CORTECO Rotary Shaft Seal 01034641B 55x70x10/12 FPM

Applications of the CORTECO Shaft Seal

FPM Material Durability and Sealing Performance

Technical Design and Specifications

Main Description

The CORTECO rotary shaft seal 01034641B is a professional-grade oil seal engineered for sealing rotating shafts in manual gearboxes, heavy-duty vehicles, and demanding industrial applications. This shaft sealing ring ensures reliable protection against gearbox oil leakage while preventing dust, moisture, and abrasive particles from entering the transmission housing.

Manufactured from FPM (fluoroelastomer), the seal provides excellent resistance to oils and grease, elevated temperatures, and aggressive operating conditions. Compared to standard elastomers, FPM offers superior aging resistance and dimensional stability, making this rotary seal suitable for long-term operation in automotive and industrial drivetrains.

The seal features a double lip oil seal design (TC type) with an additional dust lip, enhancing sealing efficiency and extending shaft and gearbox service life. This construction delivers stable rotary sealing performance even under continuous operation and variable load conditions. The variable sealing profile allows precise shaft contact and compensates for minor installation tolerances, which is especially important during gearbox service and overhaul.

The CORTECO 01034641B oil seal is widely used in manual transmission systems, including applications in RENAULT TRUCKS, as well as in industrial machinery where high durability and reliable shaft sealing are critical. Common English search terms associated with this product include CORTECO rotary shaft seal, gearbox oil seal 55x70, double lip oil seal FPM, and rotary oil seal for manual transmission.

Technical Data

• Product type: Rotary shaft seal / oil seal

• Manufacturer: CORTECO

• Article number: 01034641B

• Reference numbers: 82034641 / BAVISLDRWX67

• Inner diameter: 55 mm

• Outer diameter: 70 mm

• Working height: 10 mm

• Total height: 12 mm

• Material: FPM (fluoroelastomer)

• Design: Double lip oil seal with dust lip

• Function: Rotary shaft sealing

• Application: Manual gearbox shaft

• Compatibility: RENAULT TRUCKS

FAQ - Frequently Asked Questions

What is the difference between a single lip and double lip oil seal?
A double lip oil seal includes an additional dust lip that protects the shaft from external contamination and extends service life.

Why is FPM used for gearbox oil seals?
FPM offers high resistance to oils, grease, heat, and aging, making it ideal for demanding transmission applications.

How do I select the correct rotary shaft seal size?
Match the inner diameter to the shaft, the outer diameter to the housing bore, and the height to the available installation space.

Is this seal suitable for continuous operation?
Yes, it is designed for long-term, continuous use in manual gearboxes and industrial machinery.

Can this seal be used in automotive and industrial systems?
Yes, it is suitable for both automotive transmissions and industrial rotary sealing applications.
