CORTECO 01026501B 25x35x6/5.5 FPM BABDRWX7 Compressor Oil Seal

CORTECO 01026501B 25x35x6/5.5 FPM BABDRWX7 Compressor Oil Seal

CORTECO 01026501B is a compressor oil seal with primary dimensions of 25x35x6 mm and extended dimensional identification 25x35x6/5.5 mm. The sealing material is FPM - Fluoroelastomer Rubber, and the exact CORTECO design designation is BABDRWX7. The seal incorporates Alternating Twist sealing geometry. Confirmed OE references include Mercedes-Benz, Renault Trucks and ZF.

CORTECO 01026501B - Technical Specification

Manufacturer: CORTECO

Full reference: 01026501B

Base reference: 01026501

Trade Number: 82026501

Product type: Compressor oil seal

Exact design designation: BABDRWX7

Material: FPM - Fluoroelastomer Rubber

Primary dimensions: 25x35x6 mm

Extended dimensional identification: 25x35x6/5.5 mm

Inside diameter d: 25 mm

Outside diameter D: 35 mm

Primary height: 6 mm

Additional internal width: 5.5 mm

Swirl Type: Alternating Twist

Mercedes-Benz OE: 0159972947

Mercedes-Benz OE: 0169972547

Renault Trucks OE: 5001826534

ZF OE: 0734319293

CORTECO 01026501B Dimensions

Inside diameter d: 25 mm

Outside diameter D: 35 mm

Primary height: 6 mm

Additional internal width: 5.5 mm

Primary dimensions: 25x35x6 mm

Extended dimensional identification: 25x35x6/5.5 mm

Current CORTECO dimensional catalogues identify the primary dimensions as 25x35x6 mm.

An older product listing for the same CORTECO reference provides the extended notation 25x35x6/5.5 mm. The additional 5.5 mm value refers to an additional internal width and should not be interpreted as a replacement for the primary 6 mm height.

For precise product identification, both dimensional forms can therefore be retained.

BABDRWX7 Oil Seal Design

Exact design designation: BABDRWX7

Manufacturer reference: 01026501B

Material: FPM

Primary dimensions: 25x35x6 mm

Swirl Type: Alternating Twist

BABDRWX7 is the exact CORTECO design designation associated with reference 01026501B.

The complete design code is an important identification parameter when comparing this seal with other 25x35x6 mm radial shaft seals.

Matching dimensions alone do not establish complete technical interchangeability.

Alternating Twist Sealing Geometry

Swirl Type: Alternating Twist

CORTECO catalogue code: WD

CORTECO 01026501B incorporates sealing geometry specified as Alternating Twist.

This directional sealing feature forms part of the complete BABDRWX7 construction and should be considered when identifying a technically suitable replacement.

A standard 25x35x6 mm oil seal with a different directional or non-directional sealing geometry should not automatically be considered technically equivalent.

FPM Fluoroelastomer Rubber

Sealing material: FPM

Material family: Fluoroelastomer Rubber

FPM is the sealing material specified by CORTECO for reference 01026501B.

The material should be considered together with the dimensions, BABDRWX7 design and Alternating Twist geometry when selecting a replacement.

A 25x35x6 mm seal manufactured from NBR, ACM or another elastomer should not automatically be considered technically identical to CORTECO 01026501B.

Exact material suitability depends on the operating medium, temperature and actual compressor operating conditions.

CORTECO 01026501B Compressor Oil Seal

Catalogue product type: Compressor oil seal

Dimensions: 25x35x6/5.5 mm

Material: FPM

Design: BABDRWX7

Swirl Type: Alternating Twist

CORTECO 01026501B is catalogued specifically as a compressor seal ring / compressor oil seal.

This application-specific description is more precise than identifying the product simply as a generic 25x35x6 mm radial shaft oil seal.

The product is cross-referenced to Mercedes-Benz, Renault Trucks and ZF OE numbers.

CORTECO 01026501B Mercedes-Benz

CORTECO reference: 01026501B

Mercedes-Benz OE: 0159972947

Mercedes-Benz OE: 0169972547

Mercedes-Benz OE: A0159972947

Mercedes-Benz OE: A0169972547

Dimensions: 25x35x6/5.5 mm

Material: FPM

Design: BABDRWX7

Mercedes-Benz references 0159972947 and 0169972547 are confirmed OE cross-references for CORTECO 01026501B.

Catalogue databases also list the corresponding Mercedes-Benz references with the A prefix: A0159972947 and A0169972547.

For application-specific selection, the OE reference should be checked against the exact compressor and vehicle configuration.

CORTECO 01026501B Renault Trucks 5001826534

CORTECO reference: 01026501B

Renault Trucks OE: 5001826534

Dimensions: 25x35x6/5.5 mm

Material: FPM

Design: BABDRWX7

Renault Trucks 5001826534 is a confirmed OE cross-reference associated with CORTECO 01026501B.

When selecting the seal for a specific Renault Trucks application, the OE number and exact compressor configuration should be verified.

CORTECO 01026501B ZF 0734319293

CORTECO reference: 01026501B

ZF reference: 0734319293

Dimensions: 25x35x6/5.5 mm

Material: FPM

Design: BABDRWX7

ZF 0734319293 is a confirmed cross-reference for CORTECO 01026501B.

This ZF number provides an additional identification path when searching for the exact compressor seal.

