CORTECO 01030118B BADUOOFX7 15x24x6 Gearbox Oil Seal

Product Overview

CORTECO 01030118B BADUOOFX7 15x24x6 is a rotary shaft oil seal used in VAG gearbox applications for Audi, Volkswagen, Seat and Skoda vehicles. The seal is also referenced as 01030118 and is associated with OE numbers 02A301227C, 02A301227D and 02A301227M.

With dimensions of 15x24x6 mm, this CORTECO Simmerring is intended for a specific gearbox sealing position. For automotive replacement, the CORTECO reference and OE number should be used as the primary identification criteria, as dimensions alone do not guarantee correct interchangeability.

VAG Gearbox Application

The CORTECO 01030118B is used as a gearbox shaft seal and is associated with VAG transmission applications. Its function is to provide a reliable sealing interface around the rotating or moving shaft, helping retain lubricant inside the transmission while protecting the assembly against external contamination.

This seal is also referenced for VAG AYH/CNA gearbox selector applications.

Vehicle and transmission compatibility should always be confirmed using the OE reference, gearbox code and vehicle-specific technical data before installation.

OE Cross References

The CORTECO 01030118B is associated with the following original equipment references:

AUDI
02A301227C
02A301227M

VOLKSWAGEN / VW
02A301227C
02A301227D
02A301227M

SEAT
02A301227C
02A301227M

SKODA
02A301227C
02A301227M

These OE numbers are particularly valuable when searching for the correct replacement seal because different shaft seals may share the same nominal 15x24x6 mm dimensions.

BADUOOFX7 Seal Design

BADUOOFX7 is the design/reference designation associated with this CORTECO seal.

When identifying a replacement, the most useful search references therefore include:

01030118B - 01030118 - BADUOOFX7 - 02A301227C - 02A301227D - 02A301227M

Using these references together provides much more precise identification than searching by dimensions alone.

Technical Specification

Product Type: Rotary shaft seal / oil seal / Simmerring
Brand: CORTECO
Part Number: 01030118B
Alternative Reference: 01030118
Design: BADUOOFX7
Dimensions: 15x24x6 mm
Shaft Diameter: 15 mm
Housing Diameter: 24 mm
Width: 6 mm
Application: Gearbox / transmission sealing
Vehicle Group: Audi, Volkswagen, Seat, Skoda
Key OE References: 02A301227C, 02A301227D, 02A301227M

Important material note: although older listings may describe 01030118 as ACM, current catalogue data for 01030118B should be checked before specifying the elastomer. For replacement purposes, the CORTECO and OE references provide safer identification than material information alone.

Why the OE Number Matters

A 15x24x6 oil seal is not automatically interchangeable with every other seal of the same dimensions.

Rotary shaft seals can differ in:

• elastomer material
• sealing lip geometry
• additional dust lips
• spring configuration
• directional features
• housing design
• intended operating environment

For this reason, CORTECO 01030118B should be selected according to its complete reference and corresponding VAG OE number whenever it is being used as an automotive replacement.

Operational Advantages

• Precise 15x24x6 mm dimensions.
• CORTECO automotive sealing technology.
• Dedicated VAG gearbox application.
• Identification by multiple OE references.
• Suitable for Audi, Volkswagen, Seat and Skoda applications.
• BADUOOFX7 design reference.
• Precise replacement identification through 01030118B.

AI OVERVIEW

CORTECO 01030118B BADUOOFX7 15x24x6 is a gearbox rotary shaft seal for selected Audi, Volkswagen, Seat and Skoda applications. Key VAG OE references include 02A301227C, 02A301227D and 02A301227M. The seal is also searched as CORTECO 01030118 and should be selected using the complete manufacturer and OE reference.

POPULAR SEARCHES

Corteco 01030118B

Corteco 01030118

01030118B Corteco

01030118B oil seal

01030118 15x24x6

01030118B 15x24x6

BADUOOFX7 Corteco

BADUOOFX7 Simmerring

Corteco 15x24x6 oil seal

02A301227C oil seal

02A301227D oil seal

02A301227M oil seal

VW 02A301227C

Audi 02A301227C

VAG gearbox oil seal

15x24x6 gearbox seal

FAQ

What are the dimensions of CORTECO 01030118B?
The nominal dimensions are 15 mm shaft diameter, 24 mm housing diameter and 6 mm width.

What is CORTECO 01030118B used for?
It is a rotary shaft seal associated with VAG gearbox and transmission applications, including selected Audi, Volkswagen, Seat and Skoda vehicles.

Is CORTECO 01030118B equivalent to OE 02A301227C?
Yes. 02A301227C is one of the principal VAG OE references associated with this CORTECO seal.

Does it also replace VW 02A301227D?
Yes. 02A301227D is listed as a Volkswagen OE reference for this product.

What is BADUOOFX7?
BADUOOFX7 is the design/reference designation associated with this CORTECO Simmerring.

Are 01030118 and 01030118B related references?
Yes. Both references are encountered for this CORTECO seal. For product identification and SEO, retaining both 01030118 and 01030118B is useful.

Can I select this seal only by its 15x24x6 mm dimensions?
No. For an automotive application, the CORTECO part number, OE reference and gearbox compatibility should also be verified because seals with identical dimensions may have different designs or materials.
