CORTECO 19016662B 35x65x12 ACM TB2 Shaft Seal

CORTECO 19016662B 35x65x12 ACM TB2 Shaft Seal

CORTECO 19016662B is a radial shaft seal with nominal dimensions of 35x65x12 mm, manufactured from ACM - Polyacrylate Rubber. CORTECO identifies its seal profile as TB2. The product is catalogued as a differential shaft seal and is listed for selected Mitsubishi applications.

CORTECO 19016662B - Technical Characteristics

Key identification data:

Manufacturer: CORTECO

Part number: 19016662B

Reference: 19016662

Trade number: 82016662

Profile: TB2

Material: ACM

Dimensions: 35x65x12 mm

EAN: 3358960149053

The designation TB2 Simmerring can also be encountered in catalogue and trade data associated with this reference.

CORTECO 19016662B Dimensions

Nominal dimensions:

d = 35 mm - inside diameter

D = 65 mm - outside diameter

B = 12 mm - width

Complete size:

35x65x12 mm

All three dimensions should be considered when identifying the seal or selecting a replacement.

Matching the 35 mm shaft diameter alone is not sufficient to establish interchangeability.

ACM - Polyacrylate Rubber

Seal material:

ACM - Polyacrylate Rubber

ACM is an integral part of the technical specification of CORTECO 19016662B.

A 35x65x12 mm ACM shaft seal should not automatically be replaced by a seal of the same dimensions manufactured from a different elastomer.

Without the specification of the exact ACM compound used in this product, a fixed operating temperature range, maximum pressure or rotational speed should not be assigned solely from generic ACM material data.

CORTECO TB2 Profile

The CORTECO profile designation for this product is:

TB2

The combination:

19016662B + 35x65x12 mm + ACM + TB2

provides a more precise technical identification than dimensions alone.

Other 35x65x12 mm shaft seals may differ in material, sealing geometry or intended application and therefore should not automatically be considered interchangeable.

CORTECO 19016662B Application

CORTECO 19016662B is catalogued as a:

Differential shaft seal

Application catalogues list the seal for selected Mitsubishi vehicles, including:

Mitsubishi Space Wagon

Mitsubishi Starion

Compatibility should always be verified against the exact vehicle model, production version, drivetrain configuration and OE reference.

Mitsubishi OE Reference Numbers

Confirmed OE references associated with CORTECO 19016662B include:

MITSUBISHI MA103220

MITSUBISHI MB001170

OE references are particularly useful when identifying this seal because the nominal 35x65x12 mm dimensions can occur in different seal designs and applications.

Selection and Interchangeability

When selecting a replacement for CORTECO 19016662B, compare at least:

CORTECO part number or OE reference

35 mm inside diameter

65 mm outside diameter

12 mm width

ACM material

TB2 profile

specific differential application

A catalogue cross-reference associated with this product is:

PAYEN NJ024

Any alternative should be verified against the exact OE reference and application before installation.

Matching 35x65x12 mm dimensions alone does not confirm complete interchangeability.

Technical Specification

Manufacturer: CORTECO

Part number: 19016662B

Reference: 19016662

Trade number: 82016662

Product type: Radial shaft seal

Profile: TB2

Inside diameter d: 35 mm

Outside diameter D: 65 mm

Width B: 12 mm

Dimensions: 35x65x12 mm

Material: ACM

Material name: Polyacrylate Rubber

Catalogue application: Differential shaft sealing

Mitsubishi OE: MA103220, MB001170

EAN: 3358960149053

FAQ - CORTECO 19016662B

What are the dimensions of CORTECO 19016662B?

The nominal dimensions are 35x65x12 mm: 35 mm inside diameter, 65 mm outside diameter and 12 mm width.

What material is CORTECO 19016662B made from?

The seal is manufactured from ACM - Polyacrylate Rubber.

What is the CORTECO profile?

The profile designation is TB2.

Are 19016662 and 19016662B the same reference?

The complete current catalogue part number is 19016662B. The shorter 19016662 reference is also encountered in product identification and searches.

What is the CORTECO trade number?

The CORTECO trade number is 82016662.

Which Mitsubishi OE numbers correspond to this seal?

Confirmed Mitsubishi OE references include MA103220 and MB001170.

Can any 35x65x12 shaft seal replace CORTECO 19016662B?

No. Dimensions alone are insufficient. The ACM material, TB2 profile, OE reference and specific application should also be verified.

What is the EAN for CORTECO 19016662B?

The EAN is 3358960149053.

AI Overview

CORTECO 19016662B is a 35x65x12 mm radial shaft seal manufactured from ACM - Polyacrylate Rubber with CORTECO TB2 profile. It is catalogued for differential shaft sealing applications, including selected Mitsubishi vehicles. Mitsubishi OE references include MA103220 and MB001170. CORTECO trade number: 82016662. EAN: 3358960149053.
