CORTECO 12016274 FPM B1BASLRSX7 114x135x13 - Rotary Shaft Oil Seal

CORTECO 12016274 FPM B1BASLRSX7 114x135x13 mm Rotary Shaft Oil Seal

CORTECO 12016274 FPM B1BASLRSX7 114x135x13 mm is a radial rotary shaft oil seal manufactured from FPM/FKM fluoroelastomer. It is designed for a nominal shaft sealing diameter of 114 mm, a housing bore diameter of 135 mm and an axial installation width of 13 mm. The special B1BASLRSX7 profile identifies a specific CORTECO sealing construction used in selected mechanical assemblies, including catalogue applications associated with agricultural machinery and commercial vehicles.

The product is also referenced under the designation CORTECO 12016274B. Replacement parts catalogues associate this seal with OE reference numbers from Case IH, Iveco, Laverda, New Holland and Steyr.

Technical Specifications - CORTECO 12016274

Technical note: The exact geometry of the B1BASLRSX7 profile, metal case configuration, presence of a garter spring, directional sealing features and permissible operating parameters require confirmation from the manufacturer's technical documentation. These characteristics should not be assumed solely from the construction of similar seal profiles.

What Does CORTECO 12016274 FPM B1BASLRSX7 Mean?

CORTECO - Manufacturer

CORTECO is a brand within the Freudenberg Group, specialising in sealing solutions and technical components for automotive, agricultural and industrial applications.

The manufacturer part number 12016274 identifies a specific rotary shaft oil seal measuring 114x135x13 mm and featuring the B1BASLRSX7 construction profile.

114x135x13 mm - Installation Dimensions

The dimensional designation identifies three essential measurements:

• 114 mm - nominal diameter of the shaft sealing surface.

• 135 mm - nominal diameter of the housing bore.

• 13 mm - nominal axial width of the oil seal.

All three dimensions must be checked together with the sealing profile and manufacturer part number.

FPM/FKM - Fluoroelastomer

FPM and FKM are alternative designations for the same general family of fluorocarbon elastomers.

Fluoroelastomers are commonly used in sealing applications requiring resistance to many oils, lubricating greases, fuels and elevated temperatures.

Actual resistance depends on the specific elastomer compound, operating medium and service conditions.

B1BASLRSX7 - Special CORTECO Seal Profile

B1BASLRSX7 identifies a specific CORTECO rotary shaft seal construction.

It should not automatically be considered equivalent to conventional BA, BASL, B1 or standard double lip oil seal profiles.

Individual elements of the designation may refer to construction characteristics, but their precise interpretation for this product requires confirmation from the manufacturer's catalogue.

When selecting a replacement, the complete profile designation and equipment requirements must be considered.

Construction of CORTECO B1BASLRSX7

Radial Shaft Sealing

The oil seal operates where a rotating shaft passes through a mechanical housing.

Its sealing element works in contact with the shaft surface, restricting the escape of oil or another compatible lubricant.

The sealing performance depends on the complete operating arrangement, including shaft condition, lubrication, temperature and installation quality.

Special Sealing Profile

B1BASLRSX7 is a specific radial shaft seal profile.

Compared with conventional oil seals, special profiles may differ in:

• Sealing lip geometry.

• Additional sealing elements.

• Outer case construction.

• Contact position on the shaft.

• Installation requirements.

• Operating characteristics.

For this reason, an oil seal with identical dimensions but a different profile may not provide equivalent performance.

Shaft Contact Surface

The nominal shaft sealing diameter is 114 mm.

The condition of the shaft surface directly affects sealing performance and service life.

Important factors include:

• Appropriate surface roughness.

• Absence of mechanical damage.

• Protection against corrosion.

• Correct shaft geometry.

• Suitable lubrication.

• Controlled radial shaft runout.

Housing Installation

The outer section of the seal is designed to fit into a housing bore with a nominal diameter of 135 mm.

Correct fit and installation are essential for stable positioning and effective sealing at the housing interface.

FPM/FKM Material Properties

Resistance to Mineral Oils

FPM/FKM generally provides good resistance to many mineral-based lubricating oils.

