CORTECO 12015557 57x71x7 ACM BASLDRWX7 - Differential Shaft Oil Seal

CORTECO 12015557 57x71x7 ACM BASLDRWX7 - Differential Shaft Oil Seal

CORTECO 12015557 is a radial shaft seal with dimensions 57x71x7 mm, manufactured from ACM and featuring the BASLDRWX7 design. The seal is catalogued for selected Volkswagen Group drivetrain applications, including differential shaft sealing. The reference is also found as 12015557B and commercial reference 82015557.

CORTECO 12015557 - Technical Data

Dimensions

The principal dimensions are:

57x71x7 mm

• shaft diameter: 57 mm

• housing bore diameter: 71 mm

• seal width: 7 mm

When selecting an equivalent seal, the dimensions alone are not sufficient. The ACM material, BASLDRWX7 design and application requirements should also be verified.

ACM Material

CORTECO 12015557 is manufactured from ACM, an acrylic rubber commonly used for sealing applications in automotive drivetrains, transmissions and related assemblies.

The ACM material is part of the specified construction of this CORTECO seal and should be considered when selecting a replacement.

A seal with the same 57x71x7 mm dimensions but a different elastomer should not automatically be considered equivalent.

BASLDRWX7 Design

The CORTECO catalogue identifies the seal design as:

BASLDRWX7

This profile incorporates the specific sealing geometry required for the intended application, including an additional dust lip.

For replacement purposes, the complete profile and material should be considered together with the dimensions.

Differential Shaft Application

CORTECO catalogues associate reference 12015557 with Volkswagen applications, while product catalogue data identifies the sealing position as a VAG differential shaft.

The seal is also listed in aftermarket catalogues for selected Audi, SEAT and Volkswagen drivetrain and differential applications.

Exact vehicle compatibility should always be confirmed using the OE reference, transmission version and VIN.

OE References

CORTECO 12015557 / 12015557B is cross-referenced with OE numbers including:

• AUDI 084409189C

• SEAT 084409189C

• VW 084409189C

• VW 084409189A

• VW 02D525597

OE numbers provide an important additional identification method when selecting the seal for a specific vehicle or drivetrain assembly.

Alternative References

The product can also be searched using:

• CORTECO 12015557

• CORTECO 12015557B

• CORTECO 82015557

• BASLDRWX7

• 084409189C

• 084409189A

• 02D525597

• FEBI BILSTEIN 15287

• SWAG 30 91 5287

• TOPRAN 107 443

• VAICO V10-9776

Cross-references should be treated as identification aids. Full technical compatibility should be confirmed before installation.

Selection and Interchangeability

Before replacing CORTECO 12015557, verify:

1. Dimensions 57x71x7 mm.

2. ACM material.

3. BASLDRWX7 design.

4. Sealing lip construction.

5. Additional dust lip.

6. OE reference.

7. Installation position.

8. Transmission or differential version.

Another 57x71x7 mm oil seal is not automatically a direct replacement for CORTECO 12015557.

Material, profile and application requirements must also match.

Installation

Before installation:

• clean the shaft and housing bore

• inspect the shaft sealing surface

• remove contamination and burrs

• check the housing seat

• protect the sealing lip from sharp edges

• use an appropriate seal installation tool

• press the seal evenly into the housing

• avoid deformation of the seal body

• install the seal in the correct orientation

The sealing lip must not be damaged during assembly.

FAQ

What are the dimensions of CORTECO 12015557?

CORTECO 12015557 has dimensions of 57x71x7 mm: 57 mm shaft diameter, 71 mm housing bore diameter and 7 mm width.

What material is CORTECO 12015557 made from?

The seal is manufactured from ACM acrylic rubber.

What is the design of CORTECO 12015557?

The CORTECO design designation is BASLDRWX7.

Where is CORTECO 12015557 used?

CORTECO catalogues associate the seal with Volkswagen applications, including VAG differential shaft sealing. Exact compatibility should be verified using the OE number and vehicle data.

Is 12015557B related to 12015557?

Yes. The product is also found in current aftermarket catalogues under reference 12015557B with the same 57x71x7 mm dimensions, ACM material and BASLDRWX7 design.

What is the commercial reference for CORTECO 12015557?

The commercial reference associated with the product is 82015557.

Does CORTECO 12015557 have a dust lip?

Yes. Catalogue data specifies an additional dust protection lip.

Can any 57x71x7 oil seal replace CORTECO 12015557?

No. Dimensions alone do not confirm interchangeability. The ACM material, BASLDRWX7 profile, sealing construction and application requirements must also be verified.

CORTECO 12015557 - Quick Technical Answer

CORTECO 12015557 is a 57x71x7 mm radial shaft seal manufactured from ACM with BASLDRWX7 design and an additional dust lip. It is catalogued for selected Volkswagen Group differential shaft applications. Related references include 12015557B and 82015557, with OE numbers 084409189C, 084409189A and 02D525597.
