SLSFDRWX6 Oil Seal

CORTECO 12015254B is an 80x100x13/15 mm ACM radial shaft oil seal manufactured in the CORTECO B2SLSFDRWX6 design.

The seal is catalogued for SCANIA drivetrain applications and combines an additional dust lip with alternating hydrodynamic twist.

Product identification:

CORTECO 12015254B
Trade Number: 82015254
Dimensions: 80x100x13/15 mm
Material: ACM
Design: B2SLSFDRWX6
Dust Lip: Yes
Hydrodynamic Twist: Alternating
Application: SCANIA

CORTECO 12015254B Dimensions

The complete dimensional specification is:

80x100x13/15 mm

Shaft Diameter (d): 80 mm
Outside Diameter (D): 100 mm
Height H1: 13 mm
Overall Height H2: 15 mm

The complete 13/15 mm height specification is important.

CORTECO 12015254B should not be identified simply as an 80x100x13 mm oil seal, because the 15 mm overall height forms part of the B2SLSFDRWX6 geometry.

B2SLSFDRWX6 Oil Seal Design

The exact CORTECO design code is:

B2SLSFDRWX6

This code should be retained when identifying the seal or comparing alternatives.

For CORTECO 12015254B, the verified design characteristics include:

additional dust lip

alternating hydrodynamic twist

80x100x13/15 mm geometry

ACM sealing material

A generic 80x100 mm oil seal is therefore not automatically equivalent to CORTECO 12015254B.

Alternating Hydrodynamic Twist

CORTECO specifies alternating twist for 12015254B.

The sealing lip incorporates hydrodynamic features that are not limited to a single right-hand or left-hand direction.

This distinguishes the seal from directional designs such as a right-hand TCR or a left-hand TCL seal.

For replacement identification:

B2SLSFDRWX6 = alternating twist

The twist design is technically relevant and should be checked together with dimensions, material and lip configuration.

Additional Dust Lip

CORTECO 12015254B incorporates an additional dust lip.

The dust lip helps restrict external contamination from reaching the primary dynamic sealing interface.

This feature is relevant when comparing 12015254B with other seals having the same 80 mm shaft and 100 mm housing dimensions.

A replacement should therefore be checked for equivalent lip configuration rather than selected by dimensions alone.

ACM Polyacrylate Rubber

The specified elastomer is:

ACM - Polyacrylate Rubber

ACM is used in automotive and transmission sealing applications because of its resistance to many lubricating oils and its suitability for elevated-temperature oil environments.

It differs materially from standard NBR.

Consequently, an 80x100 mm NBR seal should not automatically be treated as a material-equivalent replacement for CORTECO 12015254B.

Actual compatibility depends on the lubricant formulation and operating conditions.

CORTECO 12015254B SCANIA Application

CORTECO 12015254B is catalogued for SCANIA applications.

It is used as a radial shaft oil seal within drivetrain / transmission-related assemblies, depending on the exact SCANIA configuration.

For vehicle identification, the OE reference should take priority over dimensional matching alone.

SCANIA OE References

CORTECO 12015254B is cross-referenced with the following SCANIA OE numbers:

SCANIA 124268
SCANIA 1242684
SCANIA 1305712
SCANIA 13057120
SCANIA 1335243
SCANIA 372791
SCANIA 3727914
SCANIA 388728
SCANIA 3887288

These OE numbers are important search and identification references for the exact SCANIA application.

CORTECO 12015254 vs 12015254B

The reference may be encountered in two forms:

12015254

12015254B

The older/base CORTECO reference is 12015254.

The current complete reference is:

12015254B

For current product identification and ordering, CORTECO 12015254B should be used as the primary reference.

The number 12015254 remains useful for older catalogue searches and cross-referencing.

CORTECO 12015254B Trade Number

CORTECO Trade Number:

82015254

Reference relationship:

12015254B = CORTECO Part Number

82015254 = CORTECO Trade Number

Both numbers should be indexed in the product description because technical catalogues and customers may search using either reference.

CORTECO 12015254B vs 80x100x13 NBR TCR

These two seals have similar nominal diameters but are technically different.

CORTECO 12015254B

Dimensions: 80x100x13/15 mm
Material: ACM
Design: B2SLSFDRWX6
Dust Lip: Yes
Twist: Alternating

80x100x13 NBR TCR

Dimensions: 80x100x13 mm
Material: NBR
Design: TCR
Dust Lip: Yes
Twist: Right-hand

The differences in material, overall geometry and hydrodynamic twist mean that these products should not be considered interchangeable solely because both fit nominal 80 mm shaft and 100 mm housing diameters.

How to Identify the Correct Replacement

Check all of the following parameters:

CORTECO Part Number: 12015254B
Trade Number: 82015254
Shaft Diameter: 80 mm
Outside Diameter: 100 mm
Height: 13/15 mm
Material: ACM
Design: B2SLSFDRWX6
Dust Lip: Yes
Hydrodynamic Twist: Alternating
OE Number: Matching SCANIA reference

The most reliable identification sequence is:

SCANIA OE -> CORTECO 12015254B -> 80x100x13/15 -> ACM -> B2SLSFDRWX6

Technical Specification

Manufacturer: CORTECO
Part Number: 12015254B
Older / Base Reference: 12015254
Trade Number: 82015254
Product Type: Radial shaft oil seal
Design: B2SLSFDRWX6
Material: ACM - Polyacrylate Rubber
Shaft Diameter: 80 mm
Outside Diameter: 100 mm
Height H1: 13 mm
Height H2: 15 mm
Dimensions: 80x100x13/15 mm
Additional Dust Lip: Yes
Hydrodynamic Twist: Alternating
Application: SCANIA drivetrain / transmission

SCANIA OE References:
124268
1242684
1305712
13057120
1335243
372791
3727914
388728
3887288

FAQ

What are the dimensions of CORTECO 12015254B?

The complete dimensions are 80x100x13/15 mm: 80 mm shaft diameter, 100 mm outside diameter, 13 mm H1 and 15 mm overall H2.

What material is CORTECO 12015254B made from?

The sealing material is ACM - Polyacrylate Rubber.

What is the CORTECO design code?

The exact design code is B2SLSFDRWX6.

Does CORTECO 12015254B have a dust lip?

Yes. The design incorporates an additional dust lip to help protect the primary sealing area against external contamination.

Is CORTECO 12015254B right-hand or left-hand?

Neither designation accurately describes this reference. CORTECO specifies alternating hydrodynamic twist rather than a single right-hand or left-hand twist.

Is CORTECO 12015254B an 80x100x13 oil seal?

Its complete dimensions are 80x100x13/15 mm. The 15 mm H2 dimension should not be omitted when identifying the seal.

Which SCANIA OE numbers correspond to CORTECO 12015254B?

OE references include 124268, 1242684, 1305712, 13057120, 1335243, 372791, 3727914, 388728 and 3887288.

What is the Trade Number for CORTECO 12015254B?

The CORTECO Trade Number is 82015254.
