CORTECO 01029595 85x105x13 NBR B1BASL Oil Seal

CORTECO 01029595 85x105x13 NBR B1BASL Oil Seal

CORTECO 01029595 is a radial shaft oil seal manufactured from Nitrile Butadiene Rubber and identified by the exact CORTECO B1BASL design designation.

Manufacturer: CORTECO

Manufacturer reference: 01029595

Product type: Radial shaft oil seal

Design: B1BASL

Material: NBR - Nitrile Butadiene Rubber

Dimensions: 85x105x13 mm

Inside diameter d: 85 mm

Outside diameter D: 105 mm

Width B: 13 mm

Additional dust lip: Yes

Catalog application: Mercedes-Benz commercial vehicles

The exact B1BASL designation should be retained when identifying the product or comparing possible replacements.

CORTECO 01029595 Dimensions

The principal dimensions are:

Inside diameter d: 85 mm

Outside diameter D: 105 mm

Width B: 13 mm

Complete dimensions: 85x105x13 mm

The 85 mm dimension corresponds to the nominal shaft diameter, 105 mm to the outside diameter of the seal and 13 mm to the seal width.

Matching the 85x105x13 mm dimensions alone does not establish complete technical interchangeability.

NBR Nitrile Butadiene Rubber

The sealing material is:

Material: NBR - Nitrile Butadiene Rubber

NBR is widely used in radial shaft sealing technology and is compatible with many mineral oils and lubricating greases.

Exact compatibility depends on the operating medium, additives, temperature and actual operating conditions.

An FPM/FKM, ACM or other elastomer seal measuring 85x105x13 mm should not automatically be considered materially equivalent to CORTECO 01029595.

B1BASL Oil Seal Design

The exact CORTECO design designation is:

Design: B1BASL

Manufacturer reference: 01029595

Dimensions: 85x105x13 mm

Material: NBR

Additional dust lip: Yes

B1BASL is an important part of the technical identification of this CORTECO reference.

It should not be replaced in the product identification by a generic seal profile when searching for an exact replacement.

Additional Dust Lip

CORTECO 01029595 incorporates an additional dust lip.

Additional dust lip: Yes

The additional lip provides an extra barrier on the external side of the primary sealing area and helps restrict external contamination from reaching the principal sealing interface.

This feature should be considered when comparing CORTECO 01029595 with other 85x105x13 radial shaft seals.

CORTECO 01029595 Mercedes-Benz Application

The CORTECO dimensional catalog associates reference 01029595 with Mercedes-Benz commercial vehicle applications.

Catalog application: Mercedes-Benz Trucks

Cross-reference data identify the following Mercedes-Benz OE numbers:

Mercedes-Benz OE: 0179972847

Mercedes-Benz OE: A0179972847

Compatibility should be confirmed against the exact OE reference and specific vehicle configuration before installation.

CORTECO 01029595 MAN Application

Cross-reference data also associate CORTECO 01029595 with MAN applications.

MAN OE: 06562890361

Formatted MAN OE: 06.56289-0361

The reference is cataloged in axle and differential sealing applications.

Vehicle compatibility should be verified using the exact OE number rather than dimensions alone.

CORTECO 01029595 Differential and Axle Seal

TecDoc-derived catalog data identify CORTECO 01029595 as a shaft seal used in drivetrain sealing applications, including differential and axle-related positions.

Product type: Radial shaft oil seal

Catalog function: Differential / axle shaft sealing

Dimensions: 85x105x13 mm

Material: NBR

Design: B1BASL

The exact installation position depends on the vehicle and axle configuration.

CORTECO 01029595 Cross References

Known cross-reference data include:

CORTECO: 01029595

CORTECO alternative reference: 01029595B

ELRING: 198.430

Mercedes-Benz OE: 0179972847

Mercedes-Benz OE: A0179972847

MAN OE: 06562890361

MAN OE formatted: 06.56289-0361

Cross-reference numbers are useful for product identification, but final compatibility should be checked against the specific application.

