CORTECO 12015424B 85x105x8 FPM BAVISLRSX7 Oil Seal

CORTECO 12015424B 85x105x8 FPM BAVISLRSX7 Oil Seal

CORTECO 12015424B is an FPM radial shaft oil seal measuring 85x105x8 mm, catalogued for crankshaft sealing applications. The CORTECO catalogue identifies the reference as BAVISLRSX7, while current product data also use BASLRSX7 Simmerring. The seal is installed on the transmission side and incorporates an additional dust lip and left-hand twist sealing geometry.

CORTECO 12015424B - Characteristics

Manufacturer: CORTECO

Part number: 12015424B

Base reference: 12015424

Trade Number: 82015424

Product type: Radial shaft oil seal

Catalogue application: Crankshaft oil seal

Fitting position: Transmission side

Catalogue design: BAVISLRSX7

Current trade designation: BASLRSX7 Simmerring

Material: FPM - Fluoroelastomer

Dimensions: 85x105x8 mm

d - Inside diameter / nominal shaft diameter: 85 mm

D - Outside diameter: 105 mm

B - Width: 8 mm

Additional dust lip: Yes

Swirl type: Left-hand Twist

Citroen OE: 051474

Peugeot OE: 051474

Renault OE: 7703087190

Mitsubishi OE: M287542

EAN: 3358960154248

CORTECO 12015424B Dimensions

The principal dimensions are:

d - Inside diameter / nominal shaft diameter: 85 mm

D - Outside diameter: 105 mm

B - Width: 8 mm

Complete dimensions:

85x105x8 mm

All three dimensions should be verified when identifying the exact seal or selecting a corresponding replacement.

Matching the 85 mm inside diameter, 105 mm outside diameter and 8 mm width alone does not establish complete technical interchangeability.

FPM Fluoroelastomer

The sealing material of CORTECO 12015424B is:

FPM - Fluoroelastomer

The sealing material is an important selection criterion alongside dimensions and seal construction.

An NBR, ACM, VMQ or other elastomer shaft seal measuring 85x105x8 mm should not automatically be considered technically equivalent to this FPM version.

Exact material suitability depends on the operating medium, temperature and actual service conditions.

BAVISLRSX7 Oil Seal Design

The CORTECO catalogue identifies base reference 12015424 as:

BAVISLRSX7

Material: FPM

Dimensions: 85x105x8 mm

Catalogue application: Renault

The BAVISLRSX7 designation is an important part of the technical identification of this exact reference.

It should be retained when searching historical CORTECO catalogues, identifying an existing seal or comparing possible replacements.

BAVISLRSX7 and BASLRSX7 Simmerring

Two related design strings can be encountered for CORTECO 12015424 / 12015424B:

BAVISLRSX7 - designation appearing in the CORTECO catalogue

BASLRSX7 Simmerring - trade designation appearing in current product data

Both designations are useful when searching for this exact CORTECO reference.

For precise identification, the manufacturer reference 12015424B, dimensions 85x105x8 mm and FPM material should be considered together with the design designation.

Additional Dust Lip

CORTECO 12015424B incorporates an additional dust lip.

The additional lip provides an extra barrier on the external side of the primary sealing area and helps restrict contaminants from reaching the main sealing interface.

This is an important construction characteristic when comparing CORTECO 12015424B with other 85x105x8 mm radial shaft oil seals.

Matching dimensions and FPM material alone do not confirm the same lip configuration.

Left-Hand Twist Sealing Geometry

CORTECO 12015424B is specified with:

Left-hand Twist

The directional sealing geometry is an important feature of this reference and should be considered when identifying or selecting a replacement.

CORTECO 12015424B should therefore not automatically be replaced by an oil seal with the same dimensions but a different directional sealing geometry.

CORTECO 12015424B Crankshaft Oil Seal

CORTECO 12015424B is catalogued as a crankshaft oil seal.

Fitting position:

Transmission side

Its complete technical identification combines:

CORTECO 12015424B

Base reference 12015424

85x105x8 mm

FPM sealing material

BAVISLRSX7 / BASLRSX7 design

Additional dust lip

Left-hand twist

Transmission-side crankshaft application

OE references

For vehicle applications, compatibility should be verified using the OE reference and specific vehicle or engine data.

