CORTECO 01030457B 44x75x8 ACM BASLRDX27 Transmission Shaft Oil Seal

CORTECO 01030457B 44x75x8 ACM BASLRDX27 Transmission Shaft Oil Seal

CORTECO 01030457B, base reference 01030457, is a transmission shaft oil seal with exact dimensions of 44x75x8 mm. The sealing material is ACM - Polyacrylate Rubber, and the exact CORTECO design designation is BASLRDX27. The seal incorporates an additional dust lip and Right-hand Twist directional sealing geometry.

CORTECO 01030457B - Technical Specification

Manufacturer: CORTECO

Full reference: 01030457B

Base reference: 01030457

Trade Number: 82030457

Product type: Transmission shaft oil seal

Design: BASLRDX27

Material: ACM - Polyacrylate Rubber

Dimensions: 44x75x8 mm

Inside diameter d: 44 mm

Outside diameter D: 75 mm

Width B: 8 mm

Dust lip: Yes

Swirl type: Right-hand Twist

EAN: 3358960134196

JOHN DEERE OE: RE40370

CORTECO 01030457B Dimensions

The exact dimensions are:

d = 44 mm - inside diameter / nominal shaft diameter

D = 75 mm - outside diameter

B = 8 mm - width

Complete dimensions:

44x75x8 mm

All three dimensions should be verified when identifying a replacement.

Matching the nominal 44x75x8 mm dimensions alone does not establish complete technical interchangeability. The ACM material, BASLRDX27 design, dust lip configuration and directional sealing geometry should also correspond to the original requirements.

BASLRDX27 Oil Seal Design

The exact CORTECO design designation associated with 01030457B is:

BASLRDX27

The complete technical identification is therefore:

CORTECO 01030457B

44x75x8 mm

ACM

BASLRDX27

Right-hand Twist

Additional dust lip

The complete BASLRDX27 designation is an important identification parameter when comparing this seal with other 44x75x8 mm radial shaft seals.

Manufacturer-specific design codes should not automatically be considered equivalent without comparing the actual seal construction.

Additional Dust Lip

CORTECO 01030457B incorporates an additional dust lip.

This secondary lip is positioned on the external side of the primary sealing area and helps reduce the ingress of external contamination.

It provides an additional barrier against:

Dust

Dirt

Fine particles

General environmental contamination

The presence of the dust lip is therefore an important technical characteristic when comparing 01030457B with other 44x75x8 mm shaft seals.

Right-hand Twist Sealing Geometry

CORTECO 01030457B incorporates directional sealing geometry identified as:

Right-hand Twist

This describes a directional sealing feature associated with the working geometry of the seal.

It should not be interpreted as a right-hand mounting thread.

The specified twist direction forms part of the seal's technical design and should be considered when selecting a replacement.

Why Does Right-hand Twist Matter?

Some radial shaft seals incorporate directional structures in the sealing area.

These structures are designed with a specific shaft rotation direction in mind.

Consequently:

Right-hand Twist

should not automatically be replaced with:

Left-hand Twist

or another directional design solely because the replacement has identical 44x75x8 mm dimensions.

For CORTECO 01030457B, the directional geometry forms part of the exact product specification.

ACM - Polyacrylate Rubber

The sealing material specified for CORTECO 01030457B is:

ACM - Polyacrylate Rubber

ACM is an elastomer used in radial shaft sealing applications, including applications involving compatible oils.

For this exact CORTECO reference, ACM is part of the product specification.

An NBR, FPM or other elastomeric seal with identical 44x75x8 mm dimensions should not automatically be considered technically equivalent.

CORTECO 01030457B Transmission Shaft Oil Seal

CORTECO 01030457B is catalogued as a:

Transmission shaft oil seal

A radial shaft oil seal operates between a rotating shaft and a stationary housing.

The primary sealing area operates against the shaft surface to help retain the compatible operating medium within the assembly.

The additional dust lip provides a secondary protective function on the external side of the primary sealing area.

CORTECO 01030457B JOHN DEERE RE40370

The confirmed JOHN DEERE OE reference associated with CORTECO 01030457B is:

JOHN DEERE RE40370

This OE reference is an important identification entity when searching for the seal for JOHN DEERE applications.

