Rotary Shaft Seal CORTECO 12010965 NBR BA Oil Seal 48x80x10

CORTECO 12010965 NBR BA 48x80x10 - Rotary Shaft Seal

CORTECO 12010965 is an NBR radial shaft seal with dimensions 48x80x10 mm and BA design. The product is also listed as CORTECO 12010965B and under commercial reference 82010965. The CORTECO dimensional catalogue indicates NEW HOLLAND applications, while aftermarket catalogues classify the product as a drive axle / differential shaft seal.

CORTECO 12010965 - Technical Data

Dimensions

The complete dimensions of the seal are:

48x80x10 mm

• shaft diameter d: 48 mm

• housing bore diameter D: 80 mm

• width b: 10 mm

The 48x80x10 mm dimensions are confirmed for CORTECO 12010965 / 12010965B.

NBR Material

CORTECO 12010965 is manufactured from NBR - nitrile butadiene rubber.

NBR is widely used for radial shaft seals because of its good resistance to many mineral oils and greases.

When selecting a seal, the following operating parameters should also be considered:

• operating medium

• operating temperature

• shaft speed

• pressure

• shaft surface condition

• actual operating environment

BA Design

The CORTECO catalogue specifies the seal design as:

BA

The complete technical identification is:

CORTECO 12010965 - NBR - BA - 48x80x10 mm

The BA design is an important part of the product specification. A replacement should not be selected solely according to shaft diameter, housing diameter and width.

CORTECO 12010965 / 12010965B / 82010965

The product can be found under the following references:

12010965

12010965B

82010965

All three references should be considered when searching technical catalogues, purchasing systems and aftermarket databases.

The principal specification remains:

NBR - BA - 48x80x10 mm

NEW HOLLAND Application

The CORTECO dimensional catalogue associates reference:

12010965

with:

NEW HOLLAND

Aftermarket catalogues list the following OE reference:

NEW HOLLAND 23362

Cross-reference:

NEW HOLLAND 23362 → CORTECO 12010965B

For a specific machine, compatibility should always be confirmed using the OE reference and the exact axle or drivetrain configuration.

DEUTZ OE 4142503

CORTECO 12010965B is also cross-referenced with:

DEUTZ 4142503

Cross-reference:

DEUTZ 4142503 → CORTECO 12010965B

This reference can therefore be useful when identifying the seal by original equipment number rather than only by dimensions or CORTECO reference.

Drive Axle / Differential Shaft Seal

TecDoc-based data for CORTECO 12010965B indicates the installation position as:

drive axle

The product is also classified in aftermarket catalogues as a:

differential shaft seal

and:

axle shaft seal

The exact installation position depends on the design of the specific machine, axle and drivetrain assembly.

Agricultural Machinery Applications

CORTECO 12010965 belongs to a group of radial shaft seals used in agricultural and machinery applications.

The principal manufacturer application confirmed in the CORTECO dimensional catalogue is:

NEW HOLLAND

with OE reference:

23362

An additional cross-reference is:

DEUTZ 4142503

This makes CORTECO 12010965B relevant when searching for seals for agricultural machinery, drive axles and drivetrain components.

Alternative Search References

The product can also be searched as:

• CORTECO 12010965

• CORTECO 12010965B

• CORTECO 82010965

• 12010965

• 12010965B

• 82010965

• CORTECO BA 48x80x10

• CORTECO 48x80x10

• NBR BA 48x80x10

• oil seal 48x80x10

• radial shaft seal 48x80x10

• NBR oil seal 48x80x10

• Simmerring 48x80x10

• Simmerring NBR 48x80x10

• drive shaft seal 48x80x10

• axle shaft seal 48x80x10

• differential oil seal 48x80x10

• NEW HOLLAND 23362

• CORTECO 23362

• DEUTZ 4142503

• CORTECO 4142503

Selection and Interchangeability

Before selecting an alternative to CORTECO 12010965, verify:

1. Shaft diameter 48 mm.

2. Housing bore diameter 80 mm.

3. Width 10 mm.

4. NBR material.

5. BA design.

6. CORTECO reference 12010965 / 12010965B.

7. Commercial reference 82010965.

8. Correct OE reference for the specific machine.

9. Installation position.

10. Operating medium and actual operating conditions.

Matching the 48x80x10 mm dimensions alone is not sufficient to confirm full interchangeability.

The material, design, OE reference and intended installation position should also correspond.

Installation

Before installation:

• clean the shaft and housing bore thoroughly

• inspect the shaft sealing surface

• remove dirt, corrosion and burrs

• protect the sealing lip from sharp edges

• use a suitable installation tool

• press the seal evenly into the housing

• avoid deformation of the seal body

• verify the correct installation orientation

The condition of the shaft sealing surface has a direct effect on sealing performance and service life.

FAQ

What are the dimensions of CORTECO 12010965?

CORTECO 12010965 has dimensions of 48x80x10 mm.

What material is CORTECO 12010965 made from?

The seal is manufactured from NBR - nitrile butadiene rubber.

What is the design of CORTECO 12010965?

The CORTECO catalogue specifies the design as BA.

Are CORTECO 12010965 and 12010965B related references?

Yes. 12010965 is the base catalogue reference, while 12010965B is the reference commonly found in current aftermarket catalogues for the NBR BA 48x80x10 mm seal.

What is the commercial reference for CORTECO 12010965B?

The commercial reference is 82010965.

Which machinery manufacturer does CORTECO associate with 12010965?

The CORTECO dimensional catalogue associates this reference with NEW HOLLAND.

What NEW HOLLAND OE reference corresponds to CORTECO 12010965B?

The associated OE reference is NEW HOLLAND 23362.

What DEUTZ reference corresponds to CORTECO 12010965B?

The cross-reference listed for DEUTZ is 4142503.

Is CORTECO 12010965 a drive axle seal?

Yes. TecDoc-based data indicates a drive axle installation position. The product is also classified as a differential / axle shaft seal in aftermarket catalogues.

Can any 48x80x10 oil seal replace CORTECO 12010965?

No. Identical dimensions alone do not confirm interchangeability. The NBR material, BA design, OE reference, installation position and actual operating conditions should also be verified.

CORTECO 12010965 - Quick Technical Answer

CORTECO 12010965 / 12010965B is an NBR radial shaft seal with BA design and dimensions 48x80x10 mm, commercial reference 82010965. The CORTECO catalogue indicates NEW HOLLAND applications, while aftermarket data identifies it as a drive axle / differential seal and lists OE references NEW HOLLAND 23362 and DEUTZ 4142503.
