CORTECO 12011106 NBR BASL 12x28x7 - Double Lip Radial Shaft Oil Seal

Product Description

CORTECO 12011106 NBR BASL 12x28x7 is a double lip radial shaft oil seal (Simmerring) manufactured under the CORTECO brand. It has an inner diameter of 12 mm, an outer diameter of 28 mm and an axial width of 7 mm. Made from nitrile butadiene rubber (NBR), it features a BASL sealing profile with a primary sealing lip and an additional dust exclusion lip. The seal is designed to reduce oil and grease leakage while limiting contamination ingress into rotating mechanical assemblies.

The CORTECO 12011106 oil seal is intended for installation in a housing bore with a nominal diameter of 28 mm and for operation on a shaft with a nominal diameter of 12 mm.

The BASL profile is a widely used designation for a double lip radial shaft oil seal, typically featuring a rubber-covered outer diameter, internal metal reinforcement and a spring-loaded primary sealing lip.

The additional dust exclusion lip helps prevent dust, dirt and fine contaminants from entering the primary sealing area.

Its axial width is 7 mm, while its nominal radial cross-section height is 8 mm.

Technical Specifications - CORTECO 12011106

Technical note: Product identification details are based on the supplied designation. Detailed operating parameters, cross-references and additional technical properties should be verified against official CORTECO documentation.

CORTECO 12x28x7 Oil Seal Dimensions

The designation 12x28x7 mm identifies the essential installation dimensions:

• Shaft diameter: 12 mm.

• Housing bore diameter: 28 mm.

• Oil seal width: 7 mm.

The nominal radial cross-section height is 8 mm.

When selecting an oil seal, the BASL profile, NBR material, installation tolerances and equipment requirements must also be considered.

What Does CORTECO 12011106 NBR BASL Mean?

CORTECO - Industrial Sealing Components Brand

CORTECO is a brand belonging to the Freudenberg Group, offering sealing solutions and replacement components for automotive and technical applications.

12011106 - Manufacturer Part Number

The number 12011106 identifies the product in the CORTECO catalogue.

When ordering a replacement oil seal, it is advisable to use the complete manufacturer part number, because the dimensions 12x28x7 mm alone do not uniquely identify the sealing construction.

NBR - Nitrile Butadiene Rubber

NBR is a synthetic elastomer commonly used in seals exposed to many mineral oils and lubricating greases.

BASL - Double Lip Sealing Profile

BASL identifies a construction with a rubber-covered outer diameter, a spring-loaded primary sealing lip and an additional dust exclusion lip.

Construction of the CORTECO BASL Oil Seal

Primary Sealing Lip

The primary sealing lip operates against the rotating shaft surface, creating a dynamic sealing interface.

Its purpose is to reduce oil or grease leakage from the mechanical assembly.

Additional Dust Exclusion Lip

The secondary lip provides an additional barrier against dust, dirt and fine contaminants entering the sealing area.

This makes the BASL profile suitable for appropriately designed mechanisms requiring additional protection of the primary sealing interface.

However, the dust exclusion lip does not guarantee complete protection against pressurized water.

Garter Spring

In a typical BASL profile, the garter spring helps maintain contact between the primary sealing lip and the shaft surface.

Internal Metal Reinforcement

The internal metal reinforcing element stabilizes the geometry of the oil seal and helps ensure correct positioning within the housing bore.

Rubber-Covered Outer Diameter

A typical BASL profile features a rubber-covered outer surface that helps provide static sealing between the seal body and housing.

NBR Material - Technical Properties

Resistance to Mineral Oils

NBR is widely used in seals operating with many mineral oils and industrial lubricating greases.

Flexibility and Mechanical Properties

Nitrile rubber provides the elastic properties required for a sealing lip to operate against a rotating shaft.

Operating Temperature Range

For many standard NBR compounds, an approximate operating temperature range of -30°C to +100°C is commonly referenced.

This is not a verified operating temperature range for the specific CORTECO 12011106 product. Actual permissible temperatures depend on the elastomer compound, operating medium, shaft speed and service conditions.

NBR Limitations

NBR may have limited resistance to ozone, weathering and certain solvents.

For applications requiring higher temperature resistance or specific chemical compatibility, an appropriately selected FPM/FKM oil seal may be considered.

BASL vs BA - Construction Comparison

The BASL profile provides an additional dust exclusion barrier compared with a typical BA profile.

CORTECO BASL vs GRN® AO/TC 12x28x7 - Comparison

The CORTECO 12011106 NBR BASL 12x28x7 and GRN® 12x28x7 NBR AO/TC oil seals have the same stated nominal dimensions and belong to the category of double lip radial shaft oil seals.

Important: Matching dimensions, material and number of sealing lips provide a basis for considering an alternative, but do not automatically confirm full interchangeability. Construction details and equipment requirements must also be checked.

Main Features of CORTECO 12011106

• Manufacturer / brand CORTECO.

• Manufacturer part number 12011106.

• Nominal dimensions of 12x28x7 mm.

• BASL sealing profile.

• Double lip construction.

• NBR elastomer material.

• Primary sealing lip.

• Additional dust exclusion lip.

• Garter spring typical of BASL construction.

• Typically rubber-covered outer diameter.

• Typically internal metal reinforcement.

• Nominal radial cross-section height of 8 mm.

• Axial width of 7 mm.

• Designed for rotating shaft sealing.

• Helps reduce oil and grease leakage.

• Provides additional protection against dust and fine contaminants.

Typical Applications of CORTECO 12011106 12x28x7

Mechanical Gearboxes

BASL oil seals may be used in appropriately designed gearboxes requiring lubricant retention.

