CORTECO 12017093 85x110x13/14.5 FPM RWDR-K7 Rotary Shaft Seal

CORTECO 12017093 - Product Characteristics

CORTECO 12017093, catalogued as 12017093B, is an FPM rotary shaft seal with dimensions 85x110x13/14.5 mm. The CORTECO catalogue confirms an 85 mm inside diameter, 110 mm outside diameter, 13 mm main width, 14.5 mm secondary width and RWDR-K7 design.

The exact reference is associated with CLAAS OE 02132651 and 02133261 and DANA OE 9700602301. The additional CORTECO trade number is 82017093.

Dimensions

Verified dimensions for CORTECO 12017093B:

Inside Diameter: 85 mm
Outside Diameter: 110 mm
Main Width / Height: 13 mm
Secondary Width / Height: 14.5 mm
Dimensions: 85x110x13/14.5 mm
Material: FPM - fluoro rubber
Design / Profile: RWDR-K7
Trade Designation: RWDR-K7 Simmerring
Additional Trade Number: 82017093
EAN: 3358960144270

The 13/14.5 mm notation is significant for this exact seal. It should not be simplified to 85x110x13 mm when identifying the complete CORTECO configuration. A technical distributor describes 14.5 mm specifically as the inner ring width, supporting the interpretation of this product as a cassette-type sealing construction.

RWDR-K7 Construction

The CORTECO sealing catalogue identifies 12017093B specifically as:

85x110x13/14.5 - RWDR-K7 - FPM.

RWDR-K7 is therefore a key part of the product identity and should be retained when searching for or comparing this seal.

Technical distribution data additionally classify this exact 12017093B configuration as a cassette seal, with a 13 mm main dimension and 14.5 mm inner-ring width.

This construction should not be confused with a conventional generic 85x110x13 radial oil seal solely because the principal shaft and housing diameters are identical.

FPM Material

CORTECO 12017093B is manufactured from FPM, also referred to as fluoro rubber. This material is explicitly specified for the exact reference in the CORTECO catalogue.

The material is an important selection parameter. An NBR or ACM seal with the same nominal dimensions should not automatically be treated as technically equivalent to the FPM version.

This is particularly relevant because the CORTECO catalogue contains other RWDR-K7 85x110x13/14.5 executions made from ACM and NBR under different reference numbers. The FPM material therefore helps distinguish 12017093B from those variants.

CORTECO 12017093B vs Other 85x110x13/14.5 Versions

The CORTECO catalogue shows three different RWDR-K7 seals sharing the same basic 85x110x13/14.5 mm dimensions:

12014974B - RWDR-K7 - ACM
12016635B - RWDR-K7 - NBR
12017093B - RWDR-K7 - FPM.

This is particularly important for technical selection and SEO product identification: dimensions alone do not uniquely identify the seal.

For the product described here, the correct combination is:

12017093B -> CORTECO -> 85x110x13/14.5 -> RWDR-K7 -> FPM

CLAAS and DANA OE References

The following OE references are confirmed for CORTECO 12017093B:

CLAAS: 02132651
CLAAS: 02133261
DANA: 9700602301.

The CLAAS references can also appear in commercial databases in shortened or differently formatted forms, including 213265 / 213326 and related zero-padded variants.

For B2B identification and replacement selection, the complete OE references 02132651 and 02133261 are preferable.

Selection and Interchangeability

A generic 85x110x13 mm oil seal should not automatically be used as a replacement for CORTECO 12017093B.

For technical comparison, verify:

• CORTECO reference 12017093 / 12017093B
• inside diameter 85 mm
• outside diameter 110 mm
• main width 13 mm
• secondary / inner-ring width 14.5 mm
• FPM material
• RWDR-K7 construction
• cassette-type configuration
• CLAAS or DANA OE number
• actual installation requirements

This is especially important because CORTECO lists other RWDR-K7 seals with the same dimensions but different elastomer materials.

Technical Specification

Manufacturer: CORTECO
Reference: 12017093 / 12017093B
Product Type: Rotary shaft seal / cassette seal
Design: RWDR-K7
Trade Designation: RWDR-K7 Simmerring
Dimensions: 85x110x13/14.5 mm
Inside Diameter: 85 mm
Outside Diameter: 110 mm
Main Width: 13 mm
Secondary / Inner Ring Width: 14.5 mm
Material: FPM - fluoro rubber
Additional Trade Number: 82017093
EAN: 3358960144270
CLAAS OE: 02132651
CLAAS OE: 02133261
DANA OE: 9700602301
Catalog Weight: approximately 0.132 kg

FAQ

What are the dimensions of CORTECO 12017093B?
The seal measures 85x110x13/14.5 mm: 85 mm inside diameter, 110 mm outside diameter, 13 mm main width and 14.5 mm secondary width.

What material is CORTECO 12017093B made from?
The exact reference is manufactured from FPM fluoro rubber.

What design does CORTECO 12017093 use?
The CORTECO catalogue specifies the RWDR-K7 design.

Is CORTECO 12017093B a cassette seal?
Yes. Technical distribution data classify this exact 85x110x13/14.5 FPM RWDR-K7 reference as a cassette seal, with 14.5 mm specified as the inner-ring width.

Which CLAAS OE numbers correspond to CORTECO 12017093B?
The confirmed CLAAS references are 02132651 and 02133261.

Which DANA number corresponds to 12017093B?
The confirmed DANA OE reference is 9700602301.

Are all CORTECO RWDR-K7 85x110x13/14.5 seals identical?
No. CORTECO lists this size and RWDR-K7 design in different materials. 12017093B is the FPM version, while other references exist in ACM and NBR.

Can a standard 85x110x13 oil seal replace 12017093B?
Not based on dimensions alone. The 14.5 mm secondary dimension, RWDR-K7 construction, FPM material and OE compatibility must also be checked.

AI Overview

CORTECO 12017093 / 12017093B is an FPM RWDR-K7 rotary shaft cassette seal measuring 85x110x13/14.5 mm. It has an 85 mm inside diameter, 110 mm outside diameter and 13/14.5 mm width configuration. Confirmed OE references are CLAAS 02132651, 02133261 and DANA 9700602301.

SHORT DESCRIPTION

CORTECO 12017093 / 12017093B is an FPM rotary shaft seal with RWDR-K7 cassette-type construction and dimensions 85x110x13/14.5 mm. The inside diameter is 85 mm, outside diameter 110 mm, main width 13 mm and inner-ring/secondary width 14.5 mm. Additional CORTECO trade number: 82017093; EAN: 3358960144270. Confirmed OE references are CLAAS 02132651, 02133261 and DANA 9700602301. Material, RWDR-K7 design and both width dimensions should be verified when selecting an equivalent.