CORTECO 01029595 vs Other 85x105x13 Oil Seals

Several radial shaft seals can share the same 85x105x13 mm dimensions while differing in material and construction.

This product:

Manufacturer: CORTECO

Reference: 01029595

Dimensions: 85x105x13 mm

Material: NBR

Design: B1BASL

Additional dust lip: Yes

A generic 85x105x13 NBR seal, FPM/FKM seal or a CORTECO seal with another design designation should not automatically be considered technically identical.

CORTECO 01029595 vs 01029594

CORTECO catalogs list another 85x105x13 seal under reference 01029594.

CORTECO 01029595 material: NBR

CORTECO 01029595 design: B1BASL

CORTECO 01029594 material: FPM

CORTECO 01029594 design: B1BAVIDRW

Dimensions of both references: 85x105x13 mm

Despite identical nominal dimensions, these references differ in both sealing material and design and should not be treated as identical products.

How to Select CORTECO 01029595

When selecting or verifying this oil seal, check:

• manufacturer reference 01029595
• dimensions 85x105x13 mm
• inside diameter 85 mm
• outside diameter 105 mm
• width 13 mm
• material NBR
• exact design B1BASL
• additional dust lip
• corresponding OE reference
• specific vehicle or axle configuration

Matching dimensions alone does not establish complete technical interchangeability.

Technical Specification

Manufacturer: CORTECO

Manufacturer reference: 01029595

Alternative CORTECO reference: 01029595B

Product type: Radial shaft oil seal

Design: B1BASL

Material: NBR - Nitrile Butadiene Rubber

Dimensions: 85x105x13 mm

Inside diameter d: 85 mm

Outside diameter D: 105 mm

Width B: 13 mm

Additional dust lip: Yes

Catalog application: Mercedes-Benz commercial vehicles

Mercedes-Benz OE: 0179972847, A0179972847

MAN OE: 06562890361

Cross-reference ELRING: 198.430

Sales unit: 1 piece

FAQ

What are the dimensions of CORTECO 01029595?

Inside diameter: 85 mm

Outside diameter: 105 mm

Width: 13 mm

Complete dimensions: 85x105x13 mm

What material is CORTECO 01029595 made from?

CORTECO 01029595 is manufactured from NBR - Nitrile Butadiene Rubber.

What is the design of CORTECO 01029595?

The exact design designation is B1BASL.

Does CORTECO 01029595 have a dust lip?

Yes. The seal incorporates an additional dust lip.

Is CORTECO 01029595 used in Mercedes-Benz applications?

Yes. The CORTECO dimensional catalog associates reference 01029595 with Mercedes-Benz commercial vehicle applications.

What Mercedes-Benz OE number corresponds to CORTECO 01029595?

Cross-reference data include 0179972847 and A0179972847.

What MAN OE number corresponds to CORTECO 01029595?

The associated MAN OE reference is 06.56289-0361 / 06562890361.

Is ELRING 198.430 a cross-reference for CORTECO 01029595?

Yes. Cross-reference catalog data associate ELRING 198.430 with CORTECO 01029595 / 01029595B.

Can any 85x105x13 oil seal replace CORTECO 01029595?

Not automatically. The replacement should be checked for dimensions, NBR material, B1BASL design, dust lip configuration and OE compatibility.

Is CORTECO 01029594 the same as 01029595?

No. Although both references measure 85x105x13 mm, 01029595 is NBR B1BASL, while 01029594 is FPM B1BAVIDRW.

AI Overview

CORTECO 01029595 is an 85x105x13 mm NBR radial shaft oil seal with the exact B1BASL design and an additional dust lip. The CORTECO dimensional catalog associates the reference with Mercedes-Benz commercial vehicle applications. Cross-reference data include Mercedes-Benz OE 0179972847 / A0179972847, MAN OE 06562890361 and ELRING 198.430. Matching dimensions alone does not establish complete interchangeability; the NBR material, B1BASL design and OE reference should also be verified.