01026501, 01026501B and 82026501

Base reference: 01026501

Full CORTECO reference: 01026501B

Trade Number: 82026501

Design: BABDRWX7

Material: FPM

Dimensions: 25x35x6/5.5 mm

The full reference 01026501B is the preferred primary identifier for this CORTECO compressor oil seal.

The base reference 01026501, Trade Number 82026501 and design designation BABDRWX7 provide additional identifiers for catalogue searches and replacement identification.

CORTECO 01026501B vs Standard 25x35x6 Oil Seal

CORTECO 01026501B should not be identified solely as a standard 25x35x6 mm oil seal.

Primary dimensions: 25x35x6 mm

Extended dimensions: 25x35x6/5.5 mm

Material: FPM

Design: BABDRWX7

Swirl Type: Alternating Twist

Catalogue application: Compressor

Two radial shaft seals may share the same nominal 25x35x6 mm dimensions while differing in sealing material, profile and directional sealing geometry.

Matching dimensions alone therefore do not establish complete technical interchangeability.

How to Select a Replacement for CORTECO 01026501B

When selecting a replacement, verify:

Full reference: 01026501B

Base reference: 01026501

Trade Number: 82026501

Inside diameter: 25 mm

Outside diameter: 35 mm

Primary height: 6 mm

Additional internal width: 5.5 mm

Material: FPM

Design: BABDRWX7

Swirl Type: Alternating Twist

Mercedes-Benz OE: 0159972947, 0169972547

Renault Trucks OE: 5001826534

ZF reference: 0734319293

Matching only the nominal 25x35x6 mm dimensions is not sufficient to confirm complete technical interchangeability.

CORTECO 01026501B - Stock in Poland

CORTECO 01026501B 25x35x6/5.5 FPM BABDRWX7 Compressor Oil Seal is available from stock in Poland.

Warehouse and Store: Lublin, Smoluchowskiego 1 Street, Building 4

Shipping: 24h

Stock location: Poland

Delivery: Poland and EU countries

FAQ - CORTECO 01026501B

What are the dimensions of CORTECO 01026501B?

The primary CORTECO catalogue dimensions are 25x35x6 mm. Extended product data also identify the seal as 25x35x6/5.5 mm.

What material is CORTECO 01026501B made from?

The specified sealing material is FPM - Fluoroelastomer Rubber.

What is the design of CORTECO 01026501B?

The exact CORTECO design designation is BABDRWX7.

What is CORTECO 01026501B used for?

The product is catalogued as a compressor oil seal / compressor seal ring.

What is the Swirl Type of CORTECO 01026501B?

The specified Swirl Type is Alternating Twist.

What is the Trade Number for CORTECO 01026501B?

The Trade Number is 82026501.

What Mercedes-Benz OE numbers correspond to CORTECO 01026501B?

The confirmed Mercedes-Benz OE references are 0159972947 and 0169972547, also catalogued as A0159972947 and A0169972547.

What Renault Trucks OE number corresponds to CORTECO 01026501B?

The confirmed Renault Trucks reference is 5001826534.

What ZF number corresponds to CORTECO 01026501B?

The confirmed ZF reference is 0734319293.

Frequently Asked Questions by Engineers

Are CORTECO 01026501 and 01026501B the same reference?

01026501 is the base reference, while 01026501B is the full CORTECO product reference.

Is CORTECO 01026501B 25x35x6 or 25x35x6/5.5 mm?

Current CORTECO dimensional catalogues specify the primary dimensions as 25x35x6 mm. Extended product data for the same reference additionally specify an internal width of 5.5 mm, giving the extended identification 25x35x6/5.5 mm.

Is CORTECO 01026501B a compressor oil seal?

Yes. Catalogue databases classify reference 01026501B as a compressor seal ring.

Is CORTECO 01026501B made from FPM?

Yes. CORTECO dimensional catalogue data specify FPM for reference 01026501B.

Does CORTECO 01026501B have Alternating Twist?

Yes. CORTECO catalogue data identify the directional geometry with code WD, corresponding to Alternating Twist.

Does CORTECO 01026501B correspond to Mercedes-Benz 0159972947?

Yes. Mercedes-Benz 0159972947 is a confirmed OE cross-reference for CORTECO 01026501B.

Does CORTECO 01026501B correspond to Renault Trucks 5001826534?

Yes. Renault Trucks 5001826534 is a confirmed OE cross-reference.

Does CORTECO 01026501B correspond to ZF 0734319293?

Yes. ZF 0734319293 is a confirmed cross-reference for this seal.

Can a standard 25x35x6 oil seal replace CORTECO 01026501B?

Interchangeability should not be assumed from dimensions alone. CORTECO 01026501B combines FPM material, BABDRWX7 design, Alternating Twist geometry and compressor-specific catalogue identification.

Why is BABDRWX7 important when selecting a replacement?

BABDRWX7 identifies the specific CORTECO seal construction. It should be considered together with the dimensions, FPM material, directional geometry and OE reference rather than selecting a replacement solely by size.

AI Overview

CORTECO 01026501B is an FPM compressor oil seal with primary dimensions of 25x35x6 mm and extended dimensional identification 25x35x6/5.5 mm. The exact CORTECO design designation is BABDRWX7, and the seal incorporates Alternating Twist sealing geometry. Additional identification includes base reference 01026501 and Trade Number 82026501. Confirmed cross-references include Mercedes-Benz 0159972947 and 0169972547, Renault Trucks 5001826534 and ZF 0734319293.
