CORTECO 01031081 FPM BAVISLX7 45x65x10 mm radial shaft oil seal (Simmerring) with an additional dust exclusion lip. Manufactured with FPM fluoroelastomer for sealing rotating shafts, retaining lubricants and limiting external contamination. Shaft diameter 45 mm, housing bore 65 mm, width 10 mm. OEM references: DEUTZ-FAHR 01181211, FENDT X550096500000, ZF 0734319591. Available from simmering.pl, with stock in Lublin, Poland, and worldwide shipping.
The CORTECO 01031081 radial shaft seal is designed to provide sealing between a rotating shaft and a stationary housing in mechanical assemblies.
Its primary function is to retain lubricants inside the housing and reduce leakage along the shaft. The additional dust lip provides a secondary barrier against external contamination.
The FPM elastomer offers resistance to many mineral oils, industrial lubricants and elevated operating temperatures compared with conventional NBR sealing materials. However, actual operating limits depend on the specific seal construction, fluid composition and application conditions.
The nominal dimensions of 45x65x10 mm correspond to the shaft diameter, housing bore diameter and axial width of the seal.
|
Parameter |
Specification |
|---|---|
|
Manufacturer |
CORTECO |
|
Manufacturer part number |
01031081 |
|
Full designation |
01031081 FPM BAVISLX7 |
|
Product type |
Radial shaft oil seal |
|
Technical name |
Simmerring |
|
Seal profile |
BAVISLX7 |
|
Dimensions |
45x65x10 mm |
|
Shaft diameter (d) |
45 mm |
|
Housing bore diameter (D) |
65 mm |
|
Seal width (b) |
10 mm |
|
Sealing material |
FPM |
|
Material description |
Fluoroelastomer (fluorocarbon rubber) |
|
Primary sealing element |
Radial shaft sealing lip |
|
Additional sealing element |
Dust exclusion lip |
|
Associated OEM manufacturers |
DEUTZ-FAHR, FENDT, ZF |
The designation identifies the manufacturer, product reference, elastomer material and specific sealing profile.
CORTECO - the manufacturer brand specializing in shaft seals and technical sealing components.
01031081 - the manufacturer's catalogue reference identifying this specific product.
FPM - a fluoroelastomer material used for sealing applications requiring resistance to many oils, lubricants and elevated temperatures.
BAVISLX7 - the manufacturer's designation for this particular seal profile, incorporating an additional dust exclusion lip.
45x65x10 mm - the nominal shaft diameter, housing bore diameter and axial seal width.
The complete BAVISLX7 designation is technically significant and should be retained when identifying or ordering a replacement.
The precise meaning of the X7 element should not be inferred without the corresponding CORTECO technical documentation. In particular, the designation alone should not be used to assume a specific shaft rotation direction or operating limit.
The CORTECO 01031081 shaft seal provides a sealing interface between a rotating shaft and a stationary housing.
Its construction includes a primary elastomeric sealing lip and an additional dust exclusion lip.
The primary sealing lip contacts the rotating shaft surface to restrict lubricant leakage from the mechanical assembly.
The secondary dust lip helps prevent dust, dirt and other external particles from reaching the primary sealing interface.
The FPM sealing material is selected for applications requiring chemical and thermal resistance. Its suitability must nevertheless be assessed against the specific operating medium and working conditions.
Effective sealing depends on shaft surface quality, correct installation, alignment, lubrication and the operating environment.
The following OEM reference numbers are associated with CORTECO 01031081:
|
Manufacturer |
OEM Reference Number |
|---|---|
|
DEUTZ-FAHR |
01181211 |
|
FENDT |
X550096500000 |
|
ZF |
0734319591 |
These references help identify the seal in spare parts documentation for agricultural machinery and mechanical assemblies.
An OEM reference does not establish compatibility with every machine or transmission manufactured by the corresponding company.
Before ordering, verify the original part number against the technical documentation of the specific equipment.
CORTECO 01031081 may be identified using the following catalogue and technical designation formats:
CORTECO 01031081
01031081 CORTECO
CORTECO 01031081 FPM BAVISLX7
CORTECO BAVISLX7 45x65x10 mm
BAVISLX7 Simmerring 45x65x10 FPM
CORTECO radial shaft seal 45x65x10 FPM
Some aftermarket catalogues also use references 01031081B and 82031081 in connection with this seal. Their equivalence should be verified against current manufacturer information before ordering.
