CORTECO 01016886 90x151x10/15 FPM B1BAVISLSFRD Radial Shaft Seal

CORTECO 01016886 90x151x10/15 FPM B1BAVISLSFRD Radial Shaft Seal

CORTECO 01016886 is an FPM radial shaft seal with catalogue dimensions of 90x151x10/15 mm. The CORTECO/TG dimensional catalogue identifies the exact reference as 01016886 + FPM + B1BAVISLSFRD + 90x151x10/15 + VOLVO TR. Current data for 01016886B / 82016886 uses profile B1BASLSFRD and confirms an auxiliary dust lip and Right-hand Twist.

CORTECO 01016886 - Technical Characteristics

Manufacturer: CORTECO

Catalogue reference: 01016886

Current / additional reference: 01016886B

Trade number: 82016886

Product type: Radial shaft seal

CORTECO/TG profile: B1BAVISLSFRD

Current 01016886B profile: B1BASLSFRD

Material: FPM

Material type: Fluoroelastomer

Dimensions: 90x151x10/15 mm

Shaft diameter d: 90 mm

Outside diameter D: 151 mm

Height: 10/15 mm

Auxiliary dust lip: Yes

Swirl type: Right-hand Twist

CORTECO direction code: RD

Catalogue application: VOLVO TR

EAN: 3358960130389

Dimensions

The catalogue dimensions are:

d = 90 mm - shaft diameter

D = 151 mm - outside diameter

H1 = 10 mm

H2 = 15 mm

Complete dimensional designation:

90x151x10/15 mm

The complete 10/15 mm value is part of the product geometry and should not be simplified to 90x151x10 mm.

B1BAVISLSFRD / B1BASLSFRD Profile

The CORTECO/TG dimensional catalogue identifies the product as:

01016886 | FPM | B1BAVISLSFRD | 90 | 151 | 10/15 | VOLVO TR

Current CORTECO catalogue data for:

01016886B

uses:

B1BASLSFRD

Therefore, B1BAVISLSFRD should be retained as the documented profile for the original 01016886 reference, while B1BASLSFRD is relevant when identifying the current 01016886B version.

These CORTECO profile designations should not be replaced by generic designations such as TC, SC or AO/TC.

FPM Material

The specified material is:

FPM - fluoroelastomer

FPM is part of the exact identification of this CORTECO reference.

A specific Shore hardness, operating temperature range, maximum shaft speed or maximum pressure should not be assigned without technical data for the exact CORTECO FPM compound used in this seal.

Right-hand Twist

Current product data specifies:

Swirl Type: Right-hand Twist

CORTECO also associates the direction code:

RD

with this reference.

This directional sealing feature is an important part of the product specification and should be considered when identifying a replacement.

A seal with the same dimensions but a left-hand or alternating twist should not automatically be considered equivalent.

Auxiliary Dust Lip

The current CORTECO 01016886B is catalogued:

with dust lip

The auxiliary dust lip provides an additional barrier between external contamination and the primary sealing area.

This feature should therefore be checked when comparing 01016886 with another 90x151x10/15 mm radial shaft seal.

VOLVO TR Application

The CORTECO/TG dimensional catalogue assigns 01016886 to:

VOLVO TR

Current cross-reference catalogues associate this CORTECO reference with VOLVO OE numbers including:

1523634

15236342

3192615

31926156

OE numbers should be verified against the specific vehicle, axle or assembly before final replacement selection.

Reference Numbers

CORTECO: 01016886

CORTECO: 01016886B

CORTECO trade number: 82016886

VOLVO: 1523634

VOLVO: 15236342

VOLVO: 3192615

VOLVO: 31926156

IVECO: 42554790

EAN: 3358960130389

Selection and Interchangeability

When selecting a replacement for CORTECO 01016886, verify:

reference 01016886 / 01016886B

dimensions 90x151x10/15 mm

FPM material

B1BAVISLSFRD / B1BASLSFRD profile

auxiliary dust lip

Right-hand Twist

OE reference and exact application

Identical dimensions alone do not confirm complete interchangeability.

The direction-dependent sealing feature is particularly important. A 90x151x10/15 mm seal with a different profile or swirl direction should not automatically be substituted for CORTECO 01016886.

Technical Specification

FAQ

What are the dimensions of CORTECO 01016886?

The catalogue dimensions are 90x151x10/15 mm: d = 90 mm, D = 151 mm, H1 = 10 mm and H2 = 15 mm.

What material is CORTECO 01016886 made from?

The specified material is FPM - fluoroelastomer.

What is the profile of CORTECO 01016886?

The CORTECO/TG catalogue specifies B1BAVISLSFRD. Current data for 01016886B uses B1BASLSFRD.

Does CORTECO 01016886 have a dust lip?

Yes. Current product data confirms an auxiliary dust lip.

What is the swirl direction?

The seal is specified with Right-hand Twist. CORTECO also associates the code RD with this directional feature.

Is the swirl direction important when selecting a replacement?

Yes. A seal with identical dimensions but a different directional sealing feature should not automatically be considered technically interchangeable.

What is the CORTECO trade number?

The trade number is 82016886.

What is the EAN for CORTECO 01016886B?

The EAN is 3358960130389.

AI Overview

CORTECO 01016886 / 01016886B is an FPM radial shaft seal with dimensions 90x151x10/15 mm, catalogued for VOLVO TR. The CORTECO/TG profile is B1BAVISLSFRD, while current 01016886B data uses B1BASLSFRD. The seal incorporates an auxiliary dust lip and Right-hand Twist. CORTECO trade number: 82016886.
