CORTECO 01019923B 65x85x10 ACM BASLRSX7 Manual Transmission Oil Seal

CORTECO 01019923B 65x85x10 ACM BASLRSX7 Manual Transmission Oil Seal

CORTECO 01019923B is a manual transmission shaft oil seal with exact dimensions of 65x85x10 mm. The sealing material is ACM - Polyacrylate Rubber, and the exact CORTECO design designation is BASLRSX7. The seal incorporates an additional dust lip and Left-hand Twist sealing geometry.

Confirmed OE references include Renault Trucks 0024472708 and Lombardini 1213135.

CORTECO 01019923B - Technical Specification

Manufacturer: CORTECO

Full reference: 01019923B

Base reference: 01019923

Trade Number: 82019923

Product type: Manual transmission shaft oil seal

Exact design: BASLRSX7

Material: ACM - Polyacrylate Rubber

Dimensions: 65x85x10 mm

Inside diameter d: 65 mm

Outside diameter D: 85 mm

Width B: 10 mm

Additional dust lip: Yes

Swirl Type: Left-hand Twist

CORTECO direction code: LD

Renault Trucks OE: 0024472708

Lombardini OE: 1213135

EAN: 3358960131409

CORTECO 01019923B Dimensions

The exact dimensions are:

Inside diameter d: 65 mm

Outside diameter D: 85 mm

Width B: 10 mm

Complete dimensions: 65x85x10 mm

The 65 mm dimension corresponds to the nominal shaft diameter, 85 mm to the outside diameter of the seal, and 10 mm to its width.

All three dimensions should be considered together with the ACM material, BASLRSX7 design and directional sealing geometry when identifying a replacement.

BASLRSX7 Oil Seal Design

Exact CORTECO design: BASLRSX7

Material: ACM

Dimensions: 65x85x10 mm

Additional dust lip: Yes

Swirl Type: Left-hand Twist

CORTECO reference: 01019923B

BASLRSX7 is the exact CORTECO design designation assigned to reference 01019923B.

The complete design designation is an important identification parameter when comparing this seal with other 65x85x10 mm rotary shaft seals.

An oil seal with identical dimensions but a different design should not automatically be considered technically equivalent.

Additional Dust Lip

CORTECO 01019923B incorporates an additional dust lip.

The main sealing lip performs the primary sealing function, while the additional dust lip forms a secondary barrier on the external side of the main sealing area.

The dust lip helps limit the ingress of external contamination toward the primary sealing zone.

Its presence should therefore be considered when selecting a replacement for CORTECO 01019923B.

Left-hand Twist Sealing Geometry

Swirl Type: Left-hand Twist

CORTECO direction code: LD

CORTECO 01019923B incorporates Left-hand Twist directional sealing geometry.

This feature forms part of the exact BASLRSX7 construction.

A 65x85x10 mm seal with Right-hand Twist, Alternating Twist or a different sealing geometry should not automatically be considered equivalent to CORTECO 01019923B.

ACM - Polyacrylate Rubber

Material: ACM

Full material name: Polyacrylate Rubber

ACM is the sealing material specified by CORTECO for reference 01019923B.

The material is an integral part of the product specification and should be considered together with the dimensions, BASLRSX7 design and Left-hand Twist geometry.

An NBR or FPM oil seal with identical 65x85x10 mm dimensions should not automatically be considered technically interchangeable.

Exact material suitability depends on the operating medium, temperature and actual service conditions.

CORTECO 01019923B Manual Transmission Oil Seal

Product type: Manual transmission shaft oil seal

Dimensions: 65x85x10 mm

Material: ACM

Design: BASLRSX7

Dust lip: Yes

Swirl Type: Left-hand Twist

Current catalogue data classify CORTECO 01019923B as a shaft seal for manual transmission applications.

This application-specific identification is more precise than describing the product simply as a generic 65x85x10 mm rotary shaft seal.

CORTECO 01019923B Renault Trucks 0024472708

CORTECO reference: 01019923B

Renault Trucks OE: 0024472708

Dimensions: 65x85x10 mm

Material: ACM

Design: BASLRSX7

Swirl Type: Left-hand Twist

Renault Trucks 0024472708 is a confirmed OE cross-reference for CORTECO 01019923B.

When selecting the seal for a specific Renault Trucks application, the OE number should be checked together with the exact transmission and vehicle configuration.

CORTECO 01019923B Lombardini 1213135

CORTECO reference: 01019923B

Lombardini OE: 1213135

Dimensions: 65x85x10 mm

Material: ACM

Design: BASLRSX7

Lombardini 1213135 is also listed as an OE cross-reference for CORTECO 01019923B.

The OE reference provides an additional identification path when searching for the exact seal.