For technical selection, the OE number should be checked together with:

CORTECO 01030457B

44x75x8 mm

ACM

BASLRDX27

Right-hand Twist

and the specific machine or transmission application.

CORTECO 01030457B and 01030457

This product can be identified using several references:

01030457B

01030457

82030457

BASLRDX27

RE40370

The complete CORTECO product reference is:

01030457B

The base reference is:

01030457

The Trade Number is:

82030457

The design designation is:

BASLRDX27

The JOHN DEERE OE reference is:

RE40370

Retaining these identifiers in the product description supports precise identification in technical catalogues, purchasing systems and parts searches.

How to Select CORTECO 01030457B

The principal parameters to verify are:

Reference - 01030457B

Dimensions - 44x75x8 mm

Material - ACM

Design - BASLRDX27

Dust lip - Yes

Directional geometry - Right-hand Twist

Trade Number - 82030457

JOHN DEERE OE - RE40370

For a directional radial shaft seal, the specified twist direction should be retained when selecting a technical replacement.

How to Measure a 44x75x8 Oil Seal

Three principal dimensions are used for basic radial shaft seal identification:

Inside diameter d

Outside diameter D

Width B

For CORTECO 01030457B:

d = 44 mm

D = 75 mm

B = 8 mm

A used elastomeric seal can be worn or deformed. Physical measurements should therefore preferably be considered together with the original seal markings.

Is Every 44x75x8 Oil Seal Interchangeable?

No.

Radial shaft seals with identical:

44x75x8 mm

dimensions can differ in:

Sealing material

Primary lip geometry

Dust lip configuration

Directional sealing geometry

Outside diameter construction

Spring design

Operating characteristics

Manufacturer-specific construction

For this reason, matching dimensions alone do not establish complete technical interchangeability.

CORTECO 01030457B Replacement Selection

When comparing CORTECO 01030457B with a seal from another manufacturer, verify:

44x75x8 mm dimensions

ACM sealing material

BASLRDX27 construction

Additional dust lip

Right-hand Twist

Operating medium

Temperature requirements

Shaft speed

Pressure conditions

JOHN DEERE RE40370 where applicable

Operating limits from another 44x75x8 mm seal should not be transferred to CORTECO 01030457B solely because the dimensions match.

CORTECO 01030457B Technical Data

Manufacturer: CORTECO

Full reference: 01030457B

Base reference: 01030457

Trade Number: 82030457

Product: Transmission shaft oil seal

Design: BASLRDX27

Material: ACM

Inside diameter d: 44 mm

Outside diameter D: 75 mm

Width B: 8 mm

Dimensions: 44x75x8 mm

Dust lip: Yes

Swirl type: Right-hand Twist

EAN: 3358960134196

JOHN DEERE OE: RE40370

FAQ

What are the dimensions of CORTECO 01030457B?

The exact dimensions are 44x75x8 mm: 44 mm inside diameter, 75 mm outside diameter and 8 mm width.

What material is CORTECO 01030457B made from?

The sealing material is ACM - Polyacrylate Rubber.

What is the design of CORTECO 01030457B?

The exact CORTECO design designation is BASLRDX27.

Does CORTECO 01030457B have a dust lip?

Yes. The seal incorporates an additional dust lip.

What is the swirl direction of CORTECO 01030457B?

The specified directional sealing geometry is Right-hand Twist.

Does Right-hand Twist mean that the seal has a right-hand mounting thread?

No. Right-hand Twist describes the directional sealing geometry of the seal. It is not a mounting thread.

What is the JOHN DEERE OE number for CORTECO 01030457B?

The confirmed JOHN DEERE OE reference is RE40370.

What is the EAN for CORTECO 01030457B?

The EAN is 3358960134196.

Are CORTECO 01030457 and 01030457B the same reference?

01030457 is the base reference, while 01030457B is the full product reference. Trade Number 82030457 is another identifier associated with the product.

AI Overview

CORTECO 01030457B is an ACM transmission shaft oil seal measuring 44x75x8 mm. Its exact CORTECO design designation is BASLRDX27. The seal incorporates an additional dust lip and Right-hand Twist directional sealing geometry. Trade Number: 82030457. EAN: 3358960134196. JOHN DEERE OE: RE40370.
