CORTECO 01033251 AU/PU T20 90x98x5.7 - ZF Seal

CORTECO 01033251 AU/PU T20 90x98x5.7 - ZF Seal

CORTECO 01033251 is a polyurethane sealing ring with dimensions 90x98x5.7 mm, manufactured from AU/PU and featuring the T20 design. The product is also listed as CORTECO 01033251B and under commercial reference 82033251. The confirmed OE cross-reference is ZF 0634312342.

CORTECO 01033251 - Technical Data

Dimensions

The exact catalogue dimensions are:

90x98x5.7 mm

• inside diameter: 90 mm

• outside diameter: 98 mm

• width: 5.7 mm

Some aftermarket catalogues round the width to 6 mm. For technical identification, the precise CORTECO catalogue dimension 90x98x5.7 mm should be used.

AU / PU Polyurethane

The CORTECO dimensional catalogue specifies the material as:

AU

TecDoc-based catalogues describe CORTECO 01033251B as:

PU - polyurethane

Polyurethane sealing materials are commonly used where good mechanical strength and wear resistance are required.

Material specification is important when selecting an equivalent. This component should not automatically be replaced with a conventional NBR oil seal simply because its dimensions are similar.

T20 Design

The CORTECO design designation is:

T20

T20 is an important identification parameter for this sealing element.

When searching for or identifying the product, the following references are particularly useful:

• CORTECO 01033251

• CORTECO 01033251B

• CORTECO 82033251

• T20

• ZF 0634312342

• 90x98x5.7 mm

ZF Application

The CORTECO dimensional catalogue associates reference 01033251 with:

ZF

The confirmed OE reference is:

ZF 0634312342

This ZF number is one of the most important references for identifying the correct sealing element.

CORTECO 01033251 and ZF 0634312342

The confirmed cross-reference is:

CORTECO 01033251 / 01033251B → ZF 0634312342

Key identification parameters:

• dimensions: 90x98x5.7 mm

• material: AU / PU

• design: T20

• CORTECO reference: 01033251

• alternative reference: 01033251B

• commercial reference: 82033251

• OE reference: ZF 0634312342

For a ZF transmission or other ZF assembly, the OE reference should be checked against the removed component or the technical documentation for the specific assembly.

Machinery Applications

ZF OE reference 0634312342 appears in aftermarket catalogues for sealing components used in drivetrain and hydraulic assemblies of working machinery.

Aftermarket sources also associate this reference with selected assemblies used in Caterpillar construction machinery.

However, CORTECO 01033251 should not be selected solely by machine model. Different versions of ZF transmissions or assemblies may be installed in the same machine series.

The most reliable identification basis is:

ZF 0634312342 + 90x98x5.7 mm + T20 + AU/PU

CORTECO 01033251 and 01033251B

The product can be found under:

CORTECO 01033251

and

CORTECO 01033251B

Additional commercial reference:

82033251

All three references are useful when searching technical catalogues and aftermarket databases.

Alternative Search References

The product can also be searched as:

• CORTECO 01033251

• CORTECO 01033251B

• CORTECO 82033251

• 01033251

• 01033251B

• 82033251

• CORTECO T20

• T20 90x98x5.7

• ZF 0634312342

• 0634312342

• ZF seal 90x98x5.7

• sealing ring 90x98x5.7

• oil seal 90x98x5.7

• Simmerring 90x98x5.7

• PU seal 90x98x5.7

• polyurethane seal 90x98x5.7

• ZF seal 0634312342

Selection and Interchangeability

Before selecting an alternative to CORTECO 01033251, verify:

1. Inside diameter 90 mm.

2. Outside diameter 98 mm.

3. Width 5.7 mm.

4. AU / PU polyurethane material.

5. T20 design.

6. CORTECO reference 01033251 / 01033251B.

7. Commercial reference 82033251.

8. ZF OE reference 0634312342.

9. Exact installation position.

Matching the 90x98 mm diameters alone is not sufficient to confirm interchangeability.

The material, profile and geometry of the sealing element must correspond to the requirements of the specific ZF assembly.

FAQ

What are the dimensions of CORTECO 01033251?

The exact CORTECO catalogue dimensions are 90x98x5.7 mm.

Is the width 5.7 mm or 6 mm?

The CORTECO dimensional catalogue specifies 5.7 mm. Some aftermarket catalogues round this value to 6 mm.

What material is CORTECO 01033251 made from?

The CORTECO catalogue specifies AU, while TecDoc-based catalogues describe the material as PU - polyurethane.

What is the design of CORTECO 01033251?

The design/profile designation is T20.

Are 01033251 and 01033251B related references?

Yes. 01033251 appears in the CORTECO dimensional catalogue, while 01033251B is widely used in current aftermarket catalogues.

What is the commercial reference for CORTECO 01033251B?

The commercial reference is 82033251.

What ZF OE number corresponds to CORTECO 01033251?

The confirmed OE cross-reference is ZF 0634312342.

Is CORTECO 01033251 a standard NBR oil seal?

No. CORTECO 01033251 is specified as an AU / PU polyurethane sealing element with T20 design. It should not be replaced with a standard NBR oil seal based only on similar dimensions.

Is CORTECO 01033251 used in ZF assemblies?

Yes. The CORTECO catalogue indicates ZF as the application, and parts catalogues cross-reference the product with ZF 0634312342.

CORTECO 01033251 - Quick Technical Answer

CORTECO 01033251 / 01033251B is an AU/PU polyurethane sealing ring with T20 design and exact dimensions of 90x98x5.7 mm. The CORTECO commercial reference is 82033251 and the confirmed OE cross-reference is ZF 0634312342. Replacement selection should consider the complete dimensions, polyurethane material, T20 design and exact installation position.
