Corteco 12000732 ACM BASL 50x80x10 rotary shaft seal

Industrial applications

The Corteco 12000732 ACM BASL 50x80x10 rotary shaft seal is designed for demanding industrial and automotive systems where elevated temperatures and continuous operation are present. This rotary shaft seal corteco performs reliably in oil-lubricated environments, ensuring long-term sealing efficiency.

Typical applications include:

• gearboxes and transmission systems
• wheel hub sealing in commercial vehicles
• rotating shafts in industrial machinery
• forklifts and logistics equipment

The ACM material makes this seal particularly suitable for applications where standard NBR seals would degrade faster under heat.

Construction and design

This simmerring features a BASL design, meaning it is equipped with a double sealing lip and an additional dust protection lip. This configuration significantly improves sealing performance by preventing both oil leakage and ingress of contaminants.

The sealing lip made from ACM material maintains flexibility and stability even at higher temperatures. The reinforced outer structure ensures proper fitment and secure installation in the housing.

Technical parameters

• inner diameter: 50 mm
• outer diameter: 80 mm
• width: 10 mm
• material: ACM polyacrylic rubber
• type: BASL double lip with dust protection
• temperature resistance: up to approx. 150 degrees C

Technical snippet:
The 50x80x10 ACM BASL rotary shaft seal is engineered for high-temperature oil sealing applications, providing reliable protection against leakage and contamination in dynamic systems.

Performance advantages

Compared to standard oil seals, this corteco rotary shaft seal offers improved durability and resistance in thermally demanding environments.

Key benefits:

• enhanced temperature resistance up to 150 degrees C
• good resistance to oils and lubricants
• effective dust and contamination protection
• extended service life in dynamic applications
• stable sealing performance over time

This makes it a strong choice for industrial and automotive professionals seeking reliability.

Main description

The Corteco 12000732 ACM BASL 50x80x10 rotary shaft seal is a high-quality sealing solution developed for protecting rotating shafts against oil leakage and external contamination in medium to high temperature environments.

This rotary shaft seal corteco in size 50x80x10 is manufactured from ACM polyacrylic rubber, which offers improved thermal resistance compared to standard sealing materials. It is especially effective in applications such as gearboxes, hubs, and industrial drive systems where temperature stability and oil resistance are critical.

The BASL design with a double sealing lip and dust lip ensures higher sealing efficiency, reducing the risk of leakage while protecting internal components from dirt and debris. This contributes to longer service intervals and reduced maintenance costs.

Additionally, this model is used as an OEM replacement, including compatibility with FIAT OM CARELLI ELEV reference 9435302, making it a reliable choice for both maintenance and new installations.

FAQ

1. Is this ACM rotary shaft seal suitable for high temperatures?
Yes, it can operate up to approximately 150 degrees C, making it suitable for demanding applications.

2. What does BASL design mean?
It indicates a double sealing lip with an additional dust lip for improved protection.

3. Where is this seal typically used?
In gearboxes, wheel hubs, industrial machinery, and transport equipment.

4. Can it replace OEM parts?
Yes, it is compatible with selected OEM references such as FIAT OM CARELLI ELEV 9435302.
