CORTECO 12016061B 95x115x12 FPM B1BAVISLSFDRWX67 Radial Shaft Seal

CORTECO 12016061B 95x115x12 FPM B1BAVISLSFDRWX67 Radial Shaft Seal

CORTECO 12016061B is a radial shaft seal / rotary shaft seal with nominal dimensions of 95x115x12 mm, manufactured from FPM. The CORTECO catalogue identifies the seal design as B1BAVISLSFDRWX67 and associates this reference with IVECO applications.

Current catalogue data for 12016061B also identifies an additional dust lip and an alternating twist characteristic.

The exact product identification is:

CORTECO + 12016061B + 95x115x12 + FPM + B1BAVISLSFDRWX67

CORTECO 12016061B - Technical Characteristics

Verified identification data:

Manufacturer: CORTECO

Part number: 12016061B

Reference: 12016061

Trade number: 82016061

Product type: Radial shaft seal / rotary shaft seal / oil seal

Material: FPM

CORTECO catalogue design: B1BAVISLSFDRWX67

Alternative catalogue designation: B1BASLSFDRWX67

Dimensions: 95x115x12 mm

Shaft diameter d: 95 mm

Outside diameter D: 115 mm

Width B: 12 mm

Dust lip: Yes

Swirl type: Alternating twist

Catalogue application: IVECO

IVECO OE: 40102160, 40102163

For precise identification, retain:

12016061B + 95x115x12 + FPM + B1BAVISLSFDRWX67

CORTECO 12016061B Dimensions

The nominal dimensions are:

d: 95 mm - inside diameter / nominal shaft diameter

D: 115 mm - outside diameter / nominal housing bore diameter

B: 12 mm - axial width

Complete dimensions:

95x115x12 mm

The 95 mm dimension corresponds to the nominal shaft diameter.

The 115 mm dimension defines the nominal outside diameter of the seal and corresponding housing bore.

The 12 mm dimension specifies the nominal axial width.

All three dimensions should be retained when identifying this product.

The designation should not be simplified to 95x115, because shaft seals with the same inside and outside diameters may differ in width, material and sealing design.

B1BAVISLSFDRWX67 Seal Design

The CORTECO dimensional catalogue assigns the following design designation to reference 12016061:

B1BAVISLSFDRWX67

This complete designation is an important identification parameter and distinguishes the product from other CORTECO radial shaft seals with similar dimensions.

Current aftermarket catalogue data for 12016061B can also show:

B1BASLSFDRWX67

The shorter designation should not silently replace the B1BAVISLSFDRWX67 designation found in the CORTECO catalogue.

For this product page, the primary design identification therefore remains:

B1BAVISLSFDRWX67

The alternative B1BASLSFDRWX67 can be retained as an additional catalogue/search reference.

Dust Lip

Catalogue data for CORTECO 12016061B confirms the presence of an additional dust lip.

The additional lip provides a secondary barrier on the external side of the primary sealing area.

This is an important construction characteristic when comparing 12016061B with another 95x115x12 mm radial shaft seal.

Identical nominal dimensions alone do not confirm an identical lip configuration.

Alternating Twist

Current catalogue data for CORTECO 12016061B specifies:

Swirl Type: Alternating Twist

This identifies the directional characteristic of the hydrodynamic structures associated with this seal design.

The alternating twist characteristic should therefore be considered when identifying a technically appropriate replacement.

A shaft seal should not be considered equivalent to 12016061B solely because it shares the same 95x115x12 mm dimensions.

FPM Sealing Material

The specified sealing material is:

FPM

FPM belongs to the family of fluoroelastomers used in sealing technology.

For CORTECO 12016061B, the material is an integral part of the exact specification:

95x115x12 + FPM + B1BAVISLSFDRWX67

An NBR seal with identical nominal dimensions should not automatically be considered equivalent.