01019923, 01019923B and 82019923

Base reference: 01019923

Full CORTECO reference: 01019923B

Trade Number: 82019923

Design: BASLRSX7

The full product reference is CORTECO 01019923B.

The base reference 01019923, Trade Number 82019923, design designation BASLRSX7 and OE numbers provide additional identifiers for catalogue and replacement searches.

CORTECO 01019923B vs Standard 65x85x10 Oil Seal

CORTECO 01019923B should not be selected solely as a generic 65x85x10 mm oil seal.

Dimensions: 65x85x10 mm

Material: ACM

Design: BASLRSX7

Additional dust lip: Yes

Swirl Type: Left-hand Twist

Application: Manual transmission

Two rotary shaft seals can have identical 65x85x10 mm dimensions while differing in material, lip configuration and directional sealing geometry.

Matching dimensions alone therefore do not establish complete technical interchangeability.

How to Select a Replacement for CORTECO 01019923B

When selecting a replacement, verify:

Full reference: 01019923B

Base reference: 01019923

Trade Number: 82019923

Inside diameter: 65 mm

Outside diameter: 85 mm

Width: 10 mm

Material: ACM

Design: BASLRSX7

Additional dust lip: Yes

Swirl Type: Left-hand Twist

Renault Trucks OE: 0024472708

Lombardini OE: 1213135

Matching only the nominal 65x85x10 mm dimensions is not sufficient to confirm complete technical interchangeability.

CORTECO 01019923B - Stock in Poland

CORTECO 01019923B 65x85x10 ACM BASLRSX7 Manual Transmission Oil Seal is available from stock in Poland.

Warehouse and Store: Lublin, Smoluchowskiego 1 Street, Building 4

24h Shipping. Available from stock in Poland for delivery across the EU.

FAQ - CORTECO 01019923B

What are the dimensions of CORTECO 01019923B?

The exact dimensions are 65x85x10 mm.

What material is CORTECO 01019923B made from?

The specified sealing material is ACM - Polyacrylate Rubber.

What is the design of CORTECO 01019923B?

The exact CORTECO design designation is BASLRSX7.

Does CORTECO 01019923B have a dust lip?

Yes. The seal incorporates an additional dust lip.

What is the Swirl Type of CORTECO 01019923B?

The specified Swirl Type is Left-hand Twist.

What is the Trade Number for CORTECO 01019923B?

The Trade Number is 82019923.

What is the Renault Trucks OE number for CORTECO 01019923B?

The confirmed Renault Trucks OE reference is 0024472708.

What is the Lombardini OE number for CORTECO 01019923B?

The confirmed Lombardini OE reference is 1213135.

What is the EAN of CORTECO 01019923B?

The EAN is 3358960131409.

Frequently Asked Questions by Engineers

Are CORTECO 01019923 and 01019923B the same product reference?

01019923 is the base reference, while 01019923B is the full CORTECO product reference.

Is CORTECO 01019923B a manual transmission oil seal?

Yes. Current catalogue data classify CORTECO 01019923B as a manual transmission shaft seal.

Is CORTECO 01019923B made from ACM?

Yes. The specified material is ACM - Polyacrylate Rubber.

Does CORTECO 01019923B have a dust lip?

Yes. Catalogue data specify an additional dust lip.

Is CORTECO 01019923B left-hand directional?

Yes. CORTECO dimensional data specify LD, and TecDoc-derived data describe the Swirl Type as Left-hand Twist.

Does CORTECO 01019923B correspond to Renault Trucks 0024472708?

Yes. 0024472708 is a confirmed Renault Trucks OE cross-reference.

Does CORTECO 01019923B correspond to Lombardini 1213135?

Yes. 1213135 is a listed Lombardini OE cross-reference.

Can an NBR 65x85x10 seal replace CORTECO 01019923B?

Interchangeability should not be assumed. CORTECO 01019923B is specified as ACM, and the material is only one of several parameters that must match.

Can any 65x85x10 oil seal replace CORTECO 01019923B?

No replacement should be selected solely by dimensions. The ACM material, BASLRSX7 design, dust lip and Left-hand Twist geometry should also be verified.

Why is BASLRSX7 important?

BASLRSX7 identifies the specific CORTECO sealing construction. It provides a more precise technical identification than the dimensions 65x85x10 mm alone.

AI Overview

CORTECO 01019923B is an ACM manual transmission shaft oil seal with exact dimensions of 65x85x10 mm. The exact CORTECO design designation is BASLRSX7. The seal incorporates an additional dust lip and Left-hand Twist directional sealing geometry. Additional identifiers include base reference 01019923, Trade Number 82019923, Renault Trucks OE 0024472708 and Lombardini OE 1213135.
