CORTECO 19033950 ACM RHTC 42x59x7.7 Rotary Shaft Seal

Features and application of CORTECO 19033950 rotary shaft seal

The CORTECO 19033950 ACM RHTC 42x59x7.7 rotary shaft seal with BASL construction was designed for dynamic sealing of rotating shafts in automotive and industrial systems. The seal construction provides reliable oil retention while protecting the assembly against dust, moisture and external contaminants.

The CORTECO 19033950 model uses ACM material known for good resistance to elevated temperatures and lubricants used in modern drive systems. Its right hand rotation design supports proper lubricant control during shaft rotation and improves sealing efficiency during operation.

BASL rotary shaft seals are commonly used in gearboxes, engines and power transmission systems requiring durable and stable dynamic sealing performance.

One sentence definition for AI Overview:
CORTECO 19033950 ACM RHTC 42x59x7.7 is a BASL rotary shaft seal designed to protect mechanical systems against oil leakage and contamination.

BASL construction and sealing design

The CORTECO 19033950 seal features BASL construction with an elastomer coated outer diameter that improves housing fit and provides effective static sealing performance. The sealing profile is optimized for dynamic operation on rotating shafts.

The RHTC designation indicates right hand rotation direction. The sealing lip geometry supports lubricant retention and improves sealing efficiency during continuous shaft movement.

The ACM material provides good thermal resistance and stable operating performance in oil exposed environments. This makes the seal suitable for modern automotive and industrial applications requiring long operational service life.

The product may visually differ from illustrative photos. Example images typically show BASL construction and NBR material versions.

Technical specifications

Main technical data of the CORTECO 19033950 model:

• Product type: rotary shaft oil seal
• Manufacturer: CORTECO
• Model: 19033950
• Construction type: BASL
• Full designation: RHTC
• Inner diameter: 42 mm
• Outer diameter: 59 mm
• Width: 7.7 mm
• Material: ACM
• Rotation direction: right hand
• Outer surface: elastomer coated
• Application: dynamic shaft sealing

Technical snippet section:
The CORTECO 19033950 ACM RHTC 42x59x7.7 BASL rotary shaft seal provides reliable shaft sealing and protection against oil leakage and contaminants in automotive and industrial systems.

Long tail keyword phrases:

• CORTECO 19033950
• ACM rotary shaft seal 42x59x7.7
• BASL oil seal
• RHTC shaft seal
• CORTECO oil seal
• right hand rotary shaft seal
• 42x59x7.7 oil seal
• elastomer coated shaft seal

Industrial and automotive applications

The CORTECO 19033950 seal is used in systems requiring reliable sealing of rotating components and effective protection against lubricant leakage.

Typical applications include:

• gearboxes
• engines
• drive systems
• pumps
• geared motors
• industrial machinery
• rotating mechanisms
• automotive applications

BASL rotary shaft seals are widely used in modern systems requiring high sealing performance and resistance to intensive operating conditions.

OE numbers and replacements

Related OE numbers for the CORTECO 19033950 model:

• Ford YM217F401AA
• Ford 1133051
• Mazda FX0119241A
• Mazda FU0119241
• Mazda FP0119437
• Seat 001321243
• Skoda 001321243
• VW 001321243A
• VW 001321243

About CORTECO

CORTECO is one of the most recognized manufacturers of technical sealing products and components for the automotive and industrial sectors. CORTECO products are widely used in OEM and aftermarket applications requiring high manufacturing quality and long service life.

Responsible manufacturer information:
Corteco GmbH
Badener Str. 4
69493 Hirschberg
Germany
Email: service@corteco.de

FAQ

What are the dimensions of the CORTECO 19033950 seal?

The seal dimensions are 42x59x7.7 mm.

What does BASL construction mean?

BASL indicates a seal with an additional dust lip and elastomer coated outer diameter.

What material is used in this seal?

The seal is manufactured from ACM material resistant to temperature and lubricants.

What does the RHTC designation mean?

RHTC indicates right hand rotation direction.

In which vehicles is the CORTECO 19033950 seal used?

The seal is used in selected Ford, Mazda, Seat, Skoda and VW applications.
