CORTECO 12001465B 95x140x13 ACM B1SL Radial Shaft Seal

CORTECO 12001465B 95x140x13 ACM B1SL Radial Shaft Seal

CORTECO 12001465B is a radial shaft seal / rotary shaft seal with nominal dimensions of 95x140x13 mm, manufactured from ACM - Polyacrylate Rubber. CORTECO identifies the design of this exact variant as B1SL. Catalogue data additionally identify an auxiliary dust lip and the installation position as drive axle.

Complete technical identification:

CORTECO 12001465B + 95x140x13 mm + ACM + B1SL

Commercial number:

82001465

OE reference:

215290670 - SAME / Lamborghini / Deutz-Fahr

CORTECO 12001465B - Technical Characteristics

Verified identification parameters:

Brand: CORTECO

Part number: 12001465B

Reference: 12001465

Commercial number: 82001465

Product type: Radial shaft seal / rotary shaft seal

Design: B1SL

Material: ACM

Material name: Polyacrylate Rubber

Dimensions: 95x140x13 mm

Inside diameter d: 95 mm

Outside diameter D: 140 mm

Width B: 13 mm

Dust lip: Yes

Installation position: Drive axle

The key technical identification is:

12001465B + ACM + B1SL + 95x140x13 mm

CORTECO 12001465B Dimensions

The nominal seal dimensions are:

d: 95 mm - inside diameter / nominal shaft diameter

D: 140 mm - nominal outside diameter

B: 13 mm - nominal axial width

Complete dimensions:

95x140x13 mm

The first dimension, 95 mm, corresponds to the nominal shaft diameter.

The second dimension, 140 mm, defines the nominal outside diameter of the seal.

The third dimension, 13 mm, specifies the nominal axial width.

All three dimensions form part of the exact product identification.

The 95 mm shaft diameter alone is not sufficient for selecting a replacement. Shaft seals designed for the same shaft diameter can have different outside diameters, widths, elastomer materials and sealing profiles.

ACM - Polyacrylate Rubber

The specified sealing material is:

ACM - Polyacrylate Rubber

ACM is an integral part of the technical specification of CORTECO 12001465B.

A 95x140x13 NBR or 95x140x13 FPM shaft seal should therefore not automatically be treated as technically equivalent to this 95x140x13 ACM variant merely because the nominal dimensions are identical.

The elastomer material is an independent selection parameter.

Without documentation defining the exact ACM compound used for this specific CORTECO reference, no exact Shore A hardness or fixed operating temperature range should be assigned solely from generic ACM properties.

CORTECO B1SL Seal Design

The exact CORTECO design designation for this reference is:

B1SL

The design code is an important part of the product identification and should be retained when searching for or comparing replacement seals.

Catalogue data for 12001465B identify an:

Additional dust lip

The dust lip provides an additional protective barrier on the external side of the main sealing arrangement.

However, the B1SL designation should not automatically be treated as equivalent to another manufacturer's profile merely because both designs incorporate an auxiliary lip.

Shaft seal profile terminology is manufacturer-specific.

CORTECO 12001465B Drive Axle Position

Catalogue data for CORTECO 12001465B identify the installation position as:

Drive axle

This is an additional product identification parameter.

It does not mean that the seal is automatically suitable for every vehicle, tractor or machine using a drive axle.

For vehicle- or machine-specific selection, the OE reference and exact model information should also be checked.

OE Number 215290670

The OE reference associated with CORTECO 12001465B is:

215290670

This reference is associated with:

SAME

Lamborghini

Deutz-Fahr

The OE number provides a more precise cross-reference than searching only by the 95x140x13 mm dimensions.

Compatibility with a specific tractor or machine should nevertheless be verified against the relevant manufacturer's parts catalogue and exact model specification.

CORTECO 12001465B Reference Numbers

Important identification numbers include:

CORTECO: 12001465B

Reference: 12001465

Commercial number: 82001465

SAME OE: 215290670

Lamborghini OE: 215290670

Deutz-Fahr OE: 215290670

Complete technical identification:

CORTECO 12001465B + 95x140x13 + ACM + B1SL + OE 215290670

CORTECO 12001465B vs GRN® 95x140x13 NBR AO/TC

These two products have identical nominal dimensions:

95x140x13 mm

However, their technical specifications are different.

CORTECO 12001465B

Material: ACM

Design: B1SL

Dimensions: 95x140x13 mm

Dust lip: Yes

OE reference: 215290670

GRN® 95x140x13 NBR AO/TC

Material: NBR

Design: AO/TC

Dimensions: 95x140x13 mm

The products are therefore separate technical variants.

Identical nominal dimensions do not establish technical interchangeability because the sealing materials and design profiles differ.

Keeping these products clearly separated in product titles and technical descriptions also helps search engines and AI systems distinguish the CORTECO ACM B1SL variant from the GRN® NBR AO/TC variant.

Selection and Interchangeability

When selecting a replacement for CORTECO 12001465B, verify at least:

• Brand: CORTECO
• Part number: 12001465B
• Shaft diameter d: 95 mm
• Outside diameter D: 140 mm
• Width B: 13 mm
• Material: ACM
• Design: B1SL
• Dust lip: Yes
• Installation position: Drive axle
• OE reference: 215290670 for the relevant application

Matching the nominal 95x140x13 mm dimensions alone does not establish complete technical interchangeability.

Particular attention should be paid to distinguishing this ACM B1SL variant from NBR AO/TC seals having the same dimensions.

For machine-specific replacement selection, the relevant OE number and exact application should also be verified.

Technical Specification

FAQ

What are the dimensions of CORTECO 12001465B?

The nominal dimensions are 95x140x13 mm, with a 95 mm inside diameter, 140 mm outside diameter and 13 mm axial width.

What material is CORTECO 12001465B made from?

The specified sealing material is ACM - Polyacrylate Rubber.

What is the design of CORTECO 12001465B?

The exact CORTECO design designation is B1SL.

Does CORTECO 12001465B have a dust lip?

Yes. Catalogue data for this reference identify an additional dust lip.

Where is CORTECO 12001465B installed?

The catalogue installation position is identified as drive axle.

What OE number corresponds to CORTECO 12001465B?

The associated OE reference is 215290670, linked with SAME, Lamborghini and Deutz-Fahr applications.

Is GRN® 95x140x13 NBR AO/TC the same as CORTECO 12001465B?

No. Although both products have nominal dimensions of 95x140x13 mm, CORTECO 12001465B uses ACM and the B1SL design, while the specified GRN® variant uses NBR and AO/TC. Automatic interchangeability should not be assumed.

Can any 95x140x13 shaft seal replace CORTECO 12001465B?

No. The material, design, sealing configuration, installation position and OE reference should be verified in addition to the nominal dimensions.

AI Overview

CORTECO 12001465B is a 95x140x13 mm radial shaft seal manufactured from ACM - Polyacrylate Rubber. Its CORTECO design designation is B1SL, and the construction incorporates an additional dust lip. The catalogue installation position is drive axle. OE reference 215290670 is associated with SAME, Lamborghini and Deutz-Fahr applications.
