CORTECO 12015629 FPM RWDR-CALZATO 125x150/167x13/29.3 Rotary Shaft Seal

CORTECO 12015629 FPM RWDR-CALZATO 125x150/167x13/29.3 Rotary Shaft Seal

CORTECO 12015629 is a special FPM rotary shaft seal with RWDR-CALZATO design and full dimensions of 125x150/167x13/29.3 mm. This is a more complex sealing design than a conventional 125x150x13 oil seal and is catalogued for IVECO applications. When selecting a replacement, the complete geometry, FPM material and reference numbers must be considered.

Technical data - CORTECO 12015629

Full dimensions 125x150/167x13/29.3 mm

For CORTECO 12015629, the simplified dimension 125x150x13 mm does not describe the complete geometry of the seal.

The full dimensional designation is:

125 mm - nominal shaft diameter.

150 mm - basic outside diameter.

167 mm - additional diameter resulting from the extended seal construction.

13 mm - basic width of the sealing section.

29.3 mm - additional overall axial dimension of the CALZATO construction.

For this reason, CORTECO 12015629 should not be selected solely as a conventional 125x150x13 mm rotary shaft seal.

What does RWDR-CALZATO mean?

RWDR refers to a radial shaft sealing ring, while CALZATO identifies the special extended construction of this particular seal.

Unlike a conventional radial shaft seal with a simple profile, CORTECO 12015629 incorporates additional construction geometry, reflected in its full dimensions of 125x150/167x13/29.3 mm.

When selecting an equivalent, it is therefore important to match not only the shaft diameter and basic outside diameter but also the complete construction of the sealing unit.

FPM material

CORTECO 12015629 is manufactured from FPM, a fluoroelastomer material.

FPM is used in sealing applications requiring increased resistance to temperature and chemicals compared with conventional NBR. Fluoroelastomers also provide good resistance to many oils, fuels and lubricants.

Actual compatibility should always be evaluated according to the specific medium, operating temperature and other working conditions.

CORTECO 12015629 - IVECO application

CORTECO catalogues part number 12015629 in connection with IVECO applications.

Reference number:

IVECO 98499177

The OEM reference is particularly important when identifying this product because of its special RWDR-CALZATO construction.

Before installation, compatibility should be confirmed using the OEM number, specific vehicle or machine configuration and the relevant mechanical assembly.

Why is it different from a standard 125x150x13 oil seal?

A conventional 125x150x13 mm oil seal may match the three basic dimensions but may not incorporate the additional structural elements of the RWDR-CALZATO design.

CORTECO 12015629 has full dimensions of 125x150/167x13/29.3 mm.

When selecting a replacement, verify:

• CORTECO part number 12015629

• IVECO reference number 98499177

• shaft diameter 125 mm

• basic outside diameter 150 mm

• additional diameter 167 mm

• basic width 13 mm

• overall construction dimension 29.3 mm

• FPM material

• RWDR-CALZATO design

Matching only the basic 125x150x13 mm dimensions does not confirm interchangeability.

Selecting a replacement for CORTECO 12015629

The most reliable method of identification is by the complete manufacturer part number:

CORTECO 12015629

and the corresponding reference number:

IVECO 98499177

When dimensional identification is required, the complete 125x150/167x13/29.3 mm geometry should be considered rather than only the simplified 125x150x13 mm dimensions.

Installation of the RWDR-CALZATO seal

Because of its extended construction, the seal should be installed according to the requirements of the specific mechanical assembly.

Before installation, inspect and clean all mating surfaces and protect the sealing elements against mechanical damage.

The seal should not be installed using tools that apply concentrated force to individual parts of its construction. Installation force should be distributed evenly across the appropriate mounting surface.

FAQ - CORTECO 12015629

What are the dimensions of CORTECO 12015629?

The full dimensions of the seal are 125x150/167x13/29.3 mm.

Is CORTECO 12015629 a 125x150x13 oil seal?

The dimensions 125x150x13 mm describe the basic sealing dimensions, but not the complete geometry of the product. The full dimensional designation also includes 167 mm and 29.3 mm.

What material is CORTECO 12015629 made from?

The seal is manufactured from FPM fluoroelastomer.

What type of seal is CORTECO 12015629?

CORTECO identifies this seal with the RWDR-CALZATO construction designation.

What vehicle manufacturer is CORTECO 12015629 associated with?

The seal is catalogued in connection with IVECO applications.

What IVECO number corresponds to CORTECO 12015629?

The reference number is IVECO 98499177.

Can a standard 125x150x13 oil seal replace CORTECO 12015629?

Interchangeability should not be assumed. CORTECO 12015629 has a special RWDR-CALZATO construction and additional dimensions of 167 mm and 29.3 mm.

What should be checked when selecting an equivalent?

Verify the complete dimensions, FPM material, RWDR-CALZATO construction and the CORTECO 12015629 and IVECO 98499177 reference numbers.

CORTECO 12015629 - key information

CORTECO 12015629 is an FPM RWDR-CALZATO rotary shaft seal with full dimensions of 125x150/167x13/29.3 mm, catalogued for IVECO applications. The corresponding IVECO reference is 98499177. Due to its extended construction, it should not be treated as a conventional 125x150x13 mm oil seal when selecting a replacement.

Available from simmering.pl, a specialist supplier of rotary shaft seals, industrial sealing solutions and bearings. Stock in Poland with worldwide shipping.