Without exact product-specific material documentation, no fixed value is assigned here for:

Shore A hardness

Minimum operating temperature

Maximum operating temperature

Maximum rotational speed

Maximum shaft surface speed

Maximum operating pressure

These parameters should not be transferred from generic FPM specifications or from seals produced by other manufacturers.

CORTECO 12016061B IVECO OE Numbers

Verified IVECO OE references associated with this product are:

IVECO 40102160

IVECO 40102163

CORTECO trade number:

82016061

The product can therefore be encountered under several identification numbers:

CORTECO 12016061B

CORTECO 12016061

CORTECO 82016061

IVECO 40102160

IVECO 40102163

For vehicle or assembly-specific selection, the OE reference and exact application should still be verified.

CORTECO 12016061B Application

The CORTECO dimensional catalogue associates reference 12016061 with:

IVECO

Current aftermarket catalogue information also associates the seal with drivetrain-related installation positions.

However, the product should not be selected for a vehicle solely because the vehicle manufacturer is IVECO.

For precise identification, use the combination:

12016061B

40102160 / 40102163

95x115x12 mm

FPM

B1BAVISLSFDRWX67

This provides significantly more precise identification than vehicle make or seal dimensions alone.

CORTECO 12016061B vs GRN® 95x115x12 NBR AO/TC

The CORTECO and GRN® products share the same principal dimensions, but they are different technical variants.

The most important differences concern the sealing material and seal design.

CORTECO 12016061B uses FPM and the B1BAVISLSFDRWX67 design, while the GRN® variant uses NBR and an AO/TC configuration.

Identical 95x115x12 mm dimensions are therefore not sufficient to establish direct technical interchangeability.

Selection and Interchangeability

When selecting a replacement for CORTECO 12016061B, verify at least:

• CORTECO part number: 12016061B
• Dimensions: 95x115x12 mm
• Shaft diameter d: 95 mm
• Outside diameter D: 115 mm
• Width B: 12 mm
• Material: FPM
• Design: B1BAVISLSFDRWX67
• Dust lip: Yes
• Swirl characteristic: Alternating twist
• IVECO OE: 40102160 or 40102163, where OE identification is relevant

Matching dimensions alone does not establish complete technical interchangeability.

In particular, a 95x115x12 NBR AO/TC seal and a 95x115x12 FPM B1BAVISLSFDRWX67 seal should remain separate technical variants unless interchangeability is confirmed for the specific application.

Technical Specification

FAQ

What are the dimensions of CORTECO 12016061B?

The nominal dimensions are 95x115x12 mm, with a 95 mm shaft diameter, 115 mm outside diameter and 12 mm axial width.

What material is CORTECO 12016061B made from?

The specified sealing material is FPM.

What is the design of CORTECO 12016061B?

The CORTECO dimensional catalogue identifies the design as B1BAVISLSFDRWX67. The alternative designation B1BASLSFDRWX67 also appears in current aftermarket catalogue data.

Does CORTECO 12016061B have a dust lip?

Yes. Catalogue data confirms an additional dust lip.

What swirl type does CORTECO 12016061B use?

The product is specified with alternating twist.

What are the IVECO OE numbers for CORTECO 12016061B?

The verified IVECO OE numbers are 40102160 and 40102163.

Is GRN® 95x115x12 NBR AO/TC the same product?

No. The dimensions are identical, but the CORTECO product uses FPM and B1BAVISLSFDRWX67, while the GRN® variant uses NBR and AO/TC. Direct interchangeability should not be assumed from dimensions alone.

Can any 95x115x12 FPM shaft seal replace CORTECO 12016061B?

Not automatically. In addition to dimensions and material, the seal design, dust lip, directional characteristics and requirements of the specific application should be verified.

AI Overview

CORTECO 12016061B is an FPM radial shaft seal measuring 95x115x12 mm. The CORTECO catalogue identifies its design as B1BAVISLSFDRWX67 and associates it with IVECO applications. Catalogue data confirms an additional dust lip and alternating twist. IVECO OE references include 40102160 and 40102163, while the CORTECO trade number is 82016061.