This is an important characteristic in mechanical transmissions and industrial lubrication systems.

Resistance to Industrial Greases

Fluoroelastomers can be suitable for contact with many industrial lubricating greases, provided chemical compatibility is confirmed.

Elevated Temperature Resistance

FPM/FKM generally offers better resistance to elevated temperatures than standard NBR rubber.

However, a specific operating temperature range should not be assigned to CORTECO 12016274 without verified manufacturer data.

Chemical Resistance

Many FPM/FKM compounds provide favourable resistance to selected hydrocarbons, oils and fuels.

This does not mean that the material is compatible with every chemical substance.

Is FPM the Same as Viton?

Not necessarily.

FPM/FKM is a general designation for fluoroelastomers, while Viton is a registered trademark for specific fluoroelastomer materials.

The FPM designation alone does not confirm that this CORTECO seal contains genuine Viton-branded material.

CORTECO 12016274 - OE Reference Numbers and Catalogue Cross-References

The following reference numbers are listed in the supplied cross-reference data for CORTECO 12016274B.

These reference numbers assist with part identification but do not independently confirm compatibility with a particular vehicle or machine model.

Case IH Reference Numbers

The supplied Case IH cross-references include:

Before installation, the required part number should be checked against the specific equipment manufacturer's parts catalogue.

Iveco Reference Numbers

The supplied Iveco cross-references include:

Compatibility with a specific Iveco vehicle or mechanical assembly requires confirmation using the relevant OE documentation.

New Holland Reference Numbers

The supplied New Holland cross-references include:

A New Holland catalogue reference does not establish universal compatibility with every machine manufactured under this brand.

Laverda and Steyr Reference Numbers

The supplied reference data also includes:

• Laverda: 98461686.

• Steyr: 504127327.

These are part identification references, not confirmation of fitment in specific equipment models.

Applications of CORTECO 114x135x13 FPM Oil Seal

Radial rotary shaft oil seals are used in mechanical systems requiring lubricant retention around rotating shafts.

Typical application categories include:

• Agricultural machinery.

• Commercial vehicles.

• Mechanical gearboxes.

• Drive assemblies.

• Rotating mechanisms.

• Shaft housings.

• Industrial mechanical equipment.

These are general application categories for rotary shaft seals.

The specific installation location of CORTECO 12016274 must be verified using the OE part number and equipment documentation.

Agricultural Machinery

Rotary shaft seals are used in agricultural equipment where rotating components require effective lubricant retention.

The catalogue references to Case IH, New Holland, Laverda and Steyr may help identify the correct replacement component.

Commercial Vehicles

Radial shaft seals are used in suitable commercial vehicle assemblies to restrict lubricant leakage.

The Iveco reference numbers can assist with part identification, subject to verification of the specific vehicle and assembly.

Industrial Mechanical Systems

FPM rotary shaft seals may be used in industrial assemblies requiring compatibility with selected lubricants and operating conditions.

Final selection must be based on the complete technical requirements.

Why Is the B1BASLRSX7 Profile Important?

Oil seals with identical dimensions can have significantly different internal constructions.

Potential differences include:

• Primary sealing lip geometry.

• Additional sealing elements.

• Shaft contact arrangement.

• Outer case construction.

• Installation orientation.

• Elastomer material.

• Operating characteristics.

Therefore, a standard 114x135x13 mm rotary shaft oil seal is not automatically a suitable replacement for CORTECO 12016274.

Can a Standard TC Oil Seal Replace B1BASLRSX7?

Not automatically.

A standard TC profile generally identifies a double lip rotary shaft oil seal, but this does not establish equivalence with the specific CORTECO B1BASLRSX7 construction.

Even if dimensions and material match, the sealing geometry and application requirements may differ.

FPM vs NBR - Material Comparison

An FPM seal should not automatically be replaced with an NBR version, even when the dimensions are identical.

The operating fluid, temperature and complete seal construction must be considered.

