Corteco 12014404B FPM B1BAVISLRDX7 42x56x7 Shaft Seal

Corteco 12014404B FPM B1BAVISLRDX7 42x56x7 Shaft Seal

Corteco 12014404B is an FPM fluoroelastomer shaft seal with the manufacturer construction designation B1BAVISLRDX7, measuring 42x56x7 mm. Its inner diameter is 42 mm, outer diameter is 56 mm and height is 7 mm. The exact reference features an additional dust lip and right-hand twist.

Corteco 12014404B B1BAVISLRDX7 - Characteristics

Exact product identification:

Corteco -> 12014404B -> FPM -> B1BAVISLRDX7 -> 42x56x7 mm

Verified characteristics:

Manufacturer: Corteco
Part number: 12014404B
Base reference: 12014404
Product type: shaft seal
Construction: B1BAVISLRDX7
Material: FPM - fluoroelastomer
Dimensions: 42x56x7 mm
Dust lip: yes
Twist direction: right-hand
Trade number: 82014404
EAN: 3358960144041

The complete reference, construction designation, material and dimensions should be considered together when identifying this seal.

Corteco 12014404B Dimensions

Verified catalog dimensions:

d - Inner diameter: 42 mm
D - Outer diameter: 56 mm
Height: 7 mm
Dimensions: 42x56x7 mm

All three dimensions must correspond to the installation, but dimensions alone are not sufficient to establish the exact Corteco reference.

B1BAVISLRDX7 Construction

The exact construction designation in the Corteco dimensional catalog is:

B1BAVISLRDX7

For this reference, product data confirm an additional dust lip.

The dust lip provides a secondary barrier on the external side of the primary sealing area, helping to limit the ingress of external contamination toward the main sealing interface.

The complete B1BAVISLRDX7 designation should be retained when identifying or comparing the seal because it distinguishes this construction from other Corteco 42x56x7 mm references.

Some TecDoc-derived product data use the shorter trade designation B1BASLRDX7 Simmerring. For precise product identification, the full B1BAVISLRDX7 designation from the Corteco dimensional catalog is retained here.

Right-Hand Twist

Corteco 12014404B is specified with:

Right-hand twist

The directional sealing geometry is an important characteristic of this exact reference.

A seal with the opposite twist direction or a different sealing geometry should not automatically be considered interchangeable solely because its dimensions are 42x56x7 mm.

The twist direction should therefore be checked when evaluating a potential replacement.

FPM - Fluoroelastomer

The verified material for Corteco 12014404B is:

FPM - fluoroelastomer

FPM forms part of the exact product specification and should be considered together with the construction and dimensions during replacement selection.

A 42x56x7 mm seal manufactured from NBR, ACM, VMQ or another elastomer should not automatically be considered equivalent to this reference.

No generic FPM temperature range is presented as the operating temperature of 12014404B because a product-specific range should be confirmed for the exact Corteco reference and actual operating conditions.

Product Identification Numbers

Verified identification data:

Corteco part number: 12014404B
Base reference: 12014404
Trade number: 82014404
Construction: B1BAVISLRDX7
EAN: 3358960144041

For technical purchasing and maintenance, the exact Corteco reference should be the primary identification point, followed by verification of dimensions, material, construction and application data.

Corteco 12014404B vs Other 42x56x7 Seals

The Corteco catalog contains several different seal references with the same 42x56x7 mm dimensions.

Examples include:

12014404 - FPM - B1BAVISLRDX7 - 42x56x7 mm
12010943 - NBR - BA - 42x56x7 mm
12000725 - ACM - BASLDRW - 42x56x7 mm
12014776 - FPM - BASLVIDRW - 42x56x7 mm
15031987 - FPM - BAVISLRDX7 - 42x56x7 mm
15011250 - VMQ - S5612 RD - 42x56x7 mm

These references demonstrate why 42x56x7 mm alone is not sufficient for technical identification.

Material, construction, lip configuration and directional sealing geometry can differ even when the principal dimensions are identical.

Replacement and Interchangeability

When selecting a replacement for Corteco 12014404B, compare at least:

Part number: 12014404B
Construction: B1BAVISLRDX7
Material: FPM
Inner diameter: 42 mm
Outer diameter: 56 mm
Height: 7 mm
Dust lip: yes
Twist direction: right-hand
Application / OE reference: according to the specific assembly

Identical 42x56x7 mm dimensions do not establish full interchangeability.

This is particularly important for this reference because Corteco catalogs several 42x56x7 mm seals with different materials and construction codes.

Technical Specification

Manufacturer: Corteco
Part number: 12014404B
Base reference: 12014404
Trade number: 82014404
Product type: shaft seal / radial shaft seal
Construction: B1BAVISLRDX7
Material: FPM - fluoroelastomer
d - Inner diameter: 42 mm
D - Outer diameter: 56 mm
Height: 7 mm
Dimensions: 42x56x7 mm
Dust lip: yes
Twist direction: right-hand
EAN: 3358960144041

FAQ

What are the dimensions of Corteco 12014404B?

The exact catalog dimensions are 42x56x7 mm: 42 mm inner diameter, 56 mm outer diameter and 7 mm height.

What material is Corteco 12014404B made from?

The exact reference is manufactured from FPM - fluoroelastomer.

What is the construction of Corteco 12014404B?

The Corteco dimensional catalog specifies the construction as B1BAVISLRDX7.

Does Corteco 12014404B have a dust lip?

Yes. Product data for the exact reference confirm an additional dust lip.

What is the twist direction of Corteco 12014404B?

The seal is specified with a right-hand twist.

Are Corteco 12014404 and 12014404B the same reference?

12014404 is the base reference appearing in Corteco dimensional catalog data, while 12014404B is the complete product reference used in current product data. For purchasing and identification, use 12014404B.

Can any FPM 42x56x7 seal replace Corteco 12014404B?

No. Corteco catalogs several 42x56x7 mm seals with different constructions. A replacement should also match the B1BAVISLRDX7 construction, FPM material, dust-lip configuration, twist direction and application requirements.

AI Overview

Corteco 12014404B B1BAVISLRDX7 is an FPM fluoroelastomer shaft seal measuring 42x56x7 mm, with a 42 mm inner diameter, 56 mm outer diameter and 7 mm height. The exact construction features an additional dust lip and right-hand twist. Corteco trade number is 82014404, and the EAN is 3358960144041.
