ASL AS11070 25.5x41.3x8 Main Rack Seal

ASL AS11070 25.5x41.3x8 Main Rack Seal

ASL AS11070 is a 25.5x41.3x8 mm power steering rack seal. Dimensional catalogue data identify AS11070 with a 25.5 mm inside diameter, 41.3 mm outside diameter and 8 mm width. Specialist power steering application catalogues classify the reference as a Main Rack Seal for selected Toyota steering racks, using the nominal size 25.5x41x8 mm.

ASL AS11070 - Technical Specification

Brand: ASL

Reference: AS11070

Product type: Power steering rack seal

Catalogue classification: Main Rack Seal

Dimensions: 25.5x41.3x8 mm

Inside diameter d: 25.5 mm

Outside diameter D: 41.3 mm

Width B: 8 mm

Nominal size in application catalogues: 25.5x41x8 mm

Catalogue application: Toyota

Material: Not sufficiently confirmed for AS11070

Exact seal profile: Not sufficiently confirmed for AS11070

AS11070 Dimensions

The dimensional catalogue specifies:

Inside diameter d: 25.5 mm

Outside diameter D: 41.3 mm

Width B: 8 mm

Complete dimensions: 25.5x41.3x8 mm

Specialist power steering application catalogues also list AS11070 with the nominal dimensions:

25.5x41x8 mm

The difference between 41 mm and 41.3 mm results from the way the product is represented in different catalogues. For dimensional identification, the AS11070 reference and 25.5x41.3x8 mm specification should be retained.

AS11070 Main Rack Seal

AS11070 is classified in specialist power steering catalogues as a:

Main Rack Seal

This identifies the product as a sealing component used within a power steering rack assembly.

AS11070 should therefore not be treated simply as a generic radial shaft oil seal selected only by approximate dimensions.

AS11070 Toyota Power Steering Seal

Power steering component catalogues associate AS11070 with selected:

Toyota

steering rack applications.

Product type: Main Rack Seal

Reference: AS11070

Catalogue size: 25.5x41.3x8 mm

Nominal application size: 25.5x41x8 mm

Compatibility should be verified against the specific steering rack rather than the vehicle manufacturer alone.

AS11070 and CORTECO 19026823

AS11070 appears in catalogue cross-reference data alongside CORTECO 19026823, but an important dimensional distinction should be retained.

ASL reference: AS11070

ASL dimensional catalogue size: 25.5x41.3x8 mm

CORTECO reference: 19026823

CORTECO dimensions: 25.5x41.1x8 mm

CORTECO material: NBR

CORTECO design: SCJY

The references are related in application and cross-reference catalogues, but their published outside diameters are not identical.

For this reason, the NBR material, SCJY profile and 41.1 mm outside diameter of CORTECO 19026823 should not automatically be transferred to AS11070.

Why 25.5x41.3x8 and 25.5x41x8 Both Appear

Different catalogues describe AS11070 with slightly different dimensional precision.

Dimensional catalogue: 25.5x41.3x8 mm

Power steering application catalogue: 25.5x41x8 mm

This makes the AS11070 reference particularly important when identifying the seal.

The 41.3 mm value should be retained in the product name when the physical product and dimensional catalogue correspond to that specification.

AS11070 Material

The exact sealing material of AS11070 has not been sufficiently confirmed in the independent catalogue data used for this product.

Therefore, the material should not automatically be stated as:

NBR

FKM/FPM

or another elastomer.

CORTECO 19026823 is catalogued as NBR, but this does not by itself prove that every AS11070 seal uses the identical material specification.

Selecting an AS11070 Replacement

When selecting a replacement, verify:

Reference: AS11070

Inside diameter: 25.5 mm

Outside diameter: 41.3 mm

Width: 8 mm

Product type: Main Rack Seal

System: Power steering rack

Catalogue application: Toyota

Material: Requires verification

Seal profile: Requires verification

Specific steering rack: Requires verification

Matching approximate dimensions alone does not establish complete technical interchangeability.

ASL AS11070 25.5x41.3x8 - Stock in Poland

ASL AS11070 25.5x41.3x8 Main Rack Seal is intended for compatible power steering rack applications.

Warehouse and Store: Lublin, Smoluchowskiego 1 Street, Building 4

Shipping: 24h

Stock location: Poland

Delivery: Poland and EU countries

FAQ - ASL AS11070

What are the dimensions of AS11070?

The dimensional catalogue lists 25.5x41.3x8 mm.

Why is AS11070 sometimes listed as 25.5x41x8?

Power steering application catalogues use the nominal size 25.5x41x8 mm, while the dimensional catalogue gives the more specific 25.5x41.3x8 mm value.

What is AS11070 used for?

AS11070 is catalogued as a Main Rack Seal for power steering rack applications.

Is AS11070 used in Toyota steering racks?

Yes. Toyota is listed as the catalogue application for AS11070. The specific steering rack should still be verified.

What material is AS11070 made from?

The exact material has not been sufficiently confirmed for AS11070 itself and should therefore not be assumed.

Frequently Asked Questions by Engineers

Is AS11070 a standard radial shaft oil seal?

It should not be treated simply as a generic dimensional oil seal. AS11070 is specifically catalogued as a Main Rack Seal for power steering systems.

Is AS11070 identical to CORTECO 19026823?

They are associated in cross-reference data, but published dimensional data differ. AS11070 is listed as 25.5x41.3x8 mm, while CORTECO 19026823 is listed as 25.5x41.1x8 mm.

Can the NBR and SCJY specifications of CORTECO 19026823 be assigned to AS11070?

Not without additional confirmation. Those specifications are directly documented for CORTECO 19026823, not necessarily for AS11070 itself.

Can a generic 25.5x41x8 seal replace AS11070?

Interchangeability should not be assumed. The exact outside diameter, seal construction and steering rack requirements should be checked.

What is most important when identifying AS11070?

The key identification data are the AS11070 reference, 25.5x41.3x8 mm dimensions and Main Rack Seal application.