Selection and Interchangeability of CORTECO 12016274

Before purchasing, verify:

1. Complete manufacturer part number CORTECO 12016274.

2. Alternative catalogue designation 12016274B, where applicable.

3. Nominal shaft diameter of 114 mm.

4. Nominal housing bore diameter of 135 mm.

5. Axial width of 13 mm.

6. FPM/FKM elastomer material.

7. B1BASLRSX7 sealing profile.

8. Equipment OE reference number.

9. Operating fluid.

10. Operating temperature.

11. Shaft rotational speed.

12. Installation requirements.

Dimensional compatibility is necessary but may not be sufficient to establish complete interchangeability.

Why Should the OE Number Be Checked?

The OE number helps identify the component specified for a particular vehicle or machine assembly.

It is especially useful when several oil seals share similar dimensions but differ in construction.

Can Another Manufacturer's Seal Be Used?

A replacement may be considered after verifying the complete dimensions, elastomer material, sealing profile, construction and operating conditions.

Matching dimensions alone do not guarantee technical equivalence.

Installation of CORTECO B1BASLRSX7

Shaft Preparation

Before installation, clean the shaft thoroughly and inspect the sealing surface.

Scratches, corrosion and excessive wear in the sealing contact area may cause leakage.

Housing Preparation

The housing bore should be clean, correctly dimensioned and free from mechanical damage.

Inspect the seating surface before installing the seal.

Protecting the Sealing Elements

Avoid pulling the sealing lip over sharp edges, threads or shaft grooves without protection.

Use a suitable installation sleeve where necessary.

Correct Installation Orientation

Install the seal according to the equipment manufacturer's instructions.

The installation direction should not be determined solely from the dimensions or appearance of a similar product.

Uniform Installation Force

Use an appropriate installation tool to press the seal evenly into the housing without deforming its construction.

Lubrication Before Operation

Provide suitable lubrication at the sealing contact surface according to the application requirements.

Avoid unintended dry-running conditions.

Installation Depth

The seal must be installed at the correct depth for the mechanical assembly.

The 13 mm axial width and the position of the sealing contact area must be considered.

Storage Recommendations

Store the oil seal in a clean, dry environment, away from excessive heat, direct sunlight and substances that may damage the elastomer.

Avoid deformation of the sealing elements during storage and handling.

Frequently Asked Questions - CORTECO 12016274 FPM B1BASLRSX7

What Are the Dimensions of CORTECO 12016274?

The nominal inside diameter is 114 mm, the outside diameter is 135 mm and the axial width is 13 mm.

What Material Is CORTECO 12016274 Made From?

The sealing elastomer is FPM/FKM fluoroelastomer.

What Does B1BASLRSX7 Mean?

B1BASLRSX7 identifies a special CORTECO sealing profile. Its detailed geometry must be verified against the manufacturer's technical documentation.

Are CORTECO 12016274 and 12016274B the Same Product?

The designation 12016274B appears in the supplied catalogue cross-reference information for CORTECO 12016274. Complete product identification should be verified before ordering.

Is CORTECO 12016274 Suitable for Case IH Machinery?

The supplied reference data includes Case IH numbers such as 40003800 and 40101341. Compatibility with a specific machine model requires verification.

Is CORTECO 12016274 Suitable for Iveco Vehicles?

The supplied reference data includes Iveco numbers such as 40003800, 40100880 and 40101340. The OE number of the specific vehicle must be checked.

Is CORTECO 12016274 Resistant to Oil?

FPM/FKM generally provides good resistance to many mineral oils. Compatibility with the specific operating fluid must be confirmed.

Can Another 114x135x13 mm Oil Seal Be Used?

Only after verifying the sealing profile, elastomer material, construction and equipment requirements. Matching dimensions alone do not confirm interchangeability.

CORTECO 12016274 - Quick Technical Overview

CORTECO 12016274 is an FPM/FKM radial rotary shaft oil seal measuring 114x135x13 mm. Its special B1BASLRSX7 profile requires verification of the complete sealing construction when selecting a replacement. Also referenced as 12016274B, the product has catalogue cross-references associated with Case IH, Iveco, Laverda, New Holland and Steyr equipment.