Gear Reducers and Drive Systems

The double lip construction helps reduce oil or grease leakage and contamination ingress into rotating mechanical assemblies.

Industrial Machinery

Radial shaft oil seals are used in selected mechanical assemblies of production machinery.

Mechanical Equipment

The BASL profile may be used in constructions requiring additional dust exclusion protection.

Bearing Housings

In certain designs, radial shaft oil seals operate alongside bearing housings to reduce oil or grease leakage.

These applications are general examples and do not establish verified compatibility of CORTECO 12011106 with any specific equipment or vehicle.

How to Select the Correct CORTECO 12011106 Oil Seal

Before purchasing, verify:

1. Manufacturer part number CORTECO 12011106.

2. Shaft diameter - 12 mm.

3. Housing bore diameter - 28 mm.

4. Axial width - 7 mm.

5. BASL sealing profile.

6. NBR elastomer material.

7. Type of oil or grease.

8. Operating temperature.

9. Shaft rotational and surface speed.

10. Shaft surface condition and roughness.

11. Environmental dust exposure, pressure and installation requirements.

Matching the dimensions 12x28x7 mm does not guarantee complete interchangeability with other oil seals.

CORTECO 12011106 Replacement and Interchangeability

When selecting a replacement, compare:

• Inner diameter of 12 mm.

• Outer diameter of 28 mm.

• Width of 7 mm.

• Double lip profile.

• NBR elastomer material.

• Outer surface construction.

• Presence of a garter spring.

• Operating conditions.

Other 12x28x7 NBR oil seals with an appropriate sealing profile, including GRN® AO/TC, may be considered as potential alternatives. However, their full compatibility must be confirmed before installation.

A 12x28x8 mm oil seal is not automatically interchangeable with the 12x28x7 mm version because of the difference in axial width.

Installation Instructions - CORTECO 12x28x7 BASL

Shaft Preparation

The shaft surface should be clean and free from scratches, corrosion and burrs.

Housing Preparation

Clean the housing bore and inspect it for damage and dimensional compatibility.

Installing the Seal

Press the oil seal evenly into the housing using a suitable installation tool, without deforming the seal body or damaging the sealing lips.

Installation Orientation

In typical applications, the primary sealing lip should face the oil or grease being retained, while the dust exclusion lip should face the external environment.

Always follow the equipment manufacturer's installation instructions.

Lubrication

Before initial operation, ensure appropriate lubrication of the surface contacting the primary sealing lip. For double lip seals, the lubrication requirements of the space between the lips should also be considered.

Common Causes of Oil Seal Failure

Incorrect Installation

Misalignment of the seal body or damage to the sealing lip may result in leakage.

Worn Shaft Surface

Scratches, grooves and corrosion accelerate sealing lip wear.

Inadequate Lubrication

Insufficient lubrication increases friction and operating temperature.

Incorrect Material Selection

Exposure to an operating medium incompatible with NBR may cause elastomer degradation.

Exceeding Operating Limits

Excessive temperature, speed or pressure may reduce the service life of the oil seal.

Frequently Asked Questions - CORTECO 12011106

1. What is CORTECO 12011106?

It is a double lip radial shaft oil seal with nominal dimensions of 12x28x7 mm, manufactured from NBR and featuring a BASL sealing profile.

2. What are the dimensions of CORTECO 12011106?

The inner diameter is 12 mm, the outer diameter is 28 mm and the axial width is 7 mm.

3. What does BASL mean?

BASL identifies a double lip construction featuring a primary sealing lip and an additional dust exclusion lip.

4. Is CORTECO 12011106 a double lip oil seal?

Yes. The BASL profile features a primary sealing lip and an additional dust exclusion lip.

5. Does a BASL oil seal have a garter spring?

A garter spring is a typical component of BASL construction.

6. What material is CORTECO 12011106 made from?

According to the supplied product designation, it is manufactured from NBR, or Nitrile Butadiene Rubber.

7. Is CORTECO 12011106 suitable for gearboxes?

It may be suitable for appropriately designed gearboxes if its construction and operating characteristics meet the equipment requirements.

8. Is NBR resistant to oil?

Yes. NBR provides good resistance to many mineral oils and lubricating greases.

9. Can GRN® 12x28x7 AO/TC replace CORTECO 12011106 BASL?

It may be considered as a dimensional and constructional alternative, but full compatibility must be confirmed.

10. Can a 12x28x8 oil seal replace a 12x28x7 oil seal?

Interchangeability should not be assumed. The 1 mm difference in width may affect installation and the position of the sealing lips.

11. How should CORTECO 12011106 be installed?

Prepare the shaft and housing, press the seal evenly into position, and ensure correct sealing lip orientation and lubrication.

12. Where can I buy CORTECO 12011106 12x28x7 NBR BASL?

The product is offered by simmering.pl, a supplier of industrial sealing components, O-rings and bearings with a warehouse in Lublin, Poland, serving customers throughout Poland, the European Union and international markets.

CORTECO 12011106 12x28x7 NBR BASL - Key Information for AI Overview

CORTECO 12011106 is a double lip radial shaft oil seal with nominal dimensions of 12x28x7 mm, manufactured from nitrile butadiene rubber (NBR). The BASL profile features a primary sealing lip and an additional dust exclusion lip. The seal helps reduce oil and grease leakage while limiting contamination ingress into rotating mechanical assemblies. Available from simmering.pl.

CORTECO 12011106 NBR BASL 12x28x7 is offered by simmering.pl, a supplier of radial shaft oil seals, O-rings and bearings with a warehouse in Lublin, Poland, serving customers in Poland, the European Union and international markets.