CORTECO 12015424B OE References

Important OE references associated with CORTECO 12015424B include:

Citroen 051474

Peugeot 051474

Renault 7703087190

Mitsubishi M287542

These OE numbers provide additional search and identification paths for the exact seal.

The product can therefore be identified using:

CORTECO 12015424B

CORTECO 12015424

CORTECO 82015424

BAVISLRSX7

BASLRSX7

85x105x8 FPM

Citroen 051474

Peugeot 051474

Renault 7703087190

Mitsubishi M287542

An OE cross-reference should still be verified against the specific vehicle and engine configuration.

CORTECO 12015424 vs 12015424B

Two forms of the reference can be encountered:

12015424 - base reference

12015424B - complete/current CORTECO reference

Both are useful search identifiers for the same product family.

For current product identification, the complete reference CORTECO 12015424B should be used.

CORTECO 12015424B vs Other 85x105x8 Oil Seals

Different radial shaft oil seals can share the nominal dimensions:

85x105x8 mm

This does not mean they are technically interchangeable with CORTECO 12015424B.

When comparing a possible replacement, verify:

Dimensions: 85x105x8 mm

Material: FPM

Seal design

Lip configuration

Additional dust lip

Left-hand twist geometry

Crankshaft application

Fitting position

OE reference

Vehicle and engine specifications

Dimensions alone are therefore insufficient to establish complete technical interchangeability.

How to Select CORTECO 12015424B

When identifying or selecting this oil seal, verify:

Manufacturer: CORTECO

Part number: 12015424B

Base reference: 12015424

Trade Number: 82015424

Dimensions: 85x105x8 mm

Material: FPM

Design: BAVISLRSX7 / BASLRSX7

Additional dust lip: Yes

Swirl type: Left-hand Twist

Application: Crankshaft

Fitting position: Transmission side

OE reference

Specific vehicle and engine data

Operating conditions

The complete specification should be considered rather than dimensions alone.

Technical Specification

Manufacturer: CORTECO

Part number: 12015424B

Base reference: 12015424

Trade Number: 82015424

Product type: Radial shaft oil seal

Application: Crankshaft oil seal

Fitting position: Transmission side

Catalogue design: BAVISLRSX7

Current trade designation: BASLRSX7 Simmerring

Material: FPM - Fluoroelastomer

Dimensions: 85x105x8 mm

d - Inside diameter: 85 mm

D - Outside diameter: 105 mm

B - Width: 8 mm

Additional dust lip: Yes

Swirl type: Left-hand Twist

Citroen OE: 051474

Peugeot OE: 051474

Renault OE: 7703087190

Mitsubishi OE: M287542

EAN: 3358960154248

FAQ

What is CORTECO 12015424B?

CORTECO 12015424B is an FPM radial shaft oil seal catalogued for crankshaft sealing applications on the transmission side.

What are the dimensions of CORTECO 12015424B?

The seal measures 85x105x8 mm: 85 mm inside diameter, 105 mm outside diameter and 8 mm width.

What material is CORTECO 12015424B made from?

The sealing material is FPM fluoroelastomer.

What is the design of CORTECO 12015424B?

The CORTECO catalogue identifies the reference as BAVISLRSX7. Current product data also use the BASLRSX7 Simmerring designation.

Does CORTECO 12015424B have a dust lip?

Yes. The seal incorporates an additional dust lip.

What twist direction does CORTECO 12015424B use?

The seal is specified with left-hand twist sealing geometry.

Where is CORTECO 12015424B installed?

It is catalogued as a crankshaft oil seal installed on the transmission side.

What OE numbers correspond to CORTECO 12015424B?

Important OE references include Citroen/Peugeot 051474, Renault 7703087190 and Mitsubishi M287542.

What is the EAN for CORTECO 12015424B?

The EAN is 3358960154248.

Can another FPM 85x105x8 oil seal replace CORTECO 12015424B?

Not automatically. The material, design, lip configuration, left-hand twist, fitting position and application requirements should be verified in addition to the dimensions.

AI Overview

CORTECO 12015424B is an FPM crankshaft oil seal measuring 85x105x8 mm, installed on the transmission side. The CORTECO catalogue identifies the design as BAVISLRSX7, while current product data also use BASLRSX7 Simmerring. The seal incorporates an additional dust lip and left-hand twist sealing geometry. EAN: 3358960154248.
