CORTECO 19035249 ACM RHTC 26x40x7 mm Radial Shaft Seal

CORTECO 19035249 ACM RHTC 26x40x7 mm Radial Shaft Seal

CORTECO 19035249 is an ACM radial shaft seal with dimensions 26x40x7 mm and CORTECO profile RHTC. The seal has a 26 mm inner diameter, 40 mm outer diameter and 7 mm width. Its construction features a right-hand directional sealing structure, making the direction-specific design an important parameter when selecting an equivalent seal.

Technical Data - CORTECO 19035249

What Does CORTECO 19035249 ACM RHTC Mean?

19035249 is the CORTECO reference identifying this specific radial shaft seal.

ACM identifies the elastomer material - polyacrylate rubber.

RHTC is the CORTECO profile designation assigned to this particular seal construction.

Catalog data for this product also specifies a right-hand directional sealing structure.

The complete RHTC designation should be retained when identifying or comparing this seal. Individual letters in the profile should not be decoded using terminology from other seal manufacturers, because radial shaft seal profile nomenclature is not universal across brands.

ACM Polyacrylate Rubber

CORTECO 19035249 is manufactured from ACM polyacrylate rubber.

ACM is an elastomer used in technical radial shaft seals, particularly where suitable resistance to certain oils and elevated operating temperatures is required.

The material should be treated as an integral part of the product specification.

An NBR, FKM or other elastomer seal measuring 26x40x7 mm should not automatically be considered equivalent to CORTECO 19035249.

Material selection should take into account:

• operating medium,
• temperature,
• shaft speed,
• operating conditions,
• seal arrangement,
• equipment or vehicle manufacturer requirements.

A universal operating temperature range should not be assigned to this specific CORTECO reference solely from general ACM material properties.

CORTECO 19035249 Dimensions

Confirmed dimensions are:

• inner diameter: 26 mm
• outer diameter: 40 mm
• width: 7 mm

Complete dimensions:

26x40x7 mm

The 26 mm inner diameter corresponds to the nominal shaft diameter, while the 40 mm outer diameter corresponds to the nominal housing bore.

RHTC Profile and Right-Hand Directional Structure

One of the most important identification features of CORTECO 19035249 is its RHTC profile.

Catalog information specifies a right-hand directional sealing structure for this product.

This is a construction feature of the seal and should not be confused with a conventional screw thread used to install a component.

A directional sealing structure can be designed to interact with the rotating shaft and support the sealing function for the intended direction of rotation.

For this reason, replacement selection should consider not only:

26x40x7 mm + ACM

but also:

RHTC profile + directional sealing structure

Why Is the Directional Structure Important?

Radial shaft seals may incorporate directional features designed for a specific direction of shaft rotation.

Therefore, an ACM seal with identical 26x40x7 mm dimensions but a different directional structure should not automatically be considered a direct replacement for CORTECO 19035249.

For this product, the directional design forms part of its technical identification.

CORTECO 19035249 vs CORTECO 19026199

The CORTECO dimensional catalogue also contains 19026199 ACM LHTC 26x42x7 mm.

This provides a useful example of why complete product identification matters.

CORTECO 19035249:

ACM RHTC 26x40x7 mm

CORTECO 19026199:

ACM LHTC 26x42x7 mm

The products differ in both outer diameter and directional profile.

A replacement should therefore never be selected solely from the shaft diameter.

OEM References for CORTECO 19035249

Confirmed OE references associated with the current CORTECO 19035249B listing include:

HONDA 91216-PHR-003

MINI 23 11 7 518 633

OEM numbers provide an important additional identification method when searching for the correct radial shaft seal.

However, an OEM reference does not mean universal compatibility with every vehicle from that manufacturer. Fitment should be verified using the OE number, vehicle model, drivetrain specification or appropriate parts documentation.

Applications of CORTECO 19035249

The CORTECO catalogue associates reference 19035249 with HONDA applications.

Current aftermarket catalogues classify CORTECO 19035249B as a transmission shaft seal.

Depending on vehicle specification, catalog listings may include selected versions of models such as:

• Honda Civic VII Sedan,
• Honda Insight,
• Honda Jazz II.

Compatibility with a specific vehicle should always be confirmed using the OEM number, model, engine, transmission and vehicle-specific catalogue data.

