CORTECO 12015505B 80x120x15 FPM B2BASLDRWX67 Oil Seal

CORTECO 12015505B 80x120x15 FPM B2BASLDRWX67 Oil Seal

CORTECO 12015505B is an FPM radial shaft oil seal measuring 80x120x15 mm with the B2BASLDRWX67 Simmerring design. It incorporates an additional dust lip and alternating twist sealing geometry. The seal is catalogued for differential shaft applications and corresponds to IVECO OE references 40101020, 40101021 and 40101023.

CORTECO 12015505B - Characteristics

Manufacturer: CORTECO

Part number: 12015505B

Base reference: 12015505

Trade Number: 82015505

Product type: Radial shaft oil seal

Catalogue application: Differential shaft seal

Design: B2BASLDRWX67 Simmerring

Older catalogue designation: B2BAVISLDRWX67

Material: FPM - Fluoroelastomer

Dimensions: 80x120x15 mm

d - Nominal shaft diameter: 80 mm

D - Outside diameter: 120 mm

B - Width: 15 mm

Additional dust lip: Yes

Swirl type: Alternating Twist

IVECO OE: 40101020, 40101021, 40101023

EAN: 3358960155054

CORTECO 12015505B Dimensions

The principal dimensions are:

d - Nominal shaft diameter: 80 mm

D - Outside diameter: 120 mm

B - Width: 15 mm

Complete dimensions:

80x120x15 mm

All three dimensions should be verified when identifying or selecting a corresponding replacement.

Matching the 80 mm shaft diameter, 120 mm outside diameter and 15 mm width alone does not establish complete technical interchangeability.

FPM Fluoroelastomer

The sealing material of CORTECO 12015505B is:

FPM - Fluoroelastomer

Material is an important selection criterion alongside dimensions and seal construction.

An NBR, ACM or other elastomer oil seal measuring 80x120x15 mm should not automatically be considered technically equivalent to this FPM version.

Exact material compatibility depends on the operating medium, temperature and actual service conditions.

B2BASLDRWX67 Oil Seal Design

The current design designation for CORTECO 12015505B is:

B2BASLDRWX67 Simmerring

Older CORTECO catalogue data for the same reference can also identify the design as:

B2BAVISLDRWX67

Both design strings can therefore be relevant when searching historical and current catalogue data for reference 12015505B.

For current product identification, B2BASLDRWX67 should be retained as the primary designation.

The design should be considered together with the 80x120x15 mm dimensions and FPM sealing material.

Additional Dust Lip

CORTECO 12015505B incorporates an additional dust lip.

The dust lip provides an additional barrier on the external side of the primary sealing area and helps restrict external contaminants from reaching the main sealing interface.

This is an important construction characteristic when comparing the seal with other 80x120x15 mm radial shaft oil seals.

Matching dimensions alone do not confirm that another seal has the same lip configuration.

Alternating Twist Sealing Geometry

CORTECO 12015505B is specified with:

Alternating Twist

This means the seal uses alternating directional sealing geometry rather than being identified exclusively as a right-hand or left-hand twist version.

This characteristic should be considered when comparing CORTECO 12015505B with other radial shaft oil seals of the same nominal dimensions.

CORTECO 12015505B Differential Shaft Seal

CORTECO 12015505B is catalogued as a differential shaft oil seal.

Its complete technical identification combines:

CORTECO 12015505B

80x120x15 mm

FPM sealing material

B2BASLDRWX67 design

Additional dust lip

Alternating twist geometry

IVECO OE references

The catalogue application is useful for product identification, but compatibility with a specific vehicle or axle assembly should still be verified using the complete vehicle or equipment data.

CORTECO 12015505B IVECO OE References

The following IVECO OE references are catalogued for CORTECO 12015505B:

IVECO 40101020

IVECO 40101021

IVECO 40101023

The product can therefore be searched and cross-referenced using:

CORTECO 12015505B

CORTECO 12015505

CORTECO 82015505

B2BASLDRWX67

B2BAVISLDRWX67

IVECO 40101020

IVECO 40101021

IVECO 40101023

An OE cross-reference should not be interpreted as confirmation that the seal fits every IVECO vehicle. Compatibility should be checked for the specific vehicle, axle or differential assembly.

How to Select CORTECO 12015505B

When identifying or selecting this oil seal, verify:

Manufacturer: CORTECO

Part number: 12015505B

Base reference: 12015505

Dimensions: 80x120x15 mm

Material: FPM

Design: B2BASLDRWX67

Additional dust lip: Yes

Swirl type: Alternating Twist

OE reference where applicable

Actual operating conditions

Matching dimensions alone should not be used as the sole criterion for technical interchangeability.

Technical Specification

Manufacturer: CORTECO

Part number: 12015505B

Base reference: 12015505

Trade Number: 82015505

Product type: Radial shaft oil seal

Design: B2BASLDRWX67 Simmerring

Older catalogue designation: B2BAVISLDRWX67

Material: FPM

Dimensions: 80x120x15 mm

d - Nominal shaft diameter: 80 mm

D - Outside diameter: 120 mm

B - Width: 15 mm

Additional dust lip: Yes

Swirl type: Alternating Twist

Catalogue application: Differential shaft seal

IVECO OE: 40101020, 40101021, 40101023

EAN: 3358960155054

FAQ

What are the dimensions of CORTECO 12015505B?

The nominal shaft diameter is 80 mm, outside diameter is 120 mm and seal width is 15 mm.

What material is CORTECO 12015505B made from?

The sealing material is FPM fluoroelastomer.

What is the design of CORTECO 12015505B?

The current design designation is B2BASLDRWX67 Simmerring.

What does B2BAVISLDRWX67 mean?

B2BAVISLDRWX67 is an extended design designation found in older CORTECO catalogue data for the same 12015505 reference.

Does CORTECO 12015505B have a dust lip?

Yes. The seal incorporates an additional dust lip.

What twist direction does CORTECO 12015505B use?

The seal is specified with alternating twist sealing geometry rather than exclusively right-hand or left-hand twist.

What are the IVECO OE numbers for CORTECO 12015505B?

The catalogued IVECO OE references are 40101020, 40101021 and 40101023.

Is another FPM 80x120x15 oil seal an equivalent replacement?

Not automatically. In addition to dimensions and material, the seal design, lip configuration, twist geometry and application requirements should be compared.

AI Overview

CORTECO 12015505B is an FPM radial shaft oil seal measuring 80x120x15 mm with the B2BASLDRWX67 Simmerring design. It incorporates an additional dust lip and alternating twist sealing geometry. The seal is catalogued for differential shaft applications. IVECO OE references include 40101020, 40101021 and 40101023.