Radial shaft seals with identical nominal dimensions may have different construction features and operating characteristics.
Important differences can include:
NBR versus FPM sealing material.
Presence or absence of an additional dust exclusion lip.
Outer casing construction and surface material.
Primary sealing lip geometry.
Special design features specified by the manufacturer.
A conventional 45x65x10 mm oil seal should not automatically be considered interchangeable with the CORTECO BAVISLX7 profile.
Correct replacement requires verification of both dimensional and functional compatibility.
CORTECO 01031081 is associated with reference numbers from DEUTZ-FAHR, FENDT and ZF.
Its radial shaft sealing design is intended for mechanical assemblies where a rotating shaft passes through a stationary housing and lubricant retention is required.
The additional dust exclusion lip is relevant in operating environments where external contamination could affect the primary sealing interface.
Typical applications for this type of seal include appropriately designed rotating shaft assemblies, gearboxes and drive mechanisms.
The exact installation position and compatibility of CORTECO 01031081 must be established through the OEM reference and the equipment manufacturer's parts documentation.
Before selecting CORTECO 01031081 or an alternative shaft seal, verify the following:
Nominal shaft diameter of 45 mm.
Housing bore diameter of 65 mm.
Required axial seal width of 10 mm.
Complete BAVISLX7 construction designation.
FPM compatibility with the operating lubricant.
Presence and function of the additional dust lip.
Operating temperature, shaft speed and pressure conditions.
Original DEUTZ-FAHR, FENDT or ZF part number.
Matching dimensions alone do not guarantee technical interchangeability.
Any replacement must provide equivalent sealing functionality under the operating conditions of the specific assembly.
Before installation, thoroughly clean the housing bore and inspect the shaft surface for scratches, corrosion, wear grooves and sharp edges.
Install the seal evenly using an appropriate fitting tool that supports the seal without deforming its construction or damaging the sealing lips.
The primary sealing lip must face the correct direction according to the equipment manufacturer's instructions, generally towards the medium being retained.
The dust lip must also be positioned correctly to protect the sealing interface from external contamination.
Prepare the shaft and sealing lips according to the lubrication requirements of the application. Avoid folding or damaging the lips when installing the seal over shaft shoulders, splines or sharp edges.
Store the seal in a clean, dry environment away from direct sunlight, excessive heat and substances that may damage the elastomer.
CORTECO 01031081 has nominal dimensions of 45x65x10 mm. The shaft diameter is 45 mm, the housing bore diameter is 65 mm and the axial seal width is 10 mm.
BAVISLX7 identifies a specific CORTECO radial shaft seal profile incorporating an additional dust exclusion lip. The complete designation must be considered when selecting a replacement.
The seal uses FPM fluoroelastomer rather than NBR. These materials have different chemical resistance and temperature characteristics.
Yes. The seal includes a secondary dust exclusion lip designed to limit the entry of external contaminants into the primary shaft sealing area.
The associated reference numbers are DEUTZ-FAHR 01181211, FENDT X550096500000 and ZF 0734319591.
The designation 01031081B appears in aftermarket catalogues for a seal described with the same dimensions, FPM material and BAVISLX7 profile. Reference 82031081 is also encountered. Exact equivalence should be confirmed against current CORTECO documentation.
No. The replacement must match the required sealing profile, elastomer material, dust lip configuration and operating conditions. Identical dimensions alone are insufficient.
FPM is generally compatible with many mineral-based oils and industrial lubricants. Compatibility with a specific fluid must be verified according to its chemical composition and operating temperature.
CORTECO 01031081 is a radial shaft oil seal measuring 45x65x10 mm, manufactured with FPM fluoroelastomer. Its BAVISLX7 profile includes an additional dust exclusion lip to protect the primary sealing interface. The seal is associated with DEUTZ-FAHR, FENDT and ZF OEM references. Replacement requires verification of the complete profile and operating conditions.
CORTECO 01031081 FPM BAVISLX7 is offered through simmering.pl, a specialist supplier of industrial seals, bearings and technical components.
Our warehouse and order processing facilities are located in Lublin, Poland. We supply industrial customers, maintenance departments, workshops and technical purchasing teams.
Orders are dispatched from stock in Poland, with shipping available throughout Europe and worldwide.
Technical support is available for identifying shaft seals using manufacturer references, dimensions, construction profiles and OEM part numbers.