Alternative References and Search Terms

The product may be searched using the following references:

CORTECO 19035249

19035249 CORTECO

CORTECO 19035249B

19035249B CORTECO

CORTECO 82035249

82035249 CORTECO

CORTECO RHTC 26x40x7

CORTECO 19035249 ACM

CORTECO 19035249 RHTC

CORTECO 19035249 26x40x7

19035249 ACM RHTC

Simmerring 26x40x7 ACM

Oil seal 26x40x7 ACM

Radial shaft seal 26x40x7 ACM

HONDA 91216-PHR-003

MINI 23 11 7 518 633

Searching by the CORTECO reference or confirmed OEM number normally provides more precise identification than searching by dimensions alone.

CORTECO 19035249 vs 19035249B

The CORTECO dimensional catalogue lists:

19035249

Current aftermarket catalogues may list:

19035249B

as well as commercial number:

82035249

For product identification and online searches, it is therefore useful to consider both reference formats while confirming the core specification:

26x40x7 mm + ACM + RHTC

How to Select a Replacement for CORTECO 19035249

When comparing an alternative radial shaft seal, verify at least:

• 26 mm shaft diameter,
• 40 mm housing bore,
• 7 mm width,
• ACM material,
• RHTC profile,
• right-hand directional sealing structure,
• operating medium,
• operating temperature,
• shaft rotation direction,
• shaft speed,
• equipment or vehicle manufacturer requirements.

If the seal is being identified by an OEM number, also compare HONDA 91216-PHR-003 or MINI 23 11 7 518 633.

Can a Standard 26x40x7 Oil Seal Replace CORTECO 19035249?

Interchangeability cannot be confirmed from dimensions alone.

CORTECO 19035249 has the specific combination:

26x40x7 mm + ACM + RHTC + right-hand directional sealing structure

Another 26x40x7 mm radial shaft seal may have a different elastomer or construction.

The nominal dimensions are therefore not sufficient on their own to confirm a replacement.

Can an NBR 26x40x7 Seal Be Used as a Replacement?

CORTECO 19035249 should not automatically be replaced with an NBR seal.

The original specification identifies ACM as the elastomer material. NBR and ACM are different elastomer groups with different properties.

Changing the material requires verification against the operating medium, temperature and other application conditions.

Installation Recommendations

Before installation, inspect the shaft surface and housing bore.

The sealing surface should be free from:

• corrosion,
• burrs,
• sharp edges,
• excessive wear,
• contamination.

Protect the sealing lip from splines, threads, grooves and sharp shaft features during installation.

The seal should be pressed evenly into the housing using a suitable installation tool.

For CORTECO 19035249, correct orientation is particularly important because the product has a directional sealing structure.

FAQ

What are the dimensions of CORTECO 19035249?

CORTECO 19035249 measures 26x40x7 mm: 26 mm inner diameter, 40 mm outer diameter and 7 mm width.

What material is CORTECO 19035249 made from?

The seal is manufactured from ACM polyacrylate rubber.

What profile does CORTECO 19035249 have?

The confirmed CORTECO profile is RHTC.

What directional structure does CORTECO 19035249 use?

Catalog data specifies a right-hand directional sealing structure.

What is the HONDA OEM reference?

The confirmed HONDA OE reference is 91216-PHR-003.

Is there also a MINI OE reference?

Yes. Current aftermarket catalogue data associates the seal with MINI 23 11 7 518 633.

Are CORTECO 19035249 and 19035249B related?

The CORTECO dimensional catalogue uses reference 19035249, while current aftermarket catalogues also list 19035249B. When identifying the product, confirm the specification ACM RHTC 26x40x7 mm.

Is every 26x40x7 oil seal interchangeable?

No. Material, construction and directional profile must also be compared. CORTECO 19035249 is specified as ACM RHTC 26x40x7 mm with a right-hand directional sealing structure.

CORTECO 19035249 - Quick Answer

CORTECO 19035249 is an ACM RHTC radial shaft seal measuring 26x40x7 mm. It has a 26 mm inner diameter, 40 mm outer diameter and 7 mm width, with a right-hand directional sealing structure. Current aftermarket references also include 19035249B and 82035249. Confirmed OE references include HONDA 91216-PHR-003 and MINI 23 11 7 518 633.

Available from simmering.pl, a specialist supplier of radial shaft seals, O-rings, bearings and industrial sealing solutions. Products are shipped worldwide from stock in Poland.
